DeLonghi EC860.M Manual

Before using the appliance, always read the safety warnings.
1. DESCRIPTION
1.1 Description of the appliance
(page 3 - A )
A1. Cup shelf/Cup warmer
A2. Milk container/water spout connector
A3. Main switch
A4. Power cord connector socket
A5. Boiler outlet/Infuser assembly
A6. Water tank housing
A7. Water tank lid
A8. Water tank with water filter housing
A9. "No water" indicator
A10. Drip tray
A11. Drip tray max. water level indicator
A12. Cup tray
A13. Sliding compartment for macchiato/caffelatte glass
A14. Cup warmer button
1.2 Description of control panel
(page 3 - B )
B1. ON/Stand-by button
B2. ON/Stand-by light
B3. 1 cup button
B4. Temperature OK/1 cup light
B5. 2 cups button
B6. Temperature OK/2 cups light
B7. Hot water button
B8. Hot water light
B9. Cappuccino/hot milk button
B10. Temperature OK/cappuccino/hot milk light
B11. Macchiato/hot milk button
B12. Temperature OK/macchiato/hot milk light
1.3 Description of the accessories
(page 2 - C )
C1. Filter holder
C2. 1 coffee froth filter
C3. 2 coffee froth filter
C4. ESE pod froth filter
C5. Power cord (removable)
C6. Measure/pressure
C7. Removable hot water spout
C8. Water hardness indicator paper (Total Hardness test)
C9. Descaler
C10. Water softener filter
1.4 Description of the milk container
(page 2 - D )
D1. Milk frother lid
D2. CLEAN button
D3. Milk spout
D4. Milk intake tube
D5. Milk container
2. FILLING THE WATER TANK
1. Extract the water tank (A8) and fill with fresh clean water,
taking care not to exceed the MAX level (fig. 1).
2. Then put the tank back in the machine (fig. 2).
Important: never operate the appliance without water in the tank or
without the tank.
3. SETTING UP THE APPLIANCE
1. Plug the power cord connector into the socket at the back
of the appliance (fig. 3), then plug the plug into the mains
socket.
2. Attach the filter holder to the appliance. To attach correctly,
align the filter holder handle with the
(fig. 4), then rotate the handle to the right until it is aligned
with the CLOSE symbol (fig. 5);
3. Place the main switch on the back of the appliance in the
I position;
4. At the end of the self-diagnosis cycle, the "hot water" light
(B8) flashes and the other lights go off. The appliance indi-
cates that the hot water spout must be inserted (C7) (fig.
6);
5. Place a container with a minimum capacity of 100 ml under
the spout (fig. 7);
6. Press the "hot water"
then stops automatically;
(B2)
Please note: if the
button again.
7. To rinse the internal circuits of the appliance, place a recipi-
ent under the coffee spout and press the
Repeat five times;
8. Now rinse the "steam" circuit. Place a recipient under the
hot water spout (fig. 7) and press the
five times. (If necessary, refill the tank).
Please note: we also recommend rinsing the internal circuits through if
the appliance is not used for a long period.
4. ACTIVATING THE WATER SOFTENER FILTER
Certain models are fitted with a water softener filter (C10). If
this is not the case with your model, you are recommended to
purchase one from De'Longhi Customer Services.
To use the filter correctly, follow the instructions below.
1. Remove the filter from the packaging;
15
OPEN symbol
button (B7). Delivery begins,
(B8)
and lights flash, press the
button (B5).
button. Repeat
