FILE NO. 060-200473
REVISED.1
SERVICE MANUAL
Color Television
29CJZ8UR
Jan. 2005 (YC)

Advertisement

Table of Contents
loading

Related Manuals for Toshiba 29CJZ8UR

Summary of Contents for Toshiba 29CJZ8UR

  • Page 1 FILE NO. 060-200473 REVISED.1 SERVICE MANUAL Color Television 29CJZ8UR Jan. 2005 (YC)

  • Page 2: Table Of Contents

    TABLE OF CONTENTS CHAPTER 1 GENERAL ADJUSTMENTS SAFETY INSTRUCTIONS ............................3 SET-UP ADJUSTMENT ............................4 SERVICE MODE ..............................6 DESIGN MODE ................................ 9 ELECTRICAL ADJUSTMENTS ..........................10 CIRCUIT CHECK ..............................17 CHAPTER 2 SPECIFIC INFORMATIONS SETTING & ADJUSTING DATA ..........................18 LOCATION OF CONTROLS ...........................

  • Page 3: Chapter 1 General Adjustments

    CHAPTER 1 GENERAL ADJUSTMENTS SAFETY INSTRUCTIONS WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU- TION” AND “PRODUCT SAFETY NOTICE” INSTRUCTIONS BELOW. X-RAY RADIATION PRECAUTION 1. Excessive high voltage can produce potentially hazardous 2. The only source of X-RAY RADIATION in this TV receiver X-RAY RADIATION.

  • Page 4: Set-Up Adjustment

    WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU- TION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF SERVICE MANUAL. SET-UP ADJUSTMENT ■ The following adjustments should be made when a complete realignment is required or a new picture tube is installed. Perform the adjustments in order as follows : 1.
  • Page 5 (5)Adjust the sub-4-pole magnets only in case there is any deviation of Xv bow-shaped convergence. (To be usually set at the initial position) Align both sides with the sub-4-pole magnets and minimize the deviation of blue and red with the main 4-pole magnets. Xv bow-shaped deviation of convergence red/blue blue...

  • Page 6: Service Mode

    SERVICE MODE 1. ENTERING TO SERVICE MODE 1) Press o button once on 2) Press o button again to 3) While pressing the o button, Remote Control. keep pressing. press MENU button on TV set. Item Data or Sound Mute (Service mode display) 2.
  • Page 7 4. SELECTING THE ADJUSTING ITEMS 1)Every pressing of CHANNEL s button in the service mode changes the adjustment items in the order of table-2. (t button for reverse order) Refer to table-2 for preset data of adjustment mode. (See SETTING & ADJUSTING DATA on page 27) 5.
  • Page 8 The diagnosis will begin to check if interface among IC’s are executed properly. 2) During diagnosis, the following displays are shown. JH9_000 29CJZ8UR Firmware: Version information of microprocessor In case of file name : JH9 and Version : 1.00 indicates[JH9_100].

  • Page 9: Design Mode

    DESIGN MODE 1. ENTERING TO DESIGN MODE 3) The following displays 1) Select the Service mode. 2) While pressing CALL button on Remote and press MENU button on TV. are shown on the screen Press Press JH9_039 (Design mode) Version information of microprocessor Main tuner information Sub tuner information...

