Overview
Before you begin, you should have a powerline network already set up, with
your router connected to a Powerline Adapter. The following instructions
describe how to connect the Powerline 4-Port Network Adapter (model
number: PLTS200) to additional computers or other network devices.
Internet
Modem
Router
Installation
A.
Connect one end of an Ethernet
network cable to the Ethernet
port of the Adapter.
All manuals and user guides at all-guides.com
Powerline 4-Port
Network Adapter
Powerline Network
Adapter
Diagram of a Typical Powerline Network
Computer
Network
Storage
Gaming Console
Powerline 4-Port
Network Adapter
Connect Ethernet Network Cable
Computer
