REFERENCE OD4.1-4-S10-BRZ-T KIT
Reference 4.1 Landscape Solution, Bronze Textured, Four 4 in. Satellites, One 10 in. Subwoofer
The Crestron®
REFERENCE OD4.1-4-S10-BRZ-T KIT
made by Origin Acoustics provides the full impact of your music
outdoors with tremendous coverage, excellent stereo imaging, and rich,
deep bass.
The 4.1 kit includes four weatherproof 2-way outdoor satellite speakers
and an in-ground subwoofer. The outdoor satellite speakers are
designed to be staked directly into the ground with the supplied ground
stakes.
NOTE: For individual speaker documentation, refer to
OD4-BRZ-T-EACH
Quick Start (Doc. 9033).
In the Box
1
REFERENCE OD4.1-4-S10-BRZ-T KIT



Additional Items
4
Satellite speakers (6511866)
4
Ground stakes
1
In-ground subwoofer (4532740)
12
Wire nuts
landscape solution
Recommended Speaker Wire
Crestron recommends using 12 to 16 gauge multistranded, direct-burial
outdoor speaker wire (not included) for installation, depending on the
overall distance from the amplifier (not included) to the further speaker
connection. Refer to the following chart for recommended wire gauge.
REFERENCE
Distance from Amplifier to furthest speaker
0 - 100 ft (0 - 30 m)
50 – 150 ft (15 - 45 m)
Over 100 ft (30 m)
Quick Start
Installation
Recommended Wire Gauge (AWG)
16
14
12
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OD4.1-4-S10-BRZ-T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Crestron OD4.1-4-S10-BRZ-T

Summary of Contents for Crestron OD4.1-4-S10-BRZ-T

  • Page 1 The 4.1 kit includes four weatherproof 2-way outdoor satellite speakers and an in-ground subwoofer. The outdoor satellite speakers are Crestron recommends using 12 to 16 gauge multistranded, direct-burial designed to be staked directly into the ground with the supplied ground outdoor speaker wire (not included) for installation, depending on the stakes.
  • Page 2 Quick Start REFERENCE OD4.1-4-S10-BRZ-T KIT Reference 4.1 Landscape Solution, Bronze Textured, Four 4 in. Satellites, One 10 in. Subwoofer Landscape Speaker Setup - Satellite Speakers in Straight-line Configuration Figure B Prior to connecting the speaker wire, fully plan out the locations of all satellite speakers and the subwoofer.

  • Page 3: Subwoofer Placement

    Quick Start REFERENCE OD4.1-4-S10-BRZ-T KIT Reference 4.1 Landscape Solution, Bronze Textured, Four 4 in. Satellites, One 10 in. Subwoofer Subwoofer Placement Figure C - Prepare the Site for Subwoofer Installation Select a location for the subwoofer near the middle of the satellite speaker arrangement (see figures A and B).

  • Page 4: Speaker Connections

    Quick Start REFERENCE OD4.1-4-S10-BRZ-T KIT Reference 4.1 Landscape Solution, Bronze Textured, Four 4 in. Satellites, One 10 in. Subwoofer Satellite Speaker Placement  2. Refer to the following application diagrams (see figures D and E) to determine the appropriate wiring configuration. Then, connect the Place the satellite speakers between 8 and 10 feet (2.4 to 3 meters)
  • Page 5 Quick Start REFERENCE OD4.1-4-S10-BRZ-T KIT Reference 4.1 Landscape Solution, Bronze Textured, Four 4 in. Satellites, One 10 in. Subwoofer - Satellite Speakers in a Straight-line Configuration Figure E  4. Secure the three positive (+) leads together (lead from the amplifier, hardwired speaker lead from the first speaker, and lead to the rest of the speakers) using the wire nuts, ensuring that no copper is exposed (see figure F).
  • Page 6 Quick Start REFERENCE OD4.1-4-S10-BRZ-T KIT Reference 4.1 Landscape Solution, Bronze Textured, Four 4 in. Satellites, One 10 in. Subwoofer NOTES:   Make sure that the white (+) and green (-) wires are used for the channel 1 signal path and red (+) and black (-) for  ...
  • Page 7 Quick Start REFERENCE OD4.1-4-S10-BRZ-T KIT Reference 4.1 Landscape Solution, Bronze Textured, Four 4 in. Satellites, One 10 in. Subwoofer  9. Once the wiring is completed, install the speakers as follows:  a. Drive the ground stake (included) into the ground.   For installation in soft soil: The stake can be installed without excavating the soil.

  • Page 8: Additional Information

    Service Providers (CSPs) under a limited nonexclusive, nontransferable Software Development Tools License Agreement. Crestron product operating system software is licensed to Crestron dealers, CSPs, and end-users under a separate End-User License Agreement. Both of these Agreements can be found on the Crestron website at www.crestron.com/legal/software_license_agreement. http://www.crestron.com/model/6512253 The product warranty can be found at www.crestron.com/warranty.
