- Page 1 by Thor’s Drone World User’s Manual...
- Page 2 Congratulations on your new The New & Improved Tablet holder for DJI Mavic AIR 2(s) / Mini 2 / Mavic 3 PRO...
- Page 3 Content: Aluminum base Star knob thumbscrew Universal clamp (¼” -20 x ½ ”) Compatible with smart phones and up to 12.9” tablets (expanding clip range Hex Key /Allen Key 65mm - 230mm)
-
Page 4: How To Assemble
How to assemble: Remove the wing knob thumbscrew located on the back of the aluminum base... - Page 5 Main aluminum base Utility mount Wing knob thumbscrew Neck (M5 x 20mm) *Note: The aluminum base has pre-installed anti-slip pad to protect the RC from any scratches and keep it secure in place.
- Page 6 Prepare the RC by extracting the antenna all the way out...
- Page 7 Gently lower the RC into the bay of the base with a slight inclination. Aligning the RC center to the mount...
- Page 8 Make sure the RC is aligned and centered properly...
- Page 9 Reconnect the neck of the aluminum base between the antenna bars back to the main body.
- Page 11 Finish screwing back the wing knob thumbscrew in place The RC is now securely mounted to the LifThor Baldur2 holder...
- Page 12 Insert the star knob thumbscrew from below the utility mount through the small round hole.
- Page 13 If needed you can loosen up the utility mount using the hex key provided to adjust its angle.
- Page 14 Screw the universal clamp in place...
- Page 15 The NEW universal clamp has two mechanisms to ensure your tablet sit secure and in place. Ratchet part to→ The first mechanism is adjust the height the ratchet part, it can be extended in 6 fixed Release steps (3 on the top / 3 button on the bottom) to adjust to the size of your...
- Page 16 Place the phone / tablet in landscape mode by pulling the spring mechanism upwards and release it to secure the device in place. * It’s the spring-loaded part that will hold your device in place ! Spring mechanism...
- Page 17 Compatible with most smart phones and tablets up to 12.9” Minimum expanding 6.5cm – Maximum expanding 23 cm...
- Page 18 Alternative setups: Integrated tripod mounting point located underneath the aluminum base...
- Page 19 *StrapThor Pro – Body Tripod sold separately...
- Page 20 *StrapThor Pro Lanyard sold separately / or included in combo kit...
- Page 21 *Tripltek 7” tripod bracket sold separately...
