Abocom WPG2000 Specifications

802.11g Wireless PCI Card

The WPG2000 is a wireless PCI adapter featuring
the latest IEEE802.11g
deliver incredibly fast data transfer in the 2.4GHz
frequency. The WPG2000
IEEE802.11g standard's
schemes. With 11g, it is backwards compatible with
all the existing 802.11b products already out there.
Better yet, it provides high-speed performance at
54Mbps operation that is essential for today's high-
bandwidth.
The WPG2000 is a powerful 32-bit PCI adapter.
Just insert the WPG2000 PCI Card into an unused
PCI expansion slot in your PC. It installs quickly and
easily through a Windows-Based Utility; then, you
are immediately wirelessly connected to your network.
The WPG2000 can be used in ad-hoc mode to connect directly with other 2.4GHz wireless
computers for peer-to-peer file sharing; or in infrastructure mode to connect with a wireless access
point or router for accessing to the Internet in your office or home network.

FEATURES

Adds 802.11g wireless capabilities to desktop computers, for faster wireless networking available
for home or office
Compliant with 32-bit PCI V2.2 specifications
Backward compatible with existing 802.11b products
Capable of up to 128-Bit WEP Encryption
54 Mbps High-Speed Transfer Rate
Supports Window 98SE/2000/ME/XP
Lower power consumption
Easy to install and configure

SPECIFICATIONS

Standards
Chipset
Host Interface
Antenna
Power Requirement
Operating Frequency
Range
Number of Selectable
Channels
Modulation Technique
Security
Physical Specifications
Supported OS
wireless technology
incorporates
mandatory modulation
IEEE 802.11g Standard Compliant
Intersil Frisbee Chipsets
32-bit PCI V2.2 Specifications
One External Antenna, Upgradeble
Operating Voltage: 3.3V
TX: 460mA (Max), RX: 310mA (Max)
USA: 2.412GHz-2.462GHz
Europe: 2.412 GHz-2.472GHz
Japan: 2.412 GHz-2.483GHz
USA, Canada: 11 channels
Europe: 13 channels
Japan: 14 channels
11g: 11g Orthogonal Frequency Division Multiplexing (64QAM, 16QAM, QPSK, BPSK)
11b: Direct Sequence Spread Spectrum (CCK, DQPSK, DBPSK)
64/128 bit WEP Encryption
Dimension:
134.6mm(L) x 121mm(W)* 22mm(H)
Weight: < 80 g
Windows 98SE/ME/2000/XP
to
the
Doc. No.:062703-02
