- Page 1 Model QW-420 Series Vertical Wall Stand Installation and Operation Manual Manual Part No. DC30-002 Revision B...
- Page 2 This manual is copyrighted and all rights are reserved. No portion of this document may be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine readable form without prior consent in writing from Quantum Medical Imaging, LLC.
- Page 3 Revision History REVISION HISTORY REVISION DATE TYPE OF MODIFICATION 11/7/00 Initial Release. 2/12/01 Added UL Mark LIST OF EFFECTIVE PAGES Page Page Page Number Number Number i - x 1 - 28 Model QW-420 Vertical Wall Stand...
- Page 4 Revision History THIS PAGE INTENTIONALLY LEFT BLANK Model QW-420 Vertical Wall Stand...
-
Page 5: Table Of Contents
Table of Contents Table of Contents Section 1, Introduction Section 2, Specifications Section 3, Assembly & Installation Section 4, Operation Section 5, Maintenance Model QW-420 Vertical Wall Stand... - Page 6 Table of Contents THIS PAGE INTENTIONALLY LEFT BLANK Model QW-420 Vertical Wall Stand...
- Page 7 Safety Notices WARNING Quantum Medical Imaging, LLC disclaims all responsibility from any in- jury resulting from improper application of this equipment. This equipment is sold to be used exclusively under the prescribed direc- tion of a person who is licensed by law to operate equipment of this na- ture.
- Page 8 Safety Notices REGULATORY COMPLIANCE This certified Quantum Medical Imaging, LLC medical device has been designed, manufactured, and calibrated to comply with governing Federal Regulations 21 CFR Subchapter J and the performance standards attendant thereto. Upon installation, all certified products require the filing of Form FD-2579 "Report of Assembly of a Diagnostic X-Ray System"...
- Page 9 15 months from the date of shipment. If the warranty card is not re- turned to QMI, then the warranty shall take effect 12 months from the date of shipment by Quantum Medical Imaging. Buyers should complete one (1) form per system or component, if items are ordered separately.
- Page 10 2) Failure of Buyer/Dealer to provide the proper incoming power required to sup- port the equipment in accordance with the recommendation of QMI. 3) Any modification of product performed by a party other than Quantum Medical Imaging. 4) Combining incompatible products.
- Page 11 B) By making available any necessary repaired or replacement parts or as- semblies. Quantum Medical Imaging shall have the option to furnish either new or ex- change replacement parts or assemblies. All returned parts shall become the property of Quantum Medical Imaging.
- Page 12 Warranty Information THIS PAGE INTENTIONALLY LEFT BLANK Model QW-420 Vertical Wall Stand...
-
Page 13: Section 1, Introduction
Chapter INTRODUCTION... - Page 15 Chapter 1 Introduction OVERVIEW This manual provides information for installing, operating, and maintaining Quan- tum Medical Imaging’s Vertical Wall Stand, Model QW-420 (hereinafter referred to NOTE as the Vertical Wall Stand). It is imperative that all safety procedures described in this manual be strictly adhered to in order to ensure the safety of both patient and The user should user.
- Page 16 Chapter 1 Introduction The Model QW-420 Vertical Wall Stand (with 14” x 36” receptor) con- tains: 1 Front Cover (phenolic) 2 Film Ejection Handle (14” x 36” Cassettes) 3 Cassette Tray Handle 4 Control Handle 5 Compliance Label 6 Vertical Column 7 Receptor Cabinet Figure 2.
-
Page 17: Section 2, Specifications
Chapter SPECIFICATIONS... - Page 19 Chapter 2 Specifications PHYSICAL SPECIFICATIONS The following are physical specifications for the Vertical Wall Stand: Column Height: 84.0 inches (2133.6 mm) • Distance from wall to • front of film cabinet: 12.75 inches (323.9 mm) Distance from front of • column to front of film cabinet: 4.5 inches (114.3 mm)*...
- Page 20 -30.5 to +3048 meters relative • to sea level COMPATIBILITY STATEMENT The Quantum Medical Imaging, LLC Vertical Wall Stand is compatible with all Quantum Medical Imaging, LLC manufactured tables, tube stands and high- voltage x-ray generators. Model QW-420 Vertical Wall Stand...
