Summary of Contents for Formula Sound ZMR 80
- Page 1 ZMR 80 STEREO MODULAR ZONER USERS MANUAL Lime Technologies http://limetechnologies.co.uk Tel: 08712 233127...
- Page 2 ZMR80 Stereo Modular Zoner Mixer Introduction The modular construction of the ZMR80 allows it to be tailored to the requirements of a wide range of different venues with a choice of 2 to 8 inputs, 2 to 12 outputs, paging options and optional remote panels.
- Page 3 Output Module (See drawing PC409 later in manual) An output module will carry two stereo (or mono) outputs which may be balanced or unbalanced, you may have up to 6 output modules to provide up to 12 Zones. There is the ability to connect a remote panel for each Zone, the remote panel provides input select and volume control.
- Page 4 Configuration of internal options PSU Module The ZMR-80 PSU PCB drawing shows the position of the ground lift select. This will remove the mains ground from 0V. Removing mains earth is generally not recommend unless there is a good technical reason for it. Also shown is the position of the Phantom power select for the priority input (adjacent is a pot which adjusts the priority input level if required).
- Page 5 Output Module (See drawing PC409 later in manual) The ZMR-80 OUTPUT PCB drawing shows the position of the Stereo or Mono selection. Page ID selection is factory set. At the rear of the module is screwdriver adjustable two band EQ for each output (Zone). Remote Paging Microphone The remote paging microphone unit connects to the Page PSU module via the RJ45 connection.
- Page 9 Front and Rear panel anodised aluminium with ident labels, extruded aluminium chassis and black plastic coated steel casing strips. Dimensions 19" rack mounting. 4RU Width 482mm (19") Depth 210mm (8.25") Height 180mm (7.0") Formula Sound reserve the right to alter the specification without notice.
-
Page 10: Certificate Of Conformity
FORMULA SOUND LIMITED UNIT 23; STADIUM BUSINESS CENTRE; NORTH END ROAD; WEMBLEY; MIDDLESEX; HA9 0AT TELEPHONE +44 (0)208-900-0947 FAX +44 (0)208-903-8657 www.formula-sound.co.uk email info@formula-sound.co.uk E.U. CERTIFICATE OF CONFORMITY We declare that the products listed conform to the following directives and standards...
