TEXONIC RX 1200 Owner's Manual

6 source/6 z0ne audio distribution amplifier (2 x streamer inside)
Hide thumbs

Advertisement

Quick Links

Download this manual
6 SOURCE/6 Z0NE
RX 1200
Audio Distribution Amplifier
(2 x Streamer Inside)
RX1200
SOURCE INPUTS
Link
3
Link
4
OWNERS MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the RX 1200 and is the answer not in the manual?

Questions and answers

Related Manuals for TEXONIC RX 1200

Summary of Contents for TEXONIC RX 1200

  • Page 1 6 SOURCE/6 Z0NE RX 1200 Audio Distribution Amplifier (2 x Streamer Inside) RX1200 SOURCE INPUTS Link Link OWNERS MANUAL...
  • Page 3 IR remote controller or APP. Simply connecting the RX 1200 to the local Ethernet network, it let you access a wide variety of music from the Built-in streaming services or stored on the Smartphones.

  • Page 4: Specification

    SPECIFICATION Output Power: 25W x 2 per zone (at 8Ω) Output Power: 50W x 2 per zone (at 4Ω) Output Power: 100W per zone (Bridged at 8Ω) S/N: >85dB A WTD THD: <0.1% Frequency Response: 20Hz-20KHz Input Impedance: >47 K Ohm Input Sensitivity: 250 mV Protection Function:...

  • Page 5: Rear Panel

    1. Power ON/OFF/ STANDBY 2. Standby/Zone ON LED Depress the power button to turn These six LEDs illuminate to indicate the on the system. Press it again to status of each zone. release the latch and power the Blue: In Standby mode.White: In Activate unit off.
  • Page 6 Set the unit ID when connecting multi 12.ETHERNET/RS232 SWITCH ETHERNET: When the amplifier connects to Controller systems Ethernet. 15.KEYPAD RS232: When the amplifier control by PC or RJ-45 jack Connects to the keypad hub Control Device via RS-232. for 6 keypads. 13.AGC 16.VOLTAGE SELECT Automatic Gain Control, brings low level up...
  • Page 8 RX 1200 RX 1200 3.5mm Stereo...
  • Page 9 The RX 1200 can work with speakers that are 4-8 Ohm. There are 9 two modes that can be set for different setups: Stereo or Bridge. An 8 Ohm speaker can only be used when in Bridge mode. To choose between modes,...
  • Page 10 comes with 6 POE enabled keypads. This allows for source MAP-1200US control from each specific zone as well as IR routing to the appropriate source devices once selected. The also comes with a hub that allows for all MAP-1200US 6-keypads to be connected to the amp via Cat5e/6. ZONE-1 ZONE-2 ZONE-3...
  • Page 11 FRONT BACK 12VDC out to trigger external amplifier RX 1200...
  • Page 13 When being used with keypads, the RX 1200 can receive IR signals from each zone, and routed back through the Cat5e/6 and Keypad up to the Amplifier to control the selected source. For example, if Source 2-DVD is selected in Zone 1, the user will be able to control the DVD player to power the device on/off, change settings ect.
  • Page 14 Master SLAVE 1 SLAVE 2...
  • Page 15 ETHERNET CONNECTION Network TV Router EXPANSION VOLTAGE SELECT Reset ETHERNET INPUT 115V 230V AC: 115V ~ 60Hz, 1250W FUSE: T10AL 250V AC: 230V-240V ~ 50Hz, 1250W FUSE: T5AL 250V RS232 EXT.MUTE KEYPADS There are two RJ-45 jacks on the rear panel of this amplifier for the connection to Ethernet.

