Edge Wireless BTR-18 Manual

BTR-18 Manual
1. Ensure your streaming device has Bluetooth® enabled and that power is applied to the BTR-18.
(The blue LED on the BTR-18 will blink to indicate it is in pairing mode.)
2. Within your streaming device's Bluetooth® setup menu, select " BTR-18 " from the list of pairable
devices.
3. When successfully connected, the Blue LED on the BTR-18 will stop blinking and remain lit. A single
beep will be heard through the connected audio system.
4. Connecting the blue wire (remote out) to the amplifier (remote in) to turn the amplifier on/off.
5. The BTR-18 will remember the last device that was connected to it and reconnect with it auto-
matically. When a connected streaming device is out of range for more than one minute, the
BTR-18 will automatically disconnect this device and return to pairing mode (LED will blink).
6. The BTR-18 can be installed out of sight, as it has a waterproof wireless remote to be used with.

Wiring Diagram

7TH BUILDING, NO.59 CHUANG FU ROAD, XIAO GANG
INDUSTRIAL ZONE, NINGBO 315800, CHINA
Tel +86.574.873.88888 Fax +86.574.876.77777
Power (yellow)
Ground (black)
Remote in
Remote out
Auxiliary input female
Audio RCA output male
www.edgeholdings.com
(red)
(blue)
(red)
