- Page 1 FF- 4.2L FIXED FORMAT DJ MIXER USERS MANUAL Formula Sound Direct https://formulasounddirect.com...
- Page 2 FF – 4.2 INTRODUCTION The features and layout of the FF-4.2 were determined in collaboration with leading loudspeaker manufacturers Funktion One. The FF-4.2 has 4 channels; each channel has two inputs selectable by a push switch. There is also a fifth input which is the console microphone input. The FF4.2L has linear faders and the FF4.2R has rotary, both versions can have internal or external power supply, external power supply versions are denoted by a suffix “P”.
-
Page 3: Mechanical And Power Supply
Mechanical and Power Supply Dimensions (Excluding. Knobs & connectors): Width 342mm (13.5") Height 355.3mm (14"-8RU) Depth 110mm (4.33"). Power Supply The internal power supply version has a fully regulated power supply that is designed to operate on 220-240Vac or 110-120Vac. Voltage is factory set. The external power supply version has a fully regulated power supply (designated PSU 6) in a separate case, connecting to the mixer by a 6 bin circular connector. -
Page 4: Input Channels
Input Channels All 4 channels have 2 inputs; the required input is selected on an input select switch at the top of the channel. There is also a GAIN control on each channel to set the maximum level and a linear channel fader to control the level sent to the output. - Page 5 The stereo balanced line input may be strapped for unbalanced operation. Channel 1 has a compressor selected by a switch, the compressor operates on both microphone and line inputs. The compressor is factory set for a threshold of 0dB, a threshold LED between the COMP and AUX 2 switch indicates when the compression threshold is reached.
-
Page 6: Output Section
Channels 2 – 4 have 2 switches that allow each channel to be assigned to a side of the cross fader, XFA assigns the channel to the left and XFB assigns the channel to the right of the cross fader. If both are pressed then XFA takes priority. Output Section Console microphone The output section includes the 5... - Page 7 There is also an insert in the master output stage on a pair of ¼” jack sockets, the insert is enabled by a switch marked INSERT. Note the send path is always active, the insert switch bringing in the return path. Booth output The booth output is on a pair of balanced XLR connectors;...
- Page 8 This may be used to interface to a fire alarm, if the alarm has a set of isolated contacts that close on alarm then these may be used directly, otherwise an isolating interface relay will be required. Formula Sound Direct https://formulasounddirect.com...
- Page 9 FORMULA SOUND LIMITED UNIT 23; STADIUM BUSINESS CENTRE; NORTH END ROAD; WEMBLEY; MIDDLESEX; HA9 0AT TELEPHONE +44 (0)208-900-0947 FAX +44 (0)208-903-8657 www.formula-sound.co.uk email info@formula-sound.co.uk E.U. CERTIFICATE OF CONFORMITY We declare that the products listed conform to the following directives and standards...
