  • Page 1 Instruction Manual Small Screen TV Starter Kit LBRKIT12...
  • Page 3 CUSTOMER HELPLINE (UK Customers Only) 0844 800 3456 MAX TV LOAD 10”- 32” 22 kg • Recommended for most 10”-32” TV screen sizes • VESA Compliance: up to 200 x 200 • Wall fixings included • Tilt angle: –20° ~ +20° •...
  • Page 4 Package M M4 × 10 M4 × 15 M4 × 20 M5 × 10 M5 × 15 M5 × 20 M6 × 10 M6 × 15 M6 × 20 M8 × 10 M8 × 15 M8 × 20 Ø6-Ø8 × 5 Ø6-Ø8 ×...
  • Page 6 ø8mm 60mm ø3mm 30mm Use spacers provided for mounting TV’s with curved / recessed backs, recessed mounting holes, or to allow access to A/V inputs.
  • Page 7 For TV installation size 200 × 200mm For TV installation size 200 × 100mm Do not tighten the screws yet. Leave them loose to allow for adjustment of position on the rear of the TV.
  • Page 12 Visit www.partmaster.co.uk or call 0844 800 3456 (UK customers only) Calls charged at National Rate. DSG Retail Ltd. (co. no. 504877) Maylands Avenue, Hemel Hempstead, , HP2 7TG, UK Herts. IB-LBRKIT12-140512V5...
