Status Indicator Led; Maintenance; Lightning Surge Protection - M-system Mini-M M2XRP2 Instruction Manual

CHANGING I/O TYPE & RANGE
Input type and range, and output type and range can be
programmed on the Configurator Software. Additionally,
when changing the input type, hardware settings are need-
ed as explained below.
■ LEFT SIDE VIEW (with cover removed)
■ DIP SWITCH SETTINGS
(*) Factory setting
Pulse sensing and noise filter settings are invalid for RS-
422 line driver input.
• Input Type
INPUT TYPE SW1-2
Open collector (*) OFF
Voltage pulse OFF
RS-422 line driver pulse
• Pulse Sensing
PULSE SENSING
Capacitor coupled *
2
DC coupled (*)
*2. Frequency range must be 0 – 100 Hz or higher. 0 – 1 kHz
or higher for sinusoidal waveform input. Frequencies
lower than ±10 Hz may be out of accuracy conformance.
• Noise Filter
NOISE FILTER
With
W/O (*)
Be sure to apply the noise filter appropriate for the selected
frequency range as shown in the table below. The accuracy
may not be assured if no filter is applied.
FREQUENCY RANGE
0 – 10 mHz
0 – 100 mHz
0 – 1 Hz
0 – 10 Hz
0 – 100 Hz
0 – 1 kHz
0 – 10 kHz
0 – 100 kHz
• Output Type
OUTPUT TYPE SW4-4
0 – 20 mA DC (*) OFF
-2.5 – 2.5 V DC
-10 – +10 V DC
Input Selector SW
4 3 2
ON OFF ON OFF
1 1
2 2
SW1 SW2 SW3
Output Selector SW
ON OFF
4
3
2
1
SW4
SW1-1 SW2-2 SW2-1
OFF OFF OFF
OFF OFF OFF
ON ON ON ON
SW3-4 SW3-2
OFF OFF
ON ON
SW4-2 SW4-1
ON ON
OFF OFF
NOISE FILTER TYPE
With
With
With
W/O
W/O
W/O
W/O
W/O
SW4-3 SW4-2 SW4-1
ON OFF OFF
ON OFF OFF ON
ON OFF ON OFF
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp

STATUS INDICATOR LED

The M2XRP2 is provided with a status indicator LED which
blinks in different patterns indicating various status of its
CPU.
When it is functioning within normal parameters, the LED
blinks in a regular pattern of ON and OFF. The high levels
mean that the LED is ON, while the low levels means OFF
1
OFF
for as shown in the figure below.
ON
Operating Mode
Normal operation
Zero adjustment
Span adjustment
Programming
Abnormal operation

MAINTENANCE

Regular calibration procedure is explained below:
■ CALIBRATION
Warm up the unit for at least 20 minutes. Apply 0%, 25%,
50%, 75% and 100% input signal. Check that the output
signal for the respective input signal remains within accu-
racy described in the data sheet. When the output is out of
tolerance, recalibrate the unit according to the "ADJUST-
MENT PROCEDURE" explained earlier.

LIGHTNING SURGE PROTECTION

M-System offers a series of lightning surge protector for
protection against induced lightning surges. Please contact
M-System to choose appropriate models.
M2XRP2
LED Blinking Pattern
80 msec.
EM-5059 Rev.8 P. 5 / 5
