Assembly
1
Attaching the side plate and the tray support bar to the top plate
Attach the side plate (B) to the top plate (A) using M6x30 combination bolts (BB).
Attach the tray support bar (D) to the top plate (A) using M6x15 combination bolts (CC).
NOTE : Loosely tighten all bolts using the hex wrench (DD).
A
B
BB
CC
CC
D
5
HOMEDEPOT.COM/HOMEDECORATORS
Please contact
1-800-998-7021
for further assistance
