Mountain MTN5505 Operating Instructions

Operating Instructions:
IMPORTANT: Sometimes during shipment and handing, air gets
into the hydraulic system, causing poor lifting performance. Before
initial operation, purge any air from the system by fully opening
release (Turn handle knob (#80) counter-clockwise). Then, while
holding the saddle down, pump pedal (#63) rapidly several times.
RAISING JACK:
1. Turn handle knob (#80) clockwise until resistance is felt to close
release valve. Do not over tighten.
2. Place jack directly under object to be lifted. Depress the pedal
(#63) repeatedly until the saddle contacts the lift point. Make
sure saddle lifts weight firmly and centrally. Check positioning
under slight load to confirm jack or load will not slip.
3. Raise jack by pumping handle until desired height is reached.
After lifting, secure load by appropriate means. Do NOT use
service jack as the only means of support.
LOWERING JACK
1. Slowly turn handle knob (#80) counter-clockwise. Speed of
descent is controlled by amount release valve is turned.
Maintenance:
Checking hydraulic oil level
1. Open release valve (turn handle knob (#80) counter-clockwise)
and push ram to its lowest position.
2. Remove filler plug (#36).
3. Fill the reservoir with clean hydraulic jack oil. Do not use
hydraulic brake oil or hydraulic brake fluid.
4. Reinstall filler plug.
Lubrication:
1. Add lubricating oil to all moving parts as needed.
MTN5505
MTN5505
5 Ton Heavy Duty
Service Jack
SPECIFICATIONS:
Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Ton
Low Height . . . . . . . . . . . . . . . . . . . . . . . . . . . 6"
Raised Height . . . . . . . . . . . . . . . . . . . . . 22-1/4"
Length . . . . . . . . . . . . . . . . . . . . . . . . . . 55-7/8"
Chassis Width . . . . . . . . . . . . . . . . . . . . . 6-3/4"
Handle Length . . . . . . . . . . . . . . . . . . . . 39-5/8"
Saddle Diameter . . . . . . . . . . . . . . . . . . . . 5-1/4"
Front Wheel . . . . . . . . . . . . . . . 4-5/16" x 1-3/4"
Rear Caster . . . . . . . . . . . . . . . 2-3/4" x 1-3/16"
Shipping Weight . . . . . . . . . . . . . . . . . . . 234 Lbs.
1. THIS IS A LIFTING DEVICE ONLY. DO NOT MOVE OR DOLLY THE
VEHICLE WHILE ON THE JACK.
2. POSITION THIS JACK TO ONLY LIFT ON THE AREAS OF THE VEHICLE
AS SPECIFIED BY THE VEHICLE MANUFACTURER.
3. AFTER LIFTING THE VEHICLE, ALWAYS SUPPORT THE LOAD WITH
APPROPRIATELY RATED VEHICLE SUPPORT STANDS BEFORE WORKING
ON THE VEHICLE.
4. DO NOT OVERLOAD THIS JACK BEYOND ITS RATED CAPACITY.
OVERLOADING CAN CAUSE DAMAGE TO OR FAILURE OF THE JACK.
5. THIS JACK IS DESIGNED ONLY FOR USE ON HARD LEVEL SURFACES
CAPABLE OF SUSTAINING THE LOAD. USE ON OTHER THAN HARD
LEVEL SURFACES CAN RESULT IN JACK INSTABILITY AND POSSIBLE LOSS
OF LOAD.
6. CENTER LOAD ON JACK SADDLE BEFORE LIFTING VEHICLE.
OFF-CENTER LOADS AND LOADS LIFTED WHEN THE JACK IS NOT LEVEL
CAN CAUSE LOSS OF LOAD OR DAMAGE TO THE JACK.
7. STUDY, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS IN THIS
MANUAL BEFORE OPERATING THE JACK.
8. FAILURE TO HEED THESE WARNINGS MAY RESULT IN LOSS OF LOAD,
DAMAGE TO THE JACK AND/OR JACK FAILURE RESULTING IN
PERSONAL INJURY OR PROPERTY DAMAGE.
1 rev. 02/10/03
