Mountain MTN2156 Operating Manual

ThiS operaTiNg MaNuaL coNTaiNS
iMporTaNT SafeTy iNforMaTioN.
read carefuLLy aNd uNderSTaNd
aLL iNforMaTioN Before operaTiNg
ThiS deVice. SaVe ThiS MaNuaL for
fuTure uSe.

Owner/User respOnsibility

The owner and/or user must have an understanding of
the man u fac tur er's operating in struc tions and warn ings be fore
using this transmission jack. Personnel involved in
the use and op er a tion of equip ment shall be careful,
com pe tent, trained, and qual i fied in the safe operation
of the equip ment and its proper use when servicing motor
vehicles and their com po nents. Warning in for ma tion should
be em pha sized and un der stood. If the operator is not fluent in
English, the man u fac tur er's in struc tions and warn ings shall be
read to and dis cussed with the op er a tor in the op er a tor's native
language by the pur chas er/own er, mak ing sure the op er a tor
com pre hends its con tents.
Owner and/or user must study and maintain for future
ref er ence the manufacturer's instructions. Owner and/or
user is responsible for keeping all warning labels and
instruction manuals legible and intact. Replacement labels
and literature are available from the manufacturer.

speCiFiCAtiOns

Low Height ........................................... 35"
Raised Height ....................................... 75"
Saddle Tilt:
Forward ............................................... 45°
Backward ............................................. 28°
Side to Side .......................................... 10° - 23°
Base Size.............................................. 35" x 31.5"
Saddle Plate Size .................................. 15.5" x 15.5"
Shipping Weight ................................... 181 Lbs
MTN2156
MTN2156
1000
LBS.
CAPACITY
• Read, study, undeRstand and follow all instRuctions
befoRe opeRating. • inspect befoRe each use. do not use
if damaged, alteRed, modified, in pooR condition,
oR has loose oR missing haRdwaRe oR components.
take coRRectiVe action befoRe using the Jack. • do
not use Jack beyond its Rated capacity. • use only
on haRd, leVel, clean and dRy suRface capable of
suppoRting the load. • this Jack was designed foR
lifting tRansmissions only. • do not attempt any
woRk until Vehicle is stabiliZed by undeR hoist
stands. • use this Jack only with adapteRs and load
RestRaints pRoVided. use of this Jack is limited to the
RemoVal, installation, and tRanspoRtation (in the
loweRed position) of tRansmissions and tRansfeR
cases. • weaR eye pRotection that meets ansi Z87.1
and osha standaRds. • do not lift oR suppoRt the
Vehicle with this Jack. • secuRe the load to the
Jack. only attachments and/oR adapteRs supplied
by the manufactuReR shall be used. • always loweR
load slowly. • make suRe the gRound, woRk aRea,
and cleaRance undeR the Vehicle aRe fRee fRom
obstRuctions oR any hindRances that would pReVent
easy maneuVeRability of the Jack and tRansmission
undeR the Vehicle. • failuRe to heed these maRkings
may Result in seRious oR fatal peRsonal inJuRy and/
oR pRopeRty damage.
1
TWO STAGE
TRANSMISSION
JACK
WARNING
12/24/08