  • Page 16: Connection Diagram

    CONNECTION DIAGRAM Stereo Amplifier Powered Subwoofer Network TV MAP-1200HD Router EXPANSION SOURCE INPUTS PRE-AMP OUTPUT PRE-AMP OUTPUT PRE-AMP OUTPUT PRE-AMP OUTPUT PRE-AMP OUTPUT PRE-AMP OUTPUT VOLTAGE SELECT Reset ETHERNET OUTPUT INPUT 115V 230V AC: 115V ~ 60Hz, 1250W FUSE: T10AL 250V AC: 230V-240V ~ 50Hz, 1250W FUSE: T5AL 250V YES NO YES NO...
  • Page 17 Please switch to MASTER and ETHERNET. Note. Please do not press “Reset” button. Note. Please do not connect the Ethernet port of RX 1200 to the computer directly. 1.Open the IE web browser of PC, log in to the WEB configuration page of local...
  • Page 18 2. Using “Advanced_IP_Scanner” software to find the IP address. Please visit www.advanced-ip-scanner.com for free download. Then enter the IP address of RX 1200 to the IE browser (shown as below), ensure the Serial Configure is 9600,n,8,1. After finishing this step, MAP-1200US could be...
  • Page 19 Download free software “PuTTY” Tool from the internet to control the device. Operation diagram as below:...
  • Page 20 Click Telnet, enter the IP address of RX 1200 and port: 8080. Click Open. When the IP address connected, the operation diagram shows as below: Key in the command code to control RX 1200. For the detail of command codes, please find the RS-232 command codes in this...
  • Page 21 RS-232 communication with third party automation systems. All keypad and remote control operations can be controlled via RS-232 in addition to system expansion up to 18 zones or 3 RX 1200 units linked together using the included 18 pin expansion cable.
  • Page 22 Note: To find the information for the COM port, please open the device manager of the computer, shown as below: When the IP address connected, the operation diagram shows as below: Key in the command code to control RX 1200...
  • Page 23 RX 1200 RS-232 CONTROL CODES (Baud Rate: 9600,8,N,1 , DB9 Connector Pin out, Tx, Rx, GND) 'CR':Carriage Return (0x0D) Not case sensitive Control Command Structure <xxPPuu'CR' Reply Control Command Structure >xxPPuu'CR' xx: Represent control command code 10 :All zones of host computer 1...
  • Page 24 30 :All Zones of host computer 3 11 :Zone1 of host computer1 12 :Zone2 of host computer1 13 : Zone3 of host computer1 21 : Zone1 of host computer2 22 : Zone2 of host computer2 23 : Zone3 of host computer2 ....
  • Page 25 BL:Balance Control CH:Source Control LS: The connection status of line control Reply command: >xxPPuu'CR' Enter1<********'CR' Change Source 1 display name;********It must be 8 effective ASCII code Enter2<********'CR' Change Source 2 display name Enter 3<********'CR' Change Source 3 display name Enter 4<********'CR' Change Source 4 display name Enter 5<********'CR' Change Source 5 display name Enter 6<********'CR' Change Source 6 display name Enter M<********'CR' Change display name of connect control when it starts...
  • Page 26 EXAMPLES OF RS-232 COMMAND CODE All Zone ON <10PR01 Zone 1 ON <11PR01 All Zone OFF <10PR00 <21PR00 Salve 1 / Zone 1 OFF All Zone Mute ON <10MU01 <16MU01 Zone 6 Mute ON All Zone Mute OFF <10MU00 <35MU00 Salve 2 / Zone 5 Mute OFF All Zone Source 01 <10CH01...
  • Page 27 INQUIRY COMMAND STRUCTURE Symbol Zone Master、Salve 1、Salve 2 1、2、3 Inquiry Master All Zone Status Inquiry Slave1 All Zone Status Inquiry Slave2 All Zone Status REPLY COMMAND >xxaabbccddeeffgghhiijj xx: Unit / Zone >1100000000200707100100 aa: PA IN Status bb: Power Status cc: Mute Status dd: DT Status ee: Volume Status ff: Treble Status...
  • Page 28 1. The control APP is available for Apple iPhone/iPad and Android smart phone/Pad, 2. Please search “MRX 1200” on Google Play / App Store to download. 3. Download and install the APP Note. This APP is applied to TEXONIC controller and Multi-Room amplifiers...
  • Page 29 APP QUICK START – FUNCTION INSTRUCTION 1. Output Zone Selection (Press and hold the button to change the zone name) 2. Input Source Selection Press and select the input source. The name of input source could be changed. 3. Treble/Bass/Balance 4.
  • Page 30 APP QUICK START – SETTINGS AND CONNECTION 1. Mobile phone IP address When the smart phone or Pad is connected to local network, the IP will automatically show on this area. 2. AUTO Press AUTO to search the device IP. 3.
