- Page 1 MULTI CHANNEL DX850/1250 POWER AMPLIFIER DX1250 ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 5 ZONE 6 ZONE 7 ZONE 8 DIGITAL POWER AMPLIFIER POWER OWNERS MANUAL...
-
Page 3: Thermal Protection
INTRODUCTION The TEXONIC DX series multichannel power amplifiers are ideal for use in adding additional power in distributed audio systems or combining with the home theater applications. The DX850 provides 8 channels, DX1250 provides 12 channels of digital amplifications. All models... -
Page 4: Front Panel
FRONT PANEL DX1250 ZONE 1 ZONE 2 ZONE 3 ZONE 4 ZONE 5 ZONE 6 ZONE 7 ZONE 8 DIGITAL POWER AMPLIFIER POWER 1. Power/Standby LED 2. Zone LED This LED lights red when any zone is active or Blue: the corresponding zone is powered on. the amplifier is in standby mode. - Page 5 220-240V/T2.5A, 250V DX1250: 100-120V/T8A, 250V 220-240V/T4A, 250V Dimensions: DX850: 16.81”W x 3.46” H x 16.14”D (42.7 x 8.8 x 41.0 cm) DX1250: 16.81”W x 3.46” H x 16.14”D (42.7 x 8.8 x 41.0 cm) Weight: DX850: 8.6Kg (19lbs.) DX1250: 9.3Kg (20.5lbs.)
-
Page 6: System Configuration
Bridged mode. When DX1250 or DX850 is working as a home theater amplifier, the amplifier could support up to a 7.1 or 5.1 surround system, and recommend using the Bridged mode to have the higher outputs. - Page 7 Bridged Mode When the amplifier is in Bridged mode operation, a single channel (the left) is used to provide a higher power mono output. Use one channel pair to amplify the left channel by connecting the left audio signal to the L input of a channel pair, setting the Stereo/Bridge switch to "Bridge" and connecting the speaker as indicated below.
