Assembly Instructions
CM4321C
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
Phillips Screwdriver
products, two persons are recommended.
(Not Included)
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 8
Rev.14-06-10
Advertisement
Related Manuals for Furniture of America CM4321C
Summary of Contents for Furniture of America CM4321C
- Page 1 Assembly Instructions CM4321C ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Phillips Screwdriver products, two persons are recommended.
- Page 2 Page 2 of 8...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 12 pcs Table Top Bolt 5/16”x7/8” #2 x 1 pc #B x 8 pcs Leg A...
- Page 4 Align the two brackets (#G) with the pre-drilled holes of the leg A (#2). Insert 4 bolts (#B) into the brackets (#G) using the Allen wrench (#E) to lock them with the leg A (#2). #B x 4 pcs Turn right (clockwise) to tighten #G x 2 pcs Align the two brackets (#G) with the pre-drilled holes of the leg B (#3).
- Page 5 Carefully place the table top (#1) facing down on a protected surface. Align the brackets (#G) assembled on the leg A (#2) AND the leg B (#3) with the pre-drilled holes on the bottom of the table top (#1). III. Prepare 8 bolt assemblies by inserting FIRST the lock washer (#C) onto the bolt (#A) and then the flat washer (#D) onto the SAME bolt (#A), in that order.
- Page 6 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc x 4 #A x 6 pcs x 4 Seat Cushion Bolt 5/16”x1-3/4”...
- Page 7 Turn right (clockwise) to tighten #A x 3 pcs #B x 3 pcs #C x 3 pcs Insert the center leg (#4) and the two side legs (#5) into the seat frame (#2). Prepare 3 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#A) and then the flat washer (#C) onto the SAME bolt (#A), in that order.
- Page 8 #A x 3 pcs #B x 3 pcs #C x 3 pcs Insert the assembled center leg (#4) and the side legs (#5) into the base (#3). Prepare 3 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#A) and then the flat washer (#C) onto the SAME bolt (#A), in that order.