-
Page 21: Section 3, Assembly & Installation
Chapter ASSEMBLY & INSTALLATION... - Page 23 (the manufacturer is relieved of any responsibility for damage during shipment after unit is picked up by the carrier). Should there be a shortage of parts, notify Quantum Medical Imaging’s Service Department. Model QW-420 Vertical Wall Stand...
- Page 24 Chapter 3 Assembly & Installation ASSEMBLY INSTRUCTIONS To assemble the Vertical Wall Stand, refer to Figures 3 through 5. 1. Rest the bottom end of the Vertical Column on soft support material. 2. Remove the shipping bolt located in the Flat Base Mounting Plate (see Fig- ure 3).
- Page 25 Chapter 3 Assembly & Installation 6. Connect the red and black wires on Control Handle Cable to Terminal Block TB1 terminals 2 and 3, respectively (see Figure 5). 7. Connect red and black wires from a double (or reinforced) insulated 24 VDC power source (must meet construction/performance criteria per UL 2601-1) to Terminal Board TB1 terminals 1 and 2, respectively (see Figure 5).
- Page 26 Chapter 3 Assembly & Installation 12. Align the collimator cross hair lines with the center on Phenolic Front Cover. 13. Secure the Vertical Column to the floor through the Flat Base Mounting Plate using appropriate hardware (must be capable of supporting 100 lbs. pull-load).
- Page 27 Chapter 3 Assembly & Installation 23. Re-install Access Panel. 24. Attach Base Cover to Flat Base Mounting Plate using two (2) 6-32 x 1/4” pan head screws. POST INSTALLATION CHECK All mounting procedures must be approved before, and checked after, installation by the hospital or facility engineering department and a registered, professional, structural engineer.
- Page 28 Chapter 3 Assembly & Installation THIS PAGE INTENTIONALLY LEFT BLANK Model QW-420 Vertical Wall Stand...
-
Page 29: Section 4, Operation
Chapter OPERATION... - Page 31 Chapter 4 Operation Vertical Wall Stand Operation Operation of the Vertical Wall Stand involves moving the Receptor Cabinet (film holder) vertically (i.e., up or down). This is accomplished by depressing the Re- ceptor Cabinet Lock Release Button (see Figure 7), located on the control handle attached to Receptor Cabinet, and then moving the cabinet to the de- sired vertical position.
- Page 32 Chapter 4 Operation CASSETTE TRAY OPERATION The Vertical Wall Frame is equipped with either a Midwest or Poersch cassette tray, depending on the system ordered. The following paragraphs describe the operating instructions for each. Additional information is contained in the cas- sette tray manufacturer’s documentation, which is shipped with the wall frame.
- Page 33 Chapter 4 Operation LOADING CASSETTE TRAY (POERSCH TYPE) To load a film cassette into a “Poersch” type cassette tray, proceed as fol- lows: 1. Pull cassette tray from Receptor Cabinet using tray handle (see Figure 2. Remove shelf from retainer by rotating flange forward. 3.
- Page 34 Chapter 4 Operation THIS PAGE INTENTIONALLY LEFT BLANK Model QW-420 Vertical Wall Stand...
-
Page 35: Section 5, Maintenance
Chapter MAINTENANCE... - Page 37 Chapter 5 Maintenance OVERVIEW The Vertical Wall Stand will function reliably when maintained according to the in- structions provided in this chapter. WARNING! Only properly trained service personnel should se WARNING! Only properly trained service personnel should se WARNING! Only properly trained service personnel should ser- vice or maintain this equipment.
- Page 38 Chapter 5 Maintenance A complete series of inspections and functional checks was conducted at the time of installation to insure proper operation of the system. The following in- spection and adjustment procedures are recommended to maintain the system in its original operating condition. Check for evidence of loose hardware or loose wires.
- Page 39 Figure 8. Model QW-420 Vertical Wall Stand Parts Location Diagram ORDERING INFORMATION To order replacement parts for the Vertical Wall Stand, contact the Service De- partment at: Quantum Medical Imaging, LLC 2905 Veterans Memorial Highway Ronkonkoma, New York 11779 USA Phone: (631) 587-5800...
- Page 40 Chapter 5 Maintenance Figure 9. Model QW-420 Vertical Wall Stand Parts Location Diagram Figure 10. Model QW-420 Vertical Wall Stand Parts Location Diagram Model QW-420 Vertical Wall Stand...
