H I B I S C U S
SIMPLE SELECT DUAL SHOWER HEAD SHOWER SYSTEM
SISTEMA DE DUCHA CLÁSICA DOBLE SIMPLE SELECT
SKU: 949740
BEFORE YOU BEGIN
We recommend consulting a professional if you are
unfamiliar with installing plumbing �xtures. Signature
Hardware accepts no liability for any damage to the
plumbing, or for personal injury during installation.
Observe all local plumbing and building codes.
Unpack and inspect the product before shipping
damaged product. If any damage is found, contact
our Customer Relations team at 1-800-221-3379.
ANTES DE COMENZAR
Le recomendamos que consulte a un profesional si no
sabe cómo instalar accesorios de plomería. Signature
Hardware no asume ninguna responsabilidad con
respecto a los daños causados al inodoro, sistema de
plomería, suelo o daños personales durante
la instalación.
Cumpla con todas las normas locales de plomería y
construcción.
Retire el inodoro del empaque y verifique si se
produjeron daños durante el envío. Si encuentra algún
daño, comuníquese con nuestro equipo de Servicio al
cliente al 1-800-221-3379.
GETTING STARTED
Ensure that you have gathered all the required
materials that are needed for the installation.
CÓMO COMENZAR
Asegúrese de haber reunido todos los materiales
necesarios para la instalación.
For Warranty information, please visit: signaturehardware.com/services/warranty
Para obtener información sobre la garantía, visite: signaturehardware.com/services/warranty
TOOLS AND MATERIALS:
HERRAMIENTAS Y MATERIALES:
Plumbers
Tape
Cinta de
fontanería
Keyhole Saw
Gafas de seguridad
Sierra de punta
Thermometer
Screwdriver
Termómetro
Destornillador de
cabeza plana
Strap
Wrench
Llave de
cincha
NOTE:
You may require di�erent, more specialized tools to
install this valve and the plumbing.
NOTA:
Usted puede necesitar herramientas diferentes y más
especializadas para instalar esta válvula y el sistema
de plomería.
1
Adjustable
Phillips
Wrench
Screwdriver
Llave
Destornillador
ajustable
Phillips
Safety Glasses
Tape Measure
Cinta métrica
Flathead
Silicone Sealant
(100% Neutral Cure)
Sellador de silicona
(100% curado neutro)
REVISED 02/03/2021
CODES: SHHB8040, SHRSC40S
SHRS1025S, SH5001SS
1.800.221.3379

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HIBISCUS 949740 and is the answer not in the manual?

Questions and answers

Related Manuals for Signature Hardware HIBISCUS 949740

Summary of Contents for Signature Hardware HIBISCUS 949740

  • Page 1 H I B I S C U S SIMPLE SELECT DUAL SHOWER HEAD SHOWER SYSTEM SISTEMA DE DUCHA CLÁSICA DOBLE SIMPLE SELECT SKU: 949740 BEFORE YOU BEGIN TOOLS AND MATERIALS: We recommend consulting a professional if you are HERRAMIENTAS Y MATERIALES: unfamiliar with installing plumbing �xtures.

  • Page 2: Valve Installation

    H I B I S C U S SIMPLE SELECT DUAL SHOWER HEAD SHOWER SYSTEM SISTEMA DE DUCHA CLÁSICA DOBLE SIMPLE SELECT SKU: 949740 VALVE INSTALLATION 2. Unscrew the screws, and remove the plaster guard. Then remove the diverter bonnet nuts and diverter INSTALACIÓN DE VÁLVULA cartridges, valve bonnet nut, cartridge and stop valves from valve body before soldering.
  • Page 3 H I B I S C U S SIMPLE SELECT DUAL SHOWER HEAD SHOWER SYSTEM SISTEMA DE DUCHA CLÁSICA DOBLE SIMPLE SELECT SKU: 949740 3. If the hot and cold inlets are reversed (hot on right 4. Use two 1/2” iron pipe plugs in shower outlet and and cold on left), remove bonnet nut from the valve tub spout outlet.
  • Page 4 H I B I S C U S SIMPLE SELECT DUAL SHOWER HEAD SHOWER SYSTEM SISTEMA DE DUCHA CLÁSICA DOBLE SIMPLE SELECT SKU: 949740 5. Turn on water lines. Press buttons allowing water to To adjust the desired maximum water temperature, �ow from outlets until all foreign matter has cleared remove the limit stop ring from the cartridge the line.
  • Page 5 H I B I S C U S SIMPLE SELECT DUAL SHOWER HEAD SHOWER SYSTEM SISTEMA DE DUCHA CLÁSICA DOBLE SIMPLE SELECT SKU: 949740 7. To install the plaster guard, place the guard onto the For colder water valve body and secure with the screws. Para agua más fría 7.
  • Page 6 H I B I S C U S SIMPLE SELECT DUAL SHOWER HEAD SHOWER SYSTEM SISTEMA DE DUCHA CLÁSICA DOBLE SIMPLE SELECT SKU: 949740 Copper (Soldering)/ Cobre (Soldar) If you are replacing your plumbing valve, please review the common plumbing methods illustrated below (Copper, IPS, and PEX).