  • Page 10: Electrical Adjustments

    ELECTRICAL ADJUSTMENTS ITEM ADJUSTMENT PROCEDURE FOCUS VR ADJ 1. Enter the service mode, then select any register item. 2. Press the TV/VIDEO button on the Remote until the black cross-bar pattern ap- pears on the screen. 3. Adjust the FOCUS control (on T461) for well defined scanning lines on the picture screen.
  • Page 11 ITEM ADJUSTMENT PROCEDURE WIDTH 1. Call up the adjustment mode display, then select the item WID. (WID) 2. Press the ; – /+ button to get the picture so the left and rightedges of raster begins to lack. 3. Press the ; – /+ button to advance the data by 7 steps. Note : Check the horizontal picture position is correct.
  • Page 12 V/C system adjustment ADJUSTING ITEMS ADJUSTMENT PROCEDURE REMARKS AND POINTS Cutoff adjustment and 1) Setting to horizontal alignment, turn the screen VR to No outside lighting shall be allowed. white balance adjust- stop where the brightness lines are slightly luminous. Measurement shall be ment (Adjustment shall be made so that they look almost...
  • Page 13 Circuit Adjustment (Procedure Manual for Deflection Adjustment) ADJUSTING ITEMS ADJUSTMENT PROCEDURE AND POINTS Focus Adjustment (1) Conditions : PAL RETMA ch Static (main): T461 Screen Size : Wide Dynamic : T461 Presentation Mode : Dynamic Only for 34-inch model Adjustment Procedure: 1) Turn the static VR knob to the “MIN.”...
  • Page 14 Horizontal adjustment * Deflection adjustment shall be made from PAL/100 Hz/WIDE mode. ADJUSTING ITEMS ADJUSTMENT PROCEDURE AND POINTS Hori- For PAL/100 Hz/WIDE <Adjustment condition> zontal Horizontal amplitude Horizontal adjusment shall be made using E-12CH Philips pattern and DY- (WID) NAMIC image mode. Side pin distortion (PARA) <Adjustment procedure>...
  • Page 15 Vertical adjustment ADJUSTING ITEMS ADJUSTMENT PROCEDURE AND POINTS Verti- For PAL WIDE 1) With E-12ch, WIDE mode, DYNAMIC and 100 Hz, adjust the vertical screen posi- Vertical amplitude tion (VPOS) and amplitude (HIT) as shown in the following figure: (HIT) Flags shall just be blinded.
  • Page 16 Geomagnetic compensation (chassis adjustment) ADJUSTING ITEMS ADJUSTMENT PROCEDURE AND POINTS Output voltage control Conditions: User control for geomagnetic compensation: 0 (GMF) Geomagnetic compensation coil: Unconnected Perform voltage measurement at both ends of RJ06 and adjust the volt- age to the following adjustable value with GMF of data adjustment mode: 0 ±...

  • Page 17: Circuit Check

    CIRCUIT CHECK HIGH VOLTAGE CHECK CAUTION: There is no HIGH VOLTAGE ADJUSTMENT on this chassis. Checking should be done following the steps below. 1. Connect an accurate high voltage meter to the second anode of the picture tube. 2. Turn on the receiver. Set the BRIGHTNESS and CONTRAST controls to minimum (zero beam current). 3.

  • Page 18: Chapter 2 Specific Informations

    CHAPTER 2 SPECIFIC INFORMATIONS SETTING & ADJUSTING DATA SAFETY INSTRUCTIONS 29" HIGH VOLTAGE AT ZERO BEAM: 29.5 kV MAX HIGH VOLTAGE: 33.0 kV AC VOLTAGE 220~240 V Table-1 SERVICE MODE ADJUSTING ITEMS AND DATAS IN THE SERVICE MODE: Item Name of adjustment Item Name of adjustment 29"...

  • Page 19: Location Of Controls

    LOCATION OF CONTROLS Front ON-TIMER indicator (green) Press to open the door. I POWER indicator (red) Remote sensor Behind the door Input source selection Headphones jack – + Volume POWER switch (ø3.5 mm) < > Menu MENU (3) Video 3 input Channel position ts terminals Menu...
  • Page 20 Remote Control /CALL Power on/Standby CALL (For Toshiba TV/VCR/DVD only) Number buttons (0-9) Input source selection 1 or 2 digit channel selection (a1, a2, a3, aC1, aC2) Selectable sound Selectable picture MENU EXIT MENU EXIT MENU – + • Volume •...

  • Page 21: Programming Channel Memory

    PROGRAMMING CHANNEL MEMORY First, use the Auto tuning to preset all the active channels in your area automatically. Then, arrange the preset channels with the Manual tuning so that you can tune into only desired channels. Use the Manual tuning if desired channels cannot be preset with the Auto tuning or if you would like to preset channels to specific position numbers one by one.
  • Page 22 D. Program position skip selection Press the button to turn the program position skip option on “ ” or off “ ”. The program position will then be skipped when you select program positions with the CH8 or CH9 button. “...

