  • Page 1 IQTouch HC900Pro ——User Manual——...

  • Page 2: Table Of Contents

    3.1 External Computer and Touch Connecting................18 3.2 AV Connecting.........................19 3.3 Video-OUT..........................20 3.4 RS232............................20 4.Turning on/off............................24 4.1 Power On..........................24 4.2 Power Off..........................25 5.IQ OS..............................26 5.1 Android Home Page........................ 26 ..........................27 5.1.1 Status Bar ..........................28 5.1.2 Sidebar ..........................40 5.1.3 Floating Bar...

  • Page 3: Safety Instruction

    Safety Instruction For your safety, please read the following instruction before you use the machine. Serious injury or property damage may be caused by improper operations. Do not try to repair the machine by your own. Disconnect the machine from power supply immediately if major failures occur.
  • Page 4 Clean the power plug regularly. Continued use of this machine may cause fire or electric shock if the plug is not  clean for a long time. Pull out the power plug before cleaning it with a dried cloth  Do not put items on the top of the machine.
  • Page 5 components are easily broken if the machine is moved in an improper way. Before you move the machine, disconnect all external connections and  separate all topple preventing machines. Move the machine carefully to prevent it from being hit or squeezed, especially the screen, which may cause injury if broken Do not cover or block up any vents on the machine.
  • Page 6 Additional advice： Use the machine in an environment with comfortable lighting. It is harmful  to your eyes to watch in a too bright or too dark environment. Relax your eyes watching for a period of time.  Keep sufficient distance from the machine to protect your eyes and prevent ...

  • Page 7: Product Overview

    1. Product Overview 1.1 Appearance Introduction Front View Rear View...

  • Page 8: Front Control Panel

    Power Button Screen Light Sensor Power socket IR Receiver Power switch Microphone Array Rear connecting port 1 Built-in Camera Rear connecting port 2 Document Camera Built-in computer ports(ops) Touch Border 1.2 Front Control Panel Front Button Button Function on/off： If the power is on, press it to enter sleep mode. Press and hold for 2 ...
  • Page 10 Rear Ports Introduction： Name Function Microphone input port Audio input port, used in combination with “VGA IN” Audio In VGA signal input port. VGA In Used in combination with “Touch USB 3.0” to operate the PC in touch mode. HD signal input port 1. HDMI 1 In Used in combination with “Touch USB 3.0”...

  • Page 11: Remote Control

    Remote Control Buttons Functions Turn on/off. Standby Enter/exit the screen off mode. Mute or unmute. Microphone switch. Up/Down/Left/Right selection button. Confirmation button. Press once to return to the previous page; Press twice to exit the current program. Note: In the settings page, press once to exit. Return to homepage.
  • Page 12 Remote Control Area The effective receiving area is about 3 meters with 30° angle from vertical point to the left and right. And the effective receiving area is about 5 meters from the front of device. Note that the remote control signal receiver locates at the position of power indicator.

  • Page 13: Installation

    2.Installation 2.1 Safety Precautions Installation Environment Installation Direction 2.2 Installation Step...
  • Page 14 Step1: Punching holes in the wall Mark 8 holes location on the wall according to wall mounting bracket A and use the drill bit drilling the 8 holes. Depth of holes not less than 90mm (Ref. Picture 1) Step2: Expansion bolt installation Press the expansion bolt into 8 holes.
  • Page 15 Step4: Install the left& right hang bracket B to IQTouch. Use screws fix the hang bracket B at the back of IQTouch. Please check the direction of hang bracket B before installation. (Ref. Picture 4) Step5: Hang IQTouch on the wall mounting bracket A Hanging the left &right hang bracket B to the wall mounting bracket A, please ensure two hang brackets B total hang on wall mounting bracket A, then tighten the screws of hang bracket B to prevent it slide.

