Buckleys BathyCorrometer Pro Installation Manual

Hide thumbs Also See for BathyCorrometer Pro:

Advertisement

Quick Links

Download this manual
BathyCorrometer Pro' Upgrade Kit
Installation manual
Click on a title below to go to that section:
3. Disassembly
1. Description
2. Preparation
4. Reassembly
5. Repairs & test certificate production
Or press 'Esc' on your keyboard to close this manual.
V 01/11/18
HOME
Description
Preparation
Disassembly
Reassembly
Repairs & test certificate production

Advertisement

loading
Need help?

Need help?

Do you have a question about the BathyCorrometer Pro and is the answer not in the manual?

Questions and answers

Related Manuals for Buckleys BathyCorrometer Pro

Summary of Contents for Buckleys BathyCorrometer Pro

  • Page 1 BathyCorrometer Pro’ Upgrade Kit Installation manual Click on a title below to go to that section: 3. Disassembly 1. Description 2. Preparation 4. Reassembly 5. Repairs & test certificate production Or press ‘Esc’ on your keyboard to close this manual.
  • Page 2 BathyCorrometer ® M k V t o P R O ’ U P G R A D E M A N U A L Description The BathyCorrometer ® Pro’ Upgrade Kit brings the specification of older MkV units up to that of the current model with improved display clarity, the correct negative potential reading and revised battery and electronics systems.
  • Page 3 11. Tamper-evident seal/paint 24. Pressure tank capable of 600psi dealer to source dealer to source 12. Crimp tool JST WC-240 (Farnell 3617270) Items with part numbers may be purchased from Buckleys HOME Description Preparation Disassembly Reassembly Repairs & test certificate production...
  • Page 4 BathyCorrometer ® M k V t o P R O ’ U P G R A D E M A N U A L Disassembly Locking Ring Removal Ensure the area around the locking ring and lens are clean and free from any grit or other debris. Attention should be given to ensuring the exposed threads are clean as any debris could damage the threads;...
  • Page 5 BathyCorrometer ® M k V t o P R O ’ U P G R A D E M A N U A L Disassembly Lens Removal Once the locking ring has been removed as described above, the lens can be removed with the aid of a small suction-puller cup.
  • Page 6 BathyCorrometer ® M k V t o P R O ’ U P G R A D E M A N U A L Disassembly Removing the BCM MkV Electronics Remove the two retaining screws at the top and bottom of the electronics assembly and withdraw the electronics assembly from the BathyCorrometer ®...
  • Page 7 BathyCorrometer ® M k V t o P R O ’ U P G R A D E M A N U A L Disassembly Removing the BCM MkV Electronics Remove the white multi-plug by cutting the wires as close to the plug as possible. Cut wires as close to multiplug as possible HOME Description...
  • Page 8 See the illustration for the correct multi-plug wiring order. BathyCorrometer Pro’ wiring harness IMPORTANT: incorrect wiring of the 6-way multiplug is likely to cause irreparable damage to the BathyCorrometer Pro’s Electronics connection plug electronics assembly. Electronics connection socket Attach the self-adhesive battery isolation disc (part no.
  • Page 9 BathyCorrometer ® M k V t o P R O ’ U P G R A D E M A N U A L Reassembly Electronics installation IMPORTANT: Before installing electronics, take a note of the new electronics’ serial number for certification purposes. •...
  • Page 10 NOTE: We would strongly advise to undertake a full calibration of the BathyCorrometer at this stage to ensure the half-cell is in serviceable condition and that all watertight seals are effective. Refer to the BathyCorrometer Pro’ Service, Diagnostics and Repair Manual for full details. Pressure test •...
  • Page 11 For details of all replacement parts available, please refer to the BathyCorrometer ® Pro’ Parts List within the BathyCorrometer Pro’ Service, Diagnostics and Repair Manual. More information For more information regarding any of the procedures described in this manual, please refer to the BathyCorrometer Pro’...
  • Page 12 Follow the steps below in order to issue Calibration Certificte for the BatheyCorrometer Pro’. 1. Go to www.buckleysinternational.com and click on SIGN-IN button to log-in to your 2. Click on ‘My Customers’. Buckleys account with your username and password. HOME Description...
  • Page 13 BathyCorrometer ® M k V t o P R O ’ U P G R A D E M A N U A L Repairs & test certificate production 3. If your customer is not on our system, click on ‘Register A New Customer’, complete the 4.
  • Page 14 5. Once you have registered your customer, or if your customer is already listed, click on the ‘New Registration’ button next to their name. 6. In the ‘Product’ field, select the model and kit variant of BathyCorrometer Pro’ *. Click in the field below ‘What is the product’s serial number?’ and enter the product’s unique serial number.
  • Page 15 Please double-check the details and click ‘Create and Download Certificate’. The process is now complete. The details of the work carried out have been passed to Buckleys for our records and you will now have the option to print a copy of the certificate or download a PDF.