  • Page 23: Chassis And Replacement Parts List

    • The part number must be used when ordering parts, in order to assist in processing, be sure to include the Model number and Description. ∗ • The PC board assembly with mark is no longer available after the end of the production. Model : 29CJZ8UR Capacitors ..... CD Ceramic Disk : Plastic Film : Electrolytic Resistors ....
  • Page 24 Location Location Parts No. Description Parts No. Description C676 24669479 ELECTROLYTIC, 50V 4.7UF M 3A C910 24669478 ELECTROLYTIC, 50V 0.47UF M 3A C677 24503042 PLASTIC FILM, 63V 0.12UF J C911 24203100 ELECTORLYTIC, 16V 10UF M 7L 3A C678 24503041 PLASTIC FILM , 63V 0.1UF J C912 24073042 ELECTROLYTIC, 16V 1000UF M 3A...
  • Page 25 Location Location Parts No. Description Parts No. Description CS56 24092538 CERAMIC CHIP, 10V F 1UF Z R330 24998103 CHIP, 1/16W 10K OHM CS57 24794470 ELECTROLYTIC, 16V 47UF M R331 24872823 CHIP, 1/16W 82K OHM J CS64 24794220 ELECTROLYTIC, 16V 22UF M R332 24011102 CHIP, 1/20W 1K OHM J...
  • Page 26 Location Location Parts No. Description Parts No. Description R662 24366101 CARBON FILM, 1/6W 100 OHM J @U905A R883 24366561 CARBON FILM, 1/6W 560 OHM J 24011222 CHIP, 1/20W 2.2K OHM J @U902 R899 24004718 METAL GLAZE 1/2W 8R2M J R663 24011472 CHIP, 1/20W 4.7K OHM J R901...
  • Page 27 Location Location Parts No. Description Parts No. Description R4560 24011102 CHIP, 1/20W 1K OHM J RS45 24011562 CHIP, 1/20W 5.6K OHM J R4562 24011103 CHIP, 1/20W 10K OHM J RS46 24011562 CHIP, 1/20W 5.6K OHM J R4563 24011752 CHIP, 1/20W 7.5K OHM J RS47 24011562 CHIP, 1/20W 5.6K OHM J...
  • Page 28 Location Location Parts No. Description Parts No. Description RV123 24011102 CHIP, 1/20W 1K OHM J LV10 23103159 EMI FILTER, TEM2028AA, 7.5X6.4X8 60MMH 0.5A LV11 23103159 EMI FILTER, TEM2028AA, 7.5X6.4X8 60MMH 0.5A RV124 24011330 CHIP, 1/20W 33 OHM J RV201 24011750 CHIP, 1/20W 75 OHM J LV12 23103159...
  • Page 29 Location Location Parts No. Description Parts No. Description Q908 23114429 TRANSISTOR, 2SC2120-Y D630 23316591 DIODE, ZENER, MA8100-M Q910 23114433 TRANSISTOR, 2SC1815-Y D631 23118041 DIODE, MA111 Q4021 23314204 TRANSISTOR, 2SC2412K,Q D632 23118041 DIODE, MA111 Q4022 23314163 TRANSISTOR, 2SA1162-Y D633 23118041 DIODE, MA111 Q4104 23314993 TRANSISTOR, 2SC4081 Q...
  • Page 30 Location Location Parts No. Description Parts No. Description DJ02 23357366 DIODE, FR105-B5 N724 23965900 TAPE, GLASS-CLOTH, W/ADHESIVE W=18 T=0.18 DJ03 23357366 DIODE, FR105-B5 N728 23960101 SILICONE RUBBER, TSE-382 RTV DJ04 23357366 DIODE, FR105-B5 P018A 23368577 CONNECTOR, PLUG, 3P 2.5MM G JST-EH, B3B-EH-F1-TV4 DV03 23316571 DIODE, ZENER, MA8056-M...
  • Page 31 Location Parts No. Description Y101 23566560 OWNERS MANUAL, ENGLISH/RUSSIAN Y120 23943846 BAG, POLY Y121 23943846 BAG, POLY CABINET PARTS A201 23533040 COVER, FRONT COVER A401 23532442 COVER, BACK COVER A902 23428340 DOOR, DOOR PROPER A905 23445889 BUTTON, BUTTON POWER A911 23436829 HANDLE A912...
  • Page 32 MEMO - 32 -...

