- Page 1 ENVIRONMENTAL INSTRUMENTS, LLC 144 Industrial Park Drive SuiteA-3 Waynesville, NC 28786 Fluoroprobe O & M Manual MODEL FL-2-S0 NEW WEBSITE: WWW.thefluoroprobe.com From Process Control Services Phone: (02) 9319 1808 Fax: (02) 9319 2786...
-
Page 2: Table Of Contents
Fluoroprobe TABLE OF CONTENTS Section 1 Product Description Section 2 Control Settings - Description Control and Set Points Section 3 Introduction to Calibration 1. Air Saturated Water Calibration 2. Zero Calibration 3. Air Calibration 4. Calibration Using Hand Held DO Meter 5. - Page 3 Fluoroprobe (FL-2) O&M Manual Product Description Section 1 The Fluoroprobe FL-2 is an environmental instrument with a newly patented optical sensor designed for long term monitoring and control of dissolved oxygen in remote and harsh environments. The probe is designed to provide years of service without the constant maintenance required by galvanic or polargraphic type probes.
-
Page 4: Section 3 Introduction To Calibration
Controls and Set Points HIGH SET: Turn the rotary switch to HIGH SET and adjust the HIGH SET pot (on the right side of the controller) to the level you select as a cut off point. This adjustment can be made with a small screwdriver. -
Page 5: Air Saturated Water Calibration
Note: If the probe is being air calibrated in a pipe where the end of the pipe is submerged, vent holes must be drilled on both ends of the pipe to allow ambient air to purge the gases, which might give a false air calibration value. Drill holes in pipe just above the water line and at the top of the pipe. -
Page 6: Zero Calibration
2. Zero Calibration: First prepare a container of oxygen depleted water. One of the chemicals that are effective in depleting the 0 in water is Sodium Sulfite (NaSO ). Use one gram/quart of water, mix well and allow up to one hour to deplete the oxygen before using. - Page 11 230 VAC RELAY 3 RELAY 3 MODEL FL-2-SWING OUT WIRING DIAGRAM...
- Page 12 FL2-FLUOROPROBE SPECIFICATIONS Application Temperature Range: Instrument -30°C to +50°C Sensor Material 0°C to +50°C Operation Range: Aqueous Solutions to Supersaturation Response Time: Aqueous Solutions 10 min Gaseous Phases 80 sec Accuracy: Aqueous Solutions – Range 0 to 10 Accuracy Sensor Lifetime: Based solely upon the application environment and the effect on Silicone Rubber.