  • Page 7: Trim Installation

    H I B I S C U S SIMPLE SELECT DUAL SHOWER HEAD SHOWER SYSTEM SISTEMA DE DUCHA CLÁSICA DOBLE SIMPLE SELECT SKU: 949740 TRIM INSTALLATION 2. Secure backplate (2) to the valve body (3) with the screws (1) using Allen wrench provided. INSTALACIÓN DE RECORTE 2.
  • Page 8 H I B I S C U S SIMPLE SELECT DUAL SHOWER HEAD SHOWER SYSTEM SISTEMA DE DUCHA CLÁSICA DOBLE SIMPLE SELECT SKU: 949740 3. With the Allen wrench (1) provided, turn the 4. Loosen the stop plugs (1) with wrench and place adjusting bolts (2) clockwise until it connects to the the stop valves (1) onto the holes in the bottom of diverter cartridges (3) and compresses to the limit...
  • Page 9 H I B I S C U S SIMPLE SELECT DUAL SHOWER HEAD SHOWER SYSTEM SISTEMA DE DUCHA CLÁSICA DOBLE SIMPLE SELECT SKU: 949740 5. Holding escutcheon (2) in place, tighten mounting 6. Water test: nut (3) onto the backplate (1). Turn on water lines.

  • Page 10: Component Installation

    H I B I S C U S SIMPLE SELECT DUAL SHOWER HEAD SHOWER SYSTEM SISTEMA DE DUCHA CLÁSICA DOBLE SIMPLE SELECT SKU: 949740 COMPONENT INSTALLATION 7. Install the handle (1) into backplate and secure with set screw (2). Cover with index (3). COMPONENTE INSTALACIÓN 1.

  • Page 11: Cleaning And Maintenance

    H I B I S C U S SIMPLE SELECT DUAL SHOWER HEAD SHOWER SYSTEM SISTEMA DE DUCHA CLÁSICA DOBLE SIMPLE SELECT SKU: 949740 3. Install the escutcheon. 5. Apply plumber's tape to the threads and then install the new shower head onto the shower arm clockwise. 3.
  • Page 12 H I B I S C U S SIMPLE SELECT DUAL SHOWER HEAD SHOWER SYSTEM SISTEMA DE DUCHA CLÁSICA DOBLE SIMPLE SELECT SKU: 949740 Part Name / Nombre de pieza Part No. Diverter Bonnet Nut / Diverter Bonnet Nut OBPF3F70014 Diverter Cartridge / Diverter Cartridge OBPF2F20002...
  • Page 13 H I B I S C U S SIMPLE SELECT DUAL SHOWER HEAD SHOWER SYSTEM SISTEMA DE DUCHA CLÁSICA DOBLE SIMPLE SELECT SKU: 949740 Part Name / Nombre de pieza Part No. Handle Assembly / Ensamblaje de la llave OBPF7KF13030* Mounting Nut / Tuerca de montaje OBPF1F70009 Screw / Tornillo...
  • Page 14 H I B I S C U S SIMPLE SELECT DUAL SHOWER HEAD SHOWER SYSTEM SISTEMA DE DUCHA CLÁSICA DOBLE SIMPLE SELECT SKU: 949740 Part Name Nombre de pieza Nom de la pièce Bras de douche de Brazo para regadera de Shower arm plafond techo...