  • Page 33: Pc Boards Top&Bottom View

    MODULE HYPER SIG BOARD UD1842E (UM01) BOTTOM (FOIL) SIDE - 33 - - 34 -...
  • Page 34 MODULE HYPER SIG BOARD UD1842E (UM01) TOP (COMPONENT) SIDE - 35 - - 36 -...
  • Page 35 POW/DEF BOARD PD1883J (U903) BOTTOM (FOIL) SIDE CAUTION LIVE AREA D815 P498 R805 R379 R818 G380 C396 R829 D808 T803 D817 C823 GJ406 23547685 C807 R807 D803 G406 C812 C816 C809 T400 G810 D801 R814 L811 G407 P803A C829 Q801 C818 F802 T4A L/250V...
  • Page 36 CRT-D BOARD PD1882L-1 (U901A) BOTTOM (FOIL) SIDE 23547684 D905 CCP-6400S Q904 Q907 L910 R939 R981 R983 R985 R984 C922 C924 C904 C905 R924 R917 Q911 R933Z Q903A Q901A R933 L905 R987 R943 R988 Q903 R912 R901 R932 L903 R970 Q901 R942 R904 R952...
  • Page 37 AV-TERMINAL BOARD PD1846H (U902) BOTTOM (FOIL) SIDE BB03A BB06A P602 P603 BB09A GR800 GRS06 R609 R610 GRS05 BB05A RS23 R603 R603 BB04A RS09 C602 CS11 RS05 RS23 C8352 C8345 RS03 RS01 GRS03 P018B RS07 Q601 GRS01 GRS01 GRS03 CS03 RS03 CS01 R672 Q833A...
  • Page 38 AV-TERMINAL BOARD PD1846H (U902) TOP (COMPONENT) SIDE JP033 JP010 P602 P603 BB05A BB06A BB03A C8345 BB04A C601 C602 PP06 BB09A 3 2 1 CS01 R672 P018B Q833 C678 GND_AUDIO GND_AUDIO D601 27V_AUDIO C836 27V_AUDIO C680 C661 C662 CS02 L836 C603 BB07A C110 PV22B...
  • Page 39 CONTROL BOARD PD1890B-1 (U905A) BOTTOM (FOIL) SIDE SA06 SA05 SA04 SA03 SA02 SA01 CC13 CC14 PV03 R662 CC11 CC12 RA76 RA87 RA71 RA72 RA73 D821 P661 S801 D863 R844 PB01A SR85 SR84 SR83 CV50 Q863 P019A RJ07 1 2 3 RJ03 R865 R808A...
  • Page 40 SCHEMATIC DIAGRAM MODEL : 29CJZ8UR WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION", "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" ON THE MANUAL FOR THIS MODEL. CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit or specified in the parts list.
  • Page 41 SCHEMATIC DIAGRAM STRUCTURE: HYPER SIGNAL (1/3) [SHEET-1/3] .... 1/54 (2/3) [SHEET-2/3] .... 2/54 (3/3) [SHEET-3/3] .... 3/54 REGULATOR .................... 4/54 (1/2) [SHEET-1/2] .... 5/54 (2/2) [SHEET-2/2] .... 6/54 ACTIVE-FILTER ..................7/54 AD-CONVERTER [SHEET-1/2] .... 8/54 [SHEET-2/2] .... 9/54 TC90101 (1/2) [SHEET-1/2] ..
  • Page 42 - 49 -...

  • Page 43: Specifications

    SPECIFICATIONS MODEL 29CJZ8UR Rated voltage 220 – 240 V, 50 Hz Power consumption 180 W 220 V, 50 Hz) Dimensions 782 mm 488 mm 585 mm (Width Depth Height ) Mass (Weight) 45.5 kg Visual screen diagonal line 677 mm...
  • Page 45 SCHEMATIC DIAGRAM MODEL : 29CJZ8UR WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION", "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" ON THE MANUAL FOR THIS MODEL. CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit or specified in the parts list.
  • Page 46 SCHEMATIC DIAGRAM STRUCTURE: HYPER SIGNAL (1/3) [SHEET-1/3] .... 1/54 (2/3) [SHEET-2/3] .... 2/54 (3/3) [SHEET-3/3] .... 3/54 REGULATOR .................... 4/54 (1/2) [SHEET-1/2] .... 5/54 (2/2) [SHEET-2/2] .... 6/54 ACTIVE-FILTER ..................7/54 AD-CONVERTER [SHEET-1/2] .... 8/54 [SHEET-2/2] .... 9/54 TC90101 (1/2) [SHEET-1/2] ..
  • Page 48 0.1V/div 0.1V/div 29CJZ8UR BEP (1/3) SH.NO. SHEET-1/3 (1/54)

