Output Module (See drawing PC409 later in manual)
The ZMR-80 OUTPUT PCB drawing shows the position of the Stereo or Mono selection.
Page ID selection is factory set.
At the rear of the module is screwdriver adjustable two band EQ for each output (Zone).
Remote Paging Microphone
The remote paging microphone unit connects to the Page PSU module via the RJ45
connection.
The microphone level is adjustable via a recessed adjustment on the back of the Page PSU
module, the position is indicated by the module legend.
Lime Technologies
http://limetechnologies.co.uk
Tel: 08712 233127
