Technical Information
Carrantuohill
Page 1
Installation Instructions
10.10.14
General
The operations described are to be carried out by a specialist.
The climbing frame is fixed on a galvanised square tubular frame. Concreting is not necessary. It is easy to
change the location without the bases
having to be removed or remaining in
the soil.
Dimensions
Effective space
2.99 x 2.99 m
Drop
Minimum space
6.09 x 6.09 m
Height
Age group
4 years upwards
Number of users
About 15 children
Maximum free drop height
1.57 m
Ground quality
With regard to the type of ground in the play area, please refer to EN 1176-1. According to this, sand, wood
chips, gravel and HIC tested synthetic protective coatings are allowed. We recommend a min. 400 mm thick
layer of gravel (grain size 2 – 8 mm) or sand (grain size 0.2 - 2 mm). If you use a synthetic protective surface
it must be sure that all relevant parts for the maintenance (see maintenance instruction on page 4) are every
time accessibly. If necessary consult SMB.
Assembly tools
Tools supplied:
1
size 32 socket spanner with extension
1
size 10 Allen key
2
special bits for securing screws
1
size 27socket spanner
EN 1176-1
1.55 m
2.99 m
Figure 1
Type Carrantuohill
Additional tools required:
2
size 24 open-jawed spanners
1
electric screwdriver for special bits
1
double ladder, approx. 3 m long
normal assembly tools
