Live Streaming VBOX Video HD2 Using LiveU Solo HDMI
A VBOX Video HD2 HDMI (RLVBVDHD2-H) connected to a LiveU Solo HDMI (RLACS298) can live stream the video
output directly to Facebook, YouTube and other popular online platforms and CDNs. LiveU Solo HDMI is available to
purchase on the
VBOX Motorsport
Store.
LiveU Solo HDMI Overview
LiveU Solo HDMI is a professional-grade wireless video encoder offering one-touch streaming to Facebook Live and
YouTube, as well as other popular social media networks and online channels. The light and compact Solo is perfectly
suited for any type of mobile use allowing you to stream live video from anywhere.
https://en.racelogic.support//Product_Info/Video_Data_Loggers/VBOX_Video_HD2/Knowledge_Base/
Live_Streaming_VBOX_Video_HD2_Using_LiveU_Solo_HDMI
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for LiveU Solo HDMI
Summary of Contents for LiveU Solo HDMI
- Page 1 Live Streaming VBOX Video HD2 Using LiveU Solo HDMI A VBOX Video HD2 HDMI (RLVBVDHD2-H) connected to a LiveU Solo HDMI (RLACS298) can live stream the video output directly to Facebook, YouTube and other popular online platforms and CDNs. LiveU Solo HDMI is available to...
-
Page 2: Specifications
• Deliver HD live videos to all popular online platforms such as Facebook Live, YouTube and Twitch. • LiveU Solo can incorporate LiveU’s patented video protocol LRT™ (LiveU Reliable Transport), a unique video transmission method. It deploys smart algorithms like adaptive bit rate adjustment and automated error correction to deliver rock-solid live streams with superior video quality. -
Page 3: Optional Accessories
High speed HDMI lead with C-HDMI1 ethernet, 1 m, black Optional Accessories Description Product Code Power Dual Supply Cable (LiveU Solo, HD2) RLACS300 RLCAB158 is also required LiveU Solo power adaptor (30 cm) RLCAB158 Cigar Plug Power Supply for HD2 (2 m) RLCAB158 is... - Page 4 Description Product Code Unterminated Power Supply for HD2 (2 RLCAB014LE m) RLCAB158 is also required Cigar Plug Power Supply for LiveU Solo (2 RLCAB010D m) RLCAB158 is also required Li-ion Battery Pack RLCAB158 is also required RLACS112 https://en.racelogic.support//Product_Info/Video_Data_Loggers/VBOX_Video_HD2/Knowledge_Base/ Live_Streaming_VBOX_Video_HD2_Using_LiveU_Solo_HDMI...
- Page 5 How Does LiveU Solo HDMI Work LiveU Solo HDMI has an HDMI video input and a number of ways to connect to the internet: 2 x Cellular network connections via 4G USB dongles, 1 x Ethernet port for LAN connections and 1 x WiFi connection.
- Page 6 Charging LiveU Solo HDMI • LiveU Solo HDMI contains an internal battery that enables a minimum of two hours of standalone operation when fully charged. LiveU recommend charging the battery for at least 4 hours before first using LiveU Solo HDMI.
- Page 7 Configuring VBOX Video HD2 To output video via the HDMI port, the setting must be enabled within VBOX Video Setup Software or the VBOX Video App. IMPORTANT - HDMI output is only available when frame rate is selected as 30 fps within the Video Settings.
- Page 8 Configuring LiveU Solo HDMI It is important that the LiveU Solo HDMI has the most up to date firmware installed, new firmware upgrades are automatically sent 'over the air' once you have an internet connection. More information on this is available here.
- Page 9 4. Read the Terms and Conditions and tick the box if agreed to. 5. Click on Submit. 6. An email will be sent asking you to verify your account. Note: One Solo Web Portal Account can have up to five LiveU Solo HDMI encoders registered to it. https://en.racelogic.support//Product_Info/Video_Data_Loggers/VBOX_Video_HD2/Knowledge_Base/ Live_Streaming_VBOX_Video_HD2_Using_LiveU_Solo_HDMI...
- Page 10 Registering LiveU Solo HDMI Once you have a LiveU Web Portal Account, it is then necessary for you to register the LiveU Solo HDMI unit following the instructions below: 1. Ensure the USB modems are connected to LiveU Solo HDMI as above.
- Page 11 Note: LiveU Solo HDMI can only be registered to one account. Once registered, the LiveU Solo HDMI unit will be displayed at the top of the Solo Web Portal along with status information, such as whether the unit is online (turned on with an active connection) and remaining battery. It is possible to change the name of the unit by pressing the cog icon above the image of the unit.
- Page 12 (2 x cellular networks, 1 x WiFi, 1 x Ethernet) to create a single, strong upstream line. By transmitting the video data over multiple connections, LiveU Solo ensures reliable live streaming even if one network degrades or drops out completely. LRT™ is not included as standard, it is an additional subscription cost, with Monthly and Yearly subscription options.
- Page 13 Streaming Destination Once you have registered the LiveU Solo HDMI unit, it is then necessary for you to setup a streaming destination for live video. With the Solo Web Portal open click on Select New Destination from within the Destination tile.
- Page 14 Web Portal. In other cases, you may need to navigate to the destination’s web user interface and find a token or key you paste into LiveU Solo to link your Solo account to the destination site. Streaming Destinations Other destinations require a few additional steps to...
- Page 15 (C-HDMI1) in to the respective HDMI ports. Once both units are powered, LiveU Solo HDMI is connected to the internet and video is being received from VBOX Video HD2 HDMI, a preview will be displayed on the LCD display screen. The Solo Web Portal Status tile will also display the video input type, which in the case of VBOX Video HD2 HDMI is 1080p30.
- Page 16 LiveU Solo Web Portal or briefly press the Power button on the front of the unit. To turn LiveU Solo HDMI off, press and hold the Power button on the front of the unit for 5 seconds. https://en.racelogic.support//Product_Info/Video_Data_Loggers/VBOX_Video_HD2/Knowledge_Base/...