  • Page 16: Weight Loading

    2.3 Weight Loading Net weight of the machine(65",75",86"): 40kg(±2kg), 50kg(±2kg), 61kg(±2kg).  When using a mobile stand, ensure that the weight of the machine is less than the loading capacity of the mobile stand.  When using the wall-mount bracket, ensure that the wall can support the weight of the machine. We recommend that the wall surface be reinforced and have a loading capacity 4 times of the weight of the machine.
  • Page 17 Vertical Installation When installing, try to keep the machine vertical. The vertical tilt range allowed for wall-mount installation is ±3 degrees. An excessive tilt angle may cause the screen glass to fall off or the machine to collapse.

  • Page 18: Ops Installation

    2.4 OPS Installation The built-in computer does not support hot plugging. Therefore, you must insert or remove the built-in computer when the display is powered off. Otherwise, the display or built-in computer may be damaged. Perform the following steps to install the built-in computer： Step1 Unscrew the screws by hand to remove OPS shielding cover.
  • Page 19 Step3 Secure OPS to the machine by using the screws.

  • Page 20: Connecting And Setting

    3.Connecting and Setting For safety, please do not connect any power supply before the external devices setup. 3.1 External Computer and Touch Connecting 1) Connect a VGA cable (15 pin) between the VGA and external PC. Connect an earphone cable between the PC and audio at the same time. 2) Connect a USB cable between the external PC and USB terminal.

  • Page 21: Av Connecting

    3.2 AV Connecting AV IN  1) Connect an AV cable with the device with AV-OUT (Yellow is Video, Red is Audio-R, White is Audio-L). 2) Plug the POWER cord and switch it on from the rear panel. 3) Press to turn on the panel.

  • Page 22: Video-Out

    1) Connect a YPbPr cable with the device with YPbPr. 2) Plug the POWER cord and switch it on from the rear panel. 3) Press to turn on the panel. 4) Select Signal source to YPbPr source. Front HDMI/ HDMI 1/ HDMI 2 ...

  • Page 23: Rs232

    1) Connect a HDMI cable with the device with HDMI. 2) Plug the POWER cord and switch it on from the rear panel. 3) Press to turn on the panel. 3.4 RS232 1) Connect a serial port cable with the device. 2) Plug the POWER cord and switch it on from the rear panel.
  • Page 24 RS232 code list RS232 Code for Android Firmware Function Required Commands(Hex) Power on 7F 08 99 A2 B3 C4 02 FF 01 00 CF Power off 7F 08 99 A2 B3 C4 02 FF 01 01 CF Mute/Unmute 7F 08 99 A2 B3 C4 02 FF 01 02 CF Signal source 7F 08 99 A2 B3 C4 02 FF 01 06 CF Enable whiteboard...
  • Page 25 NOTE: XX indicates the mode. 00-standard, 01-ECO mode, 02-custom，03-auto Enable the annotation function 7F 08 99 A2 B3 C4 02 FF 01 40 CF Increase backlight 7F 08 99 A2 B3 C4 02 FF 01 47 CF brightness Decrease backlight 7F 08 99 A2 B3 C4 02 FF 01 48 CF brightness 7F 08 99 A2 B3 C4 02 FF 09 XX CF...

  • Page 26: Turning On/Off

    4.Turning on/off 4.1 Power On Step 1 Use AC power (100V~240V, 50Hz/60Hz) as the machine power source. Make sure the power plug fully inserted and that the ground wire of the outlet is properly connected. Step 2 Turn on the rocker switch (on the rear side of the machine, next to the power socket) , after a power source has been connected.

  • Page 27: Power Off

    4.2 Power Off When the machine enters sleep mode or is turned off, the system will first detect whether the built-in computer  is turned off. If not, it will turn off the computer first and then enters the sleep mode or shutdown. Please shut down the machine before disconnecting the power source, or it may damage the machine.

  • Page 28: Iq Os

    5.IQ OS 5.1 Android Home Page The machine will automatically enter the home page after starting up. In any interface, press the "Home" button on the remote control or floating bar to enter the home page. Swipe the homepage to the left and it will show the recent application and screen shot. You can...

