Summary of Contents for DAEWOO ELECTRONICS AMI-316L
- Page 2 FIGURE 1 EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE ANTENNA LEAD IN WIRE PORTABLE GROUND CLAMP CART ANTENNA WARNING DISCHARGE UNIT (NEC SECTION 810-20) ELECTRIC SERVICE EQUIPMENT GROUNDING CONDUCTORS (NEC SECTION 810-21) GROUND CLAMPS POWER SERVICE GROUNDING ELECTRODE SYSTEM (NEC ART 250, PART H) NEC : NATIONAL ELECTRICAL CODE FIGURE 2...
- Page 4 FM Antenna FM RF SSG Terminal(75 ohm) 75 ohm Coaxal Carrier Frequency : 98MHz Output Level : 26dBuV Modulation:Audio 1kHZ, 75kHz Deviation RF Signal Waveform VOLT/DIV : 200mV TIME/DIV : 50ns Level : 1.2+0.3Vp-p Traverse Waveform...
- Page 5 Output Level Measurement Input Point Scope Point 47 kohm R-CH VTVM Input Level Measurement Point L-CH 47 kohm Adjust with Frequency Counter Connected Test Tape : MTT-111N(3kHz) Frequency Counter MTT-5511(Blank) Output Level Measurement Point Reverse Forward Side Side Test Tape MTT-114N (10kHz) Oscilloscope...
-
Page 6: Exploded View And Mechanical Parts List
2. EXPLODED VIEW AND MECHANICAL PARTS LIST u AMI - 316L / 316R - 6 -... - Page 7 N o . Parts Name Parts Code Description Q ' ty W I N D O W D O O R A 9 C D 1 6 1 3 9 0 0 A C R Y L W I N D O W D O O R B 9 C D 1 6 1 4 0 0 0 A C R Y L C O V E R D O O R A...
- Page 8 u AMI - 317L / 317R - 8 -...
- Page 9 N o . Parts Name Parts Code Description Q ' ty W I N D O W D O O R A / B 9 C D 1 6 1 3 9 0 0 A C R Y L W I N D O W D O O R A / B 9 C D 1 6 1 4 0 0 0 A C R Y L C O V E R D O O R A / B...
-
Page 10: Wiring Diagram
3. WIRING DIAGRAM u AMI -316L / 316R /317L / 317R - 10 -... -
Page 11: Block Diagram
4. BLOCK DIAGRAM u AMI -316L / 316R /317L / 317R - 11 -... -
Page 12: Schematic Diagram
5. SCHEMATIC DIAGRAM u POWER / AMP w AMI -316L / 316R /317L / 317R - 12 -... - Page 13 u CD w AMI -316L / 316R /317L / 317R - 13 -...
- Page 14 u TUNER w AMI -316L / 316R /317L / 317R - 14 -...
- Page 15 u TUNER-FTZ (OPTIONAL) - 15 -...
- Page 16 u TAPE w AMI -316L / 316R /317L / 317R - 16 -...
- Page 17 u CONTROL w AMI - 316L / 316R / 317L / 317R - 17 -...
- Page 22 Q ' t y P a r t s C o d e D e s c r i p t i o n L o c a t i o n P a r t s N a m e 3 1 7 L 3 1 7 R 3 1 6 L...
- Page 23 Q ' t y P a r t s C o d e D e s c r i p t i o n L o c a t i o n P a r t s N a m e 3 1 7 L 3 1 7 R 3 1 6 L...
- Page 24 Q ' t y P a r t s C o d e D e s c r i p t i o n L o c a t i o n P a r t s N a m e 3 1 7 L 3 1 7 R 3 1 6 L...
- Page 25 Q ' t y P a r t s C o d e D e s c r i p t i o n L o c a t i o n P a r t s N a m e 3 1 7 L 3 1 7 R 3 1 6 L...
