Mountain MTN5520 Manual

Features:

• Chrome Plated Lift Ram
• Self-Retracting Ram Springs for Fast Ram Retraction
• Push Valve Lever for Fast Air Control
• 3 Position Lock Lever
• Safety Overload Valve
• Large Diameter Wheels for Ease of Operation

Owner/User Responsibility:

The owner and/or user must have a thorough understanding of the
manufacturer's operating instructions and warnings before using
the service jack. Personnel involved in the use and operation of
equipment shall be careful, competent, trained, and qualified in the
safe operation of the equipment and its proper use when servicing
motor vehicles and their components. Warning information should
be emphasized and understood. If the operator is not fluent in
English, the manufacturer's instructions and warnings shall be read
to and discussed with the operator in the operator's native language
by the purchaser/owner, making sure that the operator
comprehends its contents.
Owner and/or user must study and maintain for future reference
the manufacturer's instructions and pertinent warning information.
Owner and/or user is responsible for keeping all warning labels
and instruction manuals legible and intact. Replacement labels and
literature are available from the manufacturer.
FOR YOUR SAFETY & TO PREVENT INJURY:
ALWAYS
Support Vehicle with
Appropriately Rated
Support Stands!
Use Service Jack
Purposes
for Lifting
ONLY!
MTN5520
Model 1006A
6 TON
CAPACITY
RATCHETING
JACK STAND
Model 1006A
6 TON
CAPACITY
RATCHETING
JACK STAND
1
MTN5520
22 Ton Air/Hydraulic Jack

SPECIFICATIONS:

Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Tons
Min. Saddle Height . . . . . . . . . . . . . . . . . . . . . . . 9"
Max. Saddle Height . . . . . . . . . . . . . . . . . . . . . .17"
Stroke . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3/4"
Handle Length . . . . . . . . . . . . . . . . . . . . . . . . . 49"
Wheel Diameter . . . . . . . . . . . . . . . . . . . . . . . . . .8"
Dimensions . . . . . . . . . . . . . . .21"L x 13"W x 56"H
Air Pressure . . . . . . . . . . . . . . . . . . . . . . . . . .90 psi
THIS OPERATING MANUAL CONTAINS
IMPORTANT SAFETY INFORMATION.
READ CAREFULLY AND UNDERSTAND
A L L I N F O R M AT I O N
OPERATING
MANUAL FOR FUTURE USE.
USE ONLY ON HARD LEVEL SURFACES.
DO NOT GET UNDER A VEHICLE THAT IS ONLY SUPPORTED BY A
TROLLEY/SERVICE JACK–USE VEHICLE SUPPORT STANDS.
THIS IS A LIFTING DEVICE ONLY. DO NOT MOVE OR DOLLY THE
VEHICLE WHILE ON THE JACK. IMMEDIATELY AFTER LIFTING,
SUPPORT THE VEHICLE WITH APPROPRIATE MEANS.
DO NOT OVERLOAD. OVERLOADING CAN CAUSE DAMAGE TO OR
FAILURE OF THE JACK.
LIFT ONLY ON AREAS OF THE VEHICLE AS SPECIFIED BY THE
VEHICLE MANUFACTURER.
CENTER LOAD ON SADDLE PRIOR TO LIFTING. OFF-CENTER LOADS
MAY CAUSE DAMAGE TO JACK, LOSS OF LOAD, PROPERTY
DAMAGE, PERSONAL OR FATAL INJURY.
NO ALTERATIONS TO THE JACK SHALL BE MADE.
READ, STUDY AND UNDERSTAND THE OPERATING MANUAL
PACKED WITH THIS JACK BEFORE OPERATING.
FAILURE TO HEED THESE WARNINGS MAY RESULT IN LOSS OF
LOAD, DAMAGE TO JACK, AND/OR FAILURE RESULTING IN
PROPERTY DAMAGE, PERSONAL OR FATAL INJURY.
B E F O R E
TOOL. SAVE THIS
rev. 02/04/03
