Assembly Instructions
CM4321S
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
Phillips Screwdriver
products, two persons are recommended.
(Not Included)
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 9
Rev: 18-10-22
Advertisement
Related Manuals for Furniture of America CM4321S
Summary of Contents for Furniture of America CM4321S
- Page 1 Assembly Instructions CM4321S ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Phillips Screwdriver products, two persons are recommended.
- Page 2 Page 2 of 9...
- Page 3 Parts List Hardware List (Continued) #1 x 1 pc #D x 8 pcs Table Top Lock Washer 5/16” #2 x 2 pcs #E x 1 pc Leg A Allen Wrench M5 #3 x 2 pcs #F x 4 pcs Leg B Bracket #4 x 1 pc #G x 8 pcs...
- Page 4 Align the bracket (#F) with the pre-drilled holes on each of the leg A (#2) AND each of the leg B (#3). Insert 8 flat bolts (#B) into the brackets (#F) using the Allen wrench (#E) to lock them in with the two leg A (#2) AND the two leg B (#3).
- Page 5 Turn right (clockwise) to tighten #A x 8 pcs #C x 8 pcs #D x 8 pcs Carefully place the table top (#1) facing down on a protected surface. Align the brackets (#F) assembled on the leg A (#2) AND the leg B (#3) with the pre-drilled holes on the bottom of the table top (#1).
- Page 6 Place the bottom shelves (#5R/L) over the shelf supports (#L). Make sure the bottom shelves (#5R/L) are rested and leveled on top of all the shelf supports (#L). Carefully place the glass top (#6) onto the table top (#1). Make sure the table is rested on a flat surface and it does not feel loose or wobbly.
- Page 7 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 6 pcs Seat Cushion Bolt 5/16”x1-3/4” #2 x 1 pc #B x 6 pcs Seat Frame...
- Page 8 #A x 3 pcs Turn right (clockwise) to tighten #B x 3pcs #C x 3 pcs Insert the center leg (#4) and the two side legs (#5) into the seat frame (#2). Prepare 3 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#A) and then the flat washer (#C) onto the SAME bolt (#A), in that order.
- Page 9 #A x 3 pcs #B x 3 pcs #C x 3 pcs Insert the center leg (#4) and the two side legs (#5) into the base (#3). Prepare 3 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#A) and then the flat washer (#C) onto the SAME bolt (#A), in that order.