  • Page 49: Circuit Block Diagram

    35PIN VP-OUT 0.1V/div #39 FBP_IN #37 H-OUT 29CJZ8UR BEP (2/3) SH.NO. SHEET-2/3 (2/54)
  • Page 50 1V/div 1V/div 1V/div 29CJZ8UR SH.NO. BEP (3/3) SHEET-3/3 (3/54)
  • Page 51 29CJZ8UR SH.NO. REGULATOR (4/54)
  • Page 52 29CJZ8UR I/F (1/2) SH.NO. SHEET-1/2 (5/54)
  • Page 53 29CJZ8UR I/F (2/2) SH.NO. SHEET-2/2 (6/54)
  • Page 54 29CJZ8UR SH.NO. ACTIVE-FILTER (7/54)
  • Page 55 29CJZ8UR AD-CONVERTER (A) SH.NO. SHEET-1/2 (8/54)
  • Page 56 29CJZ8UR AD-CONVERTER (B) SH.NO. SHEET-2/2 (9/54)
  • Page 57 0.2V/div 29CJZ8UR SH.NO. TC90101 (1/2) SHEET-1/2 (10/54)
  • Page 58 29CJZ8UR SH.NO. TC90101 (2/2) SHEET-2/2 (11/54)
  • Page 59 29CJZ8UR SH.NO. TC90101-REG (12/54)
  • Page 60 29CJZ8UR GENESIS (1/3) SH.NO. SHEET-1/3 (13/54)
  • Page 61 29CJZ8UR GENESIS (2/3) SH.NO. SHEET-2/3 (14/54)
  • Page 62 29CJZ8UR SH.NO. GENESIS (3/3) SHEET-3/3 (15/54)
  • Page 63 SH.NO. 29CJZ8UR SDRAM (16/54)
  • Page 64 29CJZ8UR SH.NO. GENESIS-OUT (17/54)
  • Page 65 29CJZ8UR SH.NO. GENESIS REG (18/54)
  • Page 66 29CJZ8UR SH.NO. RESET (19/54)
  • Page 67 29CJZ8UR SH.NO. SUB FILTER (1/2) SHEET-1/2 (20/54)
  • Page 68 29CJZ8UR SUB FILTER (2/2) SH.NO. SHEET-2/2 (21/54)
  • Page 69 29CJZ8UR SH.NO. 3DYCS-REG (22/54)
  • Page 70 29CJZ8UR 3DYCS (1/2) SH.NO. SHEET-1/2 (23/54)
  • Page 71 29CJZ8UR 3DYCS (2/2) SH.NO. SHEET-2/2 (24/54)
  • Page 72 29CJZ8UR M2 Micro (1/11) SH.NO. SHEET-1/11 (25/54)
  • Page 73 29CJZ8UR SH.NO. M2 Micro (2/11) SHEET-2/11 (26/54)
  • Page 74 29CJZ8UR M2 Micro (3/11) SH.NO. SHEET-3/11 (27/54)
  • Page 75 29CJZ8UR M2 Micro (4/11) SH.NO. SHEET-4/11 (28/54)
  • Page 76 29CJZ8UR M2 Micro (5/11) SH.NO. SHEET-5/11 (29/54)
  • Page 77 29CJZ8UR M2 Micro (6/11) SH.NO. SHEET-6/11 (30/54)
  • Page 78 29CJZ8UR M2 Micro (7/11) SH.NO. SHEET-7/11 (31/54)
  • Page 79 29CJZ8UR M2 Micro (8/11) SH.NO. SHEET-8/11 (32/54)
  • Page 80 29CJZ8UR M2 Micro (9/11) SH.NO. SHEET-9/11 (33/54)
  • Page 81 29CJZ8UR SH.NO. M2 Micro (10/11) SHEET-10/11 (34/54)
  • Page 82 29CJZ8UR M2 Micro (11/11) SH.NO. SHEET-11/11 (35/54)
  • Page 83 29CJZ8UR Connector (1/2) SH.NO. SHEET-1/2 (36/54)
  • Page 84 29CJZ8UR Connector (2/2) SH.NO. SHEET-2/2 (37/54)
