ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM3029T-7PK
DIFFICULT
Tools Required For Assembly:
Allen Wrench
2 PERSONS RECOMMENDED
Page 1 of 7
(Included)
Rev: 18-05-25
Advertisement
Related Manuals for Furniture of America CM3029T-7PK
Summary of Contents for Furniture of America CM3029T-7PK
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3029T-7PK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 8pcs #1 x 1pc Bolt Ø5/16" x 2-3/8" Table Top #B x 8pcs #2 x 4pcs Lock Washer Ø5/16"...
- Page 4 Align legs (#2) to the holes of the table top (#1), then secure by using bolts (#A) with washers (#B,C). #A x 8pcs #B x 8pcs #C x 8pcs Page 4 of 7...
- Page 5 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 2pcs x 6 #1 x 1pc x 6 Bolt Ø1/4" x 1-5/8" Chair Back #2 x 1pc x 6 #B x 4pcs x 6 Bolt Ø1/4"...
- Page 6 Align seat cushion (#2) to the holes of the chair backs (#1), then secure middle two holes of the seat cushion (#2) by using bolts (#A) with washers (#D,E). #A x 2pcs #D x 2pcs #E x 2pcs Secure corner holes of the seat (#2) to chair back (#1) by using bolts (#C) with washers (#D,E).
- Page 7 Align front legs (#3) to the holes of the seat (#2), then secure by using bolts (#B) with washers (#D,E). #B x 4pcs #D x 4pcs #E x 4pcs ASSEMBLY IS COMPLETED Page 7 of 7...
