Technical Information
Skyclimber
Page 1
Installation instructions
Maintenance instructions EN 1176-1
03.03.16
General
The described work is to be carried out by qualified specialists (a minimum of 3 persons).
Anchoring of the lattice equipment is made on a hot-galvanized square tube frame. Concrete work is not
necessary making any possible change of location quite easy without removing foundations or having
them remain in the earth.
Dimensions
∅ 5,00 m
Equipment space
Fall space
∅ 8,90 m
Minimum space
Height
Age group
From 4 years of age
Number of users
Approximately 36 children
Maximum free fall height
2.60 m
Ground conditions
We refer to EN 1176-1 with respect to the ground conditions in the playing area. Sand, wood chippings,
gravel and synthetic fall protector with HIC test are accordingly permitted. We recommend a 400 mm
thick bed of gravel (grit size 2 – 8 mm) or a sand filling (grain size 0.2 – 2 mm). When applying a synthetic
fall protector it must be guaranteed that all positions relevant for maintenance (refer to the maintenance
instructions on Pages 12 and 13) be accessible at all times. If necessary consult SMB.
EN 1176-1
1.50 m
5.00 m
The Skyclimber