  • Page 85 PLUG B-B 9P 8-D11 GND_MICON BB09A 8-B12 GND_2 8P B-B 8-F11 +12V +12V POWER 8-B12 POWER LOWB_GND 8-E11 +15V 15V_FBT 6-B3 -15V_FBT 4-E1 -15V P803A 5P 5mm AC_LINE_B2 P804A Lock 2P_11.88mm_S AC_LINE_A2_CHOKE_A CHOKE_B AC_LINE_A2_CHOKE_A 29CJZ8UR POWER DEF (1) SHEET-1/5 (38/54)
  • Page 86 R398 4.7k 6.2K R4799 R3901 Q391 R395 Q394 2SC2412K 2SC2412K C393 C392 B0.01 R3904 Q3950 1uNP R387 4-C1 2SC2412K R386 4.3k EW_FB 4-B1 EW_FB C3940 10V1u R3990 R397 DQF_VIDEO 3-B1 DQF_VIDEO 4-D1 29CJZ8UR POWER DEF (EW VERT) (3) SHEET-2/5 (39/54)
  • Page 87 1/2S 22K SCREEN 15.3 -15V_FBT -15V_FBT C3100 D303 R328 25V1000 FR105-FL 2W2.2 C303 KETSU G459 R327 SHORT 2W2.2 ABL_FBT 1-D3 +15.3 15V_FBT 6-B3 15V_FBT C310 D302 R445 FR105-FL 25V1000 KETSU C445 DV400V0.056 T461 TFB4216AS 150vo-p 29CJZ8UR POWER DEF (HORIZONTAL)(4) SHEET-3/5 (40/54)
  • Page 88 133V 132V F470B F470A C472 0.47 Q470 2SA949-Y R476 1/4R20k D470 R477 MTZJ36B PROTECT 8-D11 R473 C470 1/4R39K 50V22 D475 D476 MTZJ12C 1SS133 HV_DET HV_DET LVP_DET R475 9.1k 200V_DET R435 R494 220KG 180KG 29CJZ8UR POWER DEF (PROTECT) (6) SHEET-4/5 (41/54)
  • Page 89 BRDT2W3X10SZN D807 R883 R815 MTZJ6.8B 1/2W1k D828 R806 1SS133 C809 1/2R18k 63V0.1 C821 500V470 C833 C823 D806 500V470 G812 L811 FR105-FL TEM2011 R821 TEM2011 C817 2KV330 C818 D817 1.25KV2200p 1SS244 R824 10W6.8 29CJZ8UR COLD POWER DEF (POWER) (8) SHEET-5/5 (42/54)
  • Page 90 C910 L910 1/4W 8.2 50V0.47u +9V-1 OPEN R939 1/6P10 C922 R986 OPEN OPEN L908 C912 D901 10u COLTRF4100AT 16V1000 1SS133 R936 C912Z C921 R991 KETSU 16V2200 R990 OPEN OPEN OPEN Q908 GJ04 2SC2120-Y R933Z KETSU 29CJZ8UR CRT-D/SVM (1/2) SHEET-1/2 (43/54)
  • Page 91 GJ05 2SA1015-Y R716 R717 OPEN 1/6P27k 1/6P33k C716 R715 C705 R702 R741 1/6P27k 0.01 1R2.2 1/2R220 R739 R745 L702 1/6P680 1/6P1.2k C718 50V47 D705 R740 C719 1SS133 1R47 C720 200V10 R743 2RJ180 P705 3P_2.5mm_S_SMK M705 29CJZ8UR CRT-D/SVM (2/2) SHEET-2/2 (44/54)
  • Page 92 U901A L801Z L802Z OPEN OPEN L801 L802 TPW2064AL/TPW2058AS TPW2064AL/TPW2058AS P804B Lock 2P_11.88mm_S GJ16 OPEN GJ14 OPEN OPEN OPEN GJ17 GJ15 29CJZ8UR CRT-D/SVM CHOKE COIL (45/54)
  • Page 93 RXD_EXT 5V1_EXT 7-C3 TO CONTROL BOARD TXD_EXT IF_GND RXD_EXT P018B 3P_2.5mm_1.5A_Beige 7-B5 7-B5 GND_AUDIO GND_AUDIO GND_AUDIO 7-B5 27V_AUDIO 27V_AUDIO 27V_AUDIO 7-B5 7-B5 P805 CON 1P TO B/M MODULE TO PC/D TERMINAL TO PC/D TERMINAL 29CJZ8UR AV TERMINAL (1/7) SHEET-1/7 (46/54)
