Summary of Contents for DAEWOO ELECTRONICS AMI-717L
- Page 1 All manuals and user guides at all-guides.com...
- Page 2 All manuals and user guides at all-guides.com FIGURE 1 EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE ANTENNA LEAD IN WIRE PORTABLE GROUND CLAMP CART ANTENNA WARNING DISCHARGE UNIT (NEC SECTION 810-20) ELECTRIC SERVICE EQUIPMENT GROUNDING CONDUCTORS (NEC SECTION 810-21) GROUND CLAMPS POWER SERVICE GROUNDING ELECTRODE SYSTEM...
- Page 3 All manuals and user guides at all-guides.com...
- Page 4 All manuals and user guides at all-guides.com FM Antenna FM RF SSG Terminal(75 ohm) 75 ohm Coaxal Carrier Frequency : 98MHz Output Level : 26dBuV Modulation:Audio 1kHZ, 75kHz Deviation RF Signal Waveform VOLT/DIV : 200mV TIME/DIV : 50ns Level : 1.2+0.3Vp-p Traverse Waveform...
- Page 5 All manuals and user guides at all-guides.com Output Level Measurement Input Point Scope Point 47 kohm R-CH VTVM Input Level Measurement Point L-CH 47 kohm Adjust with Frequency Counter Connected Test Tape : MTT-111N(3kHz) Frequency Counter MTT-5511(Blank) Output Level Measurement Point Reverse Forward Side...
-
Page 6: Exploded View And Mechanical Parts List
All manuals and user guides at all-guides.com 2. EXPLODED VIEW AND MECHANICAL PARTS LIST u AMI - 717L / 717R / 817L / 817R / 817LS / 817LSR - 6 -... - Page 7 All manuals and user guides at all-guides.com Q ' t y N o . P a r t s N a m e P a r t s C o d e D e s c r i p t i o n 7 1 7 L / 7 1 7 R 8 1 7 L / R / L S / L S R W I N D O W D O O R A / B 9 C D 1 6 1 3 9 0 0...
-
Page 8: Wiring Diagram
All manuals and user guides at all-guides.com 3. WIRING DIAGRAM u AMI - 717L / 717R / 817L / 817R / 817LS / 817LSR - 8 -... -
Page 9: Block Diagram
All manuals and user guides at all-guides.com 4. BLOCK DIAGRAM u AMI - 717L / 717R / 817L / 817R / 817LS / 817LSR - 9 -... -
Page 10: Schematic Diagram
All manuals and user guides at all-guides.com 5. SCHEMATIC DIAGRAM u POWER / AMP w AMI - 717L / 717R - 10 -... - Page 11 All manuals and user guides at all-guides.com u POWER / AMP w AMI - 817L / 817R - 11 -...
- Page 12 All manuals and user guides at all-guides.com u POWER / AMP w AMI - 817LS / 817LSR - 12 -...
- Page 13 All manuals and user guides at all-guides.com u CD w AMI - 717L / 717R / 817L / 817R - 13 -...
- Page 14 All manuals and user guides at all-guides.com u TUNER w AMI - 717L / 717R / 817L / 817R / 817LS / 817LSR - 14 -...
- Page 15 All manuals and user guides at all-guides.com u TUNER-FTZ (OPTIONAL) w AMI - 717L / 717R / 817L / 817R / 817LS / 817LSR - 15 -...
- Page 16 All manuals and user guides at all-guides.com u TAPE w AMI - 717L / 717R / 817L / 817R / 817LS / 817LSR - 16 -...
- Page 17 All manuals and user guides at all-guides.com u CONTROL w AMI - 717L / 717R / 817L / 817R - 17 -...
- Page 18 All manuals and user guides at all-guides.com u CONTROL w AMI - 817LS / 817LSR - 18 -...
- Page 19 All manuals and user guides at all-guides.com Q ' t y N o . P a r t s N a m e P a r t s C o d e D e s c r i p t i o n L o c a t i o n 7 1 7 R 7 1 7 L A M R F U N I T...
- Page 20 All manuals and user guides at all-guides.com Q ' t y N o . P a r t s N a m e P a r t s C o d e D e s c r i p t i o n L o c a t i o n 7 1 7 R 7 1 7 L C M Y L A R...
- Page 21 All manuals and user guides at all-guides.com Q ' t y N o . P a r t s N a m e P a r t s C o d e D e s c r i p t i o n L o c a t i o n 7 1 7 R 7 1 7 L 1 3 6...
- Page 22 All manuals and user guides at all-guides.com Q ' t y N o . P a r t s N a m e P a r t s C o d e D e s c r i p t i o n L o c a t i o n 7 1 7 R 7 1 7 L R 5 2 0...
- Page 23 All manuals and user guides at all-guides.com Q ' t y P a r t s N a m e P a r t s C o d e D e s c r i p t i o n 8 1 7 8 1 7 8 1 7...
- Page 24 All manuals and user guides at all-guides.com Q ' t y P a r t s N a m e P a r t s C o d e D e s c r i p t i o n L o c a t i o n 8 1 7 8 1 7...
- Page 25 All manuals and user guides at all-guides.com Q ' t y P a r t s N a m e P a r t s C o d e D e s c r i p t i o n L o c a t i o n 8 1 7 8 1 7...
- Page 26 All manuals and user guides at all-guides.com Q ' t y P a r t s N a m e P a r t s C o d e D e s c r i p t i o n L o c a t i o n 8 1 7 8 1 7...