  • Page 29: Status Bar

    choose one to clear or clear all. Swipe the homepage to the right and it will show all the applications the interactive display has. 5.1.1 Status Bar Status icons (including Wi-Fi and hotspot status) are displayed in the top right corner of the homepage.

  • Page 30: Sidebar

    5.1.2 Sidebar The sidebars are divided into left sidebar and right sidebar. Click on the icon floating on the left and right side of the screen to show the sidebar. The functions are Home, Back, Annotation, Capture, Freeze, Recent, Control panel, and Input. Icon Name Function...
  • Page 31 Icon Name Function Freeze Freeze current page. Touch the screen once to unfreeze. Show recent application you used. Recent Control Please check the detail below panel Please check the detail below Input Control panel Click icon to show the control panel which consists of the task management bar, toolbar, and notification bar.
  • Page 32 Task Management Bar  The user can perform the following operations using the task management bar： 1) Open an app: Tap the task management widget to enter the app interface. 2) Close an app: Swipe left and right to close the corresponding app. 3) Close all apps: Tap the “...
  • Page 33  Tool The user can perform the following operations on the toolbar: 1) Quick access to Calendar, Clock, Setting, Calculator, Screenshot, Record, Camera, Screen Recording and Wireless Screen Sharing, Vote and Sign in. Calendar Click icon in the notification panel to show the calendar interface that user can check time and mark the events.
  • Page 34 Tap the “ ” icon to exit the screenshot. Tap the “ ” to screenshot the current selected area. Screenshot will be saved in: File Commander -> Pictures -> Screenshots -> Image “Screenshot”, “Record”, “Screen Recording” are only available in “Tool”. “Screenshot”...
  • Page 35 Image and video took by Camera will be saved in: File Commander -> DCIM -> Camera Screen Recording Click icon to enter screen recording mode. User can choose to screen record with or without external audio (Microphone) sound. The recording will be saved in subsequent 45 minutes long sessions.
  • Page 36 “Vote” only works when both the machine and the mobile device are connected to the internet. User will see the voting topic and options on the mobile device after the QR code is scanned. After making the selection, tap “submit” to cast vote.
  • Page 37 In the voting process, the number of voters is displayed in real-time under the QR code. The user can tap the “Result” button to terminate the current vote process and show the voting results. The voting results can be displayed in both the “Pie chart“ or “Bar chart” form.
  • Page 38 The user can tap “Insert into whiteboard” to insert the current voting results into the whiteboard. Sign in Click icon to enter sign in. The function is for the attendees to sign in the meeting. Attendees can use their mobile phones to scan the QR code to sign in. After the attendees have signed in, the relevant information is synchronized to the sign-in form in real-time: Scan the QR code with your mobile devices “Sign In”...
  • Page 39 Your devices will be directed to a website for you to input your name, company name, and department name. After the user tap submits from their mobile devices, their input will be shown on the Sign-in list. The meeting host can tap “Complete” to finish the signing process. After the meeting host tap “Complete”, users can use their mobile device to scan the QR code to download the Sign-in List onto their mobile devices.
  • Page 40 2) Wi-Fi / Hotspot Switch On/Off: Tap the “Wi-Fi” button to turn on/off the Wi-Fi; long press to enter the settings page. Tap the “Hotspot” button to turn on/off the Hotspot; long press to enter the settings page. 3) Adjust Volume / Brightness: Slide your finger on the bar to adjust volume and brightness. 4) Bottom bar:When the bottom toolbar is closed, the toolbar will not be displayed at the bottom but on toolbar from Control Panel.
  • Page 41 Input Click icon to show the source channel list, and the user can switch channel.

  • Page 42: Floating Bar

    The icon floating on the desktop can be moved freely and displayed in any interface. Click the IQ icon, it will shows the pop-up menu , the functions are Home, Back, Annotation and Capture. You can expand/hide the tool icons by touching it once.