  • Page 94 Q4103 2SC4667 2SC4081-Q G_PC R4102 R4107 G_PC R4104 R4109 Q4102 2SC4081-Q R4123 R4121 B_PC 2.2k B_PC 2.2k Q4100 2SC4667 R_PC R_PC VS_PC VS_PC HS_PC HS_PC GRV01 OPEN GRV02 OPEN GRV03 OPEN GRV04 OPEN 29CJZ8UR AV TERMINAL (V SW) SHEET-2/7 (47/54)
  • Page 95 RS64 2SC4081-Q 6.8k RS68 R_BM R_BM QS41 MUTE 2SC4081-Q RS65 CS31 1.8k 16V10 RS66 BIAS R_MONI R_MONI L_E6 RS72 L_E6 RS70 CS64 2.2k 16V22 R_E6 R_E6 7-C5 SCL1 6-E2 SCL1 SDA1 6-E2 SDA1 29CJZ8UR AV TERMINAL (A SW) SHEET-3/7 (48/54)
  • Page 96 AUDIO OUT 50V0.47 QS07 2SC3326B RS33 L_E6 L_E6 L_AUDIO L_AUDIO RC07 RS26 CC07 100K B1000p R_AUDIO R_AUDIO RC08 QS04 CC08 QS05 B1000p 2SC3326B RS57 RN2404 RS21 RS25 100K CS25 RS20 50V0.47 100K QS06 2SC3326B RS73 29CJZ8UR AV TERMINAL (JACK) SHEET-4/7 (49/54)
  • Page 97 C107 OPEN B25V0.01 MTZJ33C 16V220 C102 10V220 C103 C106 B25V0.01 50V4.7 R_APRO 6-B2 6-B2 L_APRO W_APRO W_APRO L_AV R_AV L_TV R_TV 7-B5 7-C5 RESET_IMA 7-C5 V_TV1 Q170 2SC4081-Q R170 R171 MAIN_AFT R172 29CJZ8UR AV TERMINAL (TUNER IF TIF) SHEET-5/7 (50/54)
  • Page 98 C626 C641 C643 R635 C645 C650 50V4.7 50V2.2 CHIP 4.7k 220p C633 KETSU 100u 5-C7 SCL1 SCL1 R625 Q631 FILTER SCL1 2SC3326B C628 SDA1 5-C7 SDA1 R640 HP_AMP R624 SDA1 Q632 2SC3326B R639 29CJZ8UR AV TERMINAL (AUDIO OUT) SHEET-6/7 (51/54)
  • Page 99 850mA C8348 C8350 C8342 HE16V56u(NEW) 16V10 63V0.33 Q831A Q833 BA50BC0T 750mA C8352 C8345 C8351 16V10 63V0.33 HE16V56u(NEW) Q833A Q834 NJM2396F05D L836 1.0A TLN3299GH VOUT C8349 CONTROL C836 C8347 16V10 10V2200 C8344 10V22 63V0.33 Q834A 29CJZ8UR AV TERMINAL (REGURATOR) SHEET-7/7 (52/54)
  • Page 100 4.7k 1SS133 SR83 R808A G5PA-2 RZ92P2E4R5M1 D821 1SS133 Q821 2SC1815-Y R844 R843 5V-2 14 13 FROM POW/DEF TO POW/DEF POWER/DEF BOARD HYPER SIGNAL BOARD HYPER SIGNAL BOARD AV TERMINAL BOARD AV TERMINAL BOARD BB07/BB08 OR P018A/P019A 29CJZ8UR CONTROL LED (53/54)
  • Page 101 23367068G 23368577G 23368103 M601 PC/D TERMINAL 23501896 M104 PV21B PV22B P802A P803A 23368588 23368664 W_GND 23509200 P602 23368577G M805 P805 W_SPK P800 RAKUDENN RAKUDENN M611 L_GND 23509783 M805 L_OUT P603 23368578G R_OUT PM02A R_GND 23367071G M602 23501897 29CJZ8UR CONNECTION (54/54)
