First Setup; Wall Mounted - Xenios WOD TIMER User Manual

FIRST SET UP:
ROOF HANGING HARDWARE SET

WALL MOUNTED

TO PLUG IT
Xenios USA and/or its international licensers are not responsible for any damage and/or injuries that may occour to persons, animals, objects and/or properties, while
®
wall-mounting the WOD Timer.
4 4
WOD TIMER
The WOD Timer comes with two sets of hardware to be top-hung at the
floor. Each set contains a steel hook-bolt to be screwed in to the Timer
cursors that are pre-assembled in to the top-side track, and a steel
wire to hang the Timer to the ceil. All hardware to fix the steel wires to
the roof/ceil is not provided.
The WOD Timer can be wall-mounted by using provided hardware. Wall
screws are not provided along with the timer.
Each bracket carries 3 holes. According to the top and bottom bracket
holes combination, the Timer can be set on the wall in a straight
position, or tilted-up or tilted-down.
WARNING: Do not use any other AC Adaptor than the one provided
with the WOD Timer. Do not supply the WOD Timer with different
voltage power than 110/220 V. Warranty will void in case of mis-use of
the WOD Timer.
EQUIPMENT FOR THE FITTEST