  • Page 43: Android Settings

    Icon Name Function Show the source channel list, and the user can switch channel. Input User can switch directly to the built-in computer Windows channel. Show recent application you used. Recent Show all the applications the interactive display has. Apps Enter browser page.

  • Page 44: Network

    5.2.1 Network Enter the “Network” submenu to set settings for Wi-Fi, LAN, Hotspot Setting, and Other Settings. Wi-Fi Turn on the wireless network, which automatically connects the display to the available wireless network.
  • Page 45 View the MAC address, IP address, gateway, subnet mask, and DNS information. The user can customize settings to automatically obtain an IP address of the Ethernet or set a static IP address as needed. Hotspot Setting The user can customize relevant settings like Network Name or Password for portable Wi-Fi hotspot.

  • Page 46: Application Notification

    Other settings The user can customize settings for network reset, network upgrade, timing reset, network always on, change network mode, and network proxy. 5.2.2 Application Notification Enter the “Application Notifications” submenu to choose whether the app receives notifications.

  • Page 47: Display

    5.2.3 Display Enter the “Display” submenu to set the screen backlight brightness, blue-light filter, close bottom toolbar.  Auto Brightness: Turn on Auto Brightness, it can automatically adjust screen brightness based on ambient light.  Brightness: The user can set the screen to automatically or manually adjust the brightness between 0-100. ...

  • Page 48: Power On/Off Schedule

    5.2.5 Power on/off Schedule The “Scheduled Power-On/Off” submenu allows the user to set the automatic power on/off, or customize power After setting the power-on time and power-off time, the system will automatically power on/off time. on or power off when the scheduled time is up.

  • Page 49: Personal Settings

    Choose the time that the machine power on/off automatically, and confirm it. 5.2.6 Personal Settings The “Personal Settings” menu allows the user to customize USB device system host, camera, microphone and touch for wakeup etc. settings.
  • Page 50  External USB device dependency: Options include Windows, Android, and Follow the system. The default option is the built-in system.  Camera: Turn on/off the built in camera.  Sleep: Turns on/off sleep mode. When sleep mode is turned on, if there is no operation within the specified time, the device will sleep automatically and windows will shut down at the same time.

  • Page 51: System Space

     CEC Auto Power Off: When “CEC Auto Power Off” is enabled: Connect the HDMI port of the machine to an external CEC device. If the machine is turned off, the CEC device automatically turns off after receiving the command. ...
  • Page 52  About the Device: View device name (customizable), Android version and firmware version, update System. Users can modify the name of the interactive display.  Date and Time: The user can customize for the device to automatically adjust date and time, time zone provided by the Internet, or customize manually the date and time, and choose whether to enable the 24-hour...

  • Page 53: Restore To Factory Settings

    system.  Language and Keyboard: The user can set their preferred language and input method. The language options include Simplified Chinese, Traditional Chinese, Thai language , Korean language, English. 5.2.9 Restore To Factory Settings The “Restore To Factory Settings” submenu allows the user to restore factory settings and it will...

  • Page 54: Application

    erase all data within the device. 5.3 Application 5.3.1 Whiteboard Click icon to open whiteboard app. The pen tool of whiteboard is selected by default and it can be written directly. Support single-point and multi-point up to 20 points. Moreover, we support pen writing by using matched writing pen with thick and thin dual head.
  • Page 55 Icon Function Open the setting interface to set up Click to import data from file management, user could import the pictures/ whiteboard data(PNG)/ screenshots(PNG) from system files or USB. Click to insert text, and show the keyboard. (Default is Roboto , 40pt) to set the default text setting.
  • Page 56 Click to show the page thumbnails. Exiting the whiteboard Whiteboard Functions  Object recognition switch Click to choose thin and thick pen mode or multi-touch mode. When the switch is swiped to the left, it enters the thick and thin pen mode , and you can write with the thick and thin double-tip pen that comes with HC900Pro.
  • Page 57  Insert Text Click to insert text, and show the keyboard. (Default is Roboto, 40pt) Click to set the default text setting. Text Color: Black/White/Red/Yellow/Green/Blue/Purple (default is White) Text Size: 30-180 (click A to change the font size)  Insert custom shape Click to insert the anto shape.
  • Page 58 Color: Black/White/Red/Yellow/Green/Blue/Purple (default is White)  Plugins Click to choose the camera of plugins, such as visualizer, recorder. When there is more than one external device connected, you can choose the split mode to view the screen separately.  Page Operation Click at the lower right corner in the discussion mode.
  • Page 59 On the Navigation page, you can select, share or delete writing pages according to requirements. Click to select all pages. Click to delete selected pages. Click to exit the Navigation. Click , the writing pages you choose will export in the different form such as PNG, JPEG and PDF.

  • Page 60: File Commander

    5.3.2 File Commander Enter the File application , you can click the submenu at the left side according to requirements, preview internal storage, external storage devices connected via the USB ports, cloud stored files, FTP uploaded files, and local network files, as shown in the following figure. Notes：Users can click the icon at the top right corner to add categories.
  • Page 61 1. Search: Enter the File Viewer application, and click . In the dialog box that is displayed, enter keywords in the search box according to requirements. The system will display a list of files that match the keywords. 2. Filtering : You can click the menu at the left side to display files by type, for example, document, picture, music, video, archive and the downloaded.
  • Page 62 3.New Folder: Enter the File Viewer application, and click to create folder. 4. Paste: Choose the files, picture or video to paste to internal storage, external storage.

  • Page 63: Eshare Pro

    For details on other operations, click in the upper right corner for more operations. 5.3.3 Eshare Pro Application note The main function of this application is to wirelessly transmit the content of mobile phones, tablets or computers to the display, and truly achieve the wireless screen transmission function of the...
  • Page 64 projection device and the projected device (note: mobile phones, tablets or computers need to be on the same local area network). Operating instructions 1) Click (multi-screen interaction) icon to open the multi-screen interaction interface, and the application display interface is as shown. 2) Function activation Activate it only through connecting network if you have purchased EShare serial number.
  • Page 65  Android mobile phone connection network, scan the multi-screen interactive interface QR code to download and install E-share application software (Apple mobile phone does not need to download);  The mobile phone needs to use the same network as the all-in-one. The Android mobile phone can open the E-share to cast the screen, and the Apple mobile phone can open the Air Play to cast the screen.
  • Page 66 Show Device Name on Screen: The device name is displayed on the screen when it is turned on Airplay visible: Airplay visible when it turned on. Laptop screen sharing The screen sharing of the laptop needs to be used with the IQShare button. The IQShare button is as shown below: Note: Before using the IQShare button wireless screen function, user needs to make sure that the hotspot of the Touch screen is turned on.
  • Page 67  Pairing completed When the touch screen successfully connects to the laptop, the indicator light of the IQShare button will no longer flash blue.  Screen sharing Press the button of IQShare button, the blue light will be dimmed, which means the screen sharing is successful, and the screen and sound of the laptop will be mirrored to the touch screen;...

  • Page 68: Built-In Pc Operation

    6.Built-in PC Operation 1) Select PC signal source to enter PC interface. The following are three ways to select a signal source channel.  Swipe your finger up from the left and right side to bring up a toolbar then click input. ...

  • Page 69: Packing Lists

    7.Packing Lists Name Quantity（Set） IQTouch Power Cord (Type C) Writing Pen Remote Control HDMI Cable Touch Cable Type-C Cable Wall Mounting Bracket User Manual Certification Warranty Card Packing List...

  • Page 70: Troubleshooting

    8.Troubleshooting Remote Control Check whether there is object between remote control and  panel receiver; Remote control out of order Check whether the battery is installed correctly;  Check whether the battery is drained.  Touch Make sure infrared frames have not been obscured. ...
  • Page 71 panel is connected correctly. No image is displayed or the Modify the color settings.  image is black and white. Check the color system.  This is the general user manual for HC900Pro interactive flat panel. Some details may be different from the actual product.
