- Page 1 EMOTEC HCS 9003 Assembly and operating instruction Made in Germany IP x4 Druck Nr. 29344209en / -24.12...
-
Page 2: Table Of Contents
English Table of Contents Package contents ....................4 Optional connections: ..................4 Technical data ......................5 General information concerning sauna bathing ............6 General safety precautions ..................7 Assembly of the control unit ..................8 Wall mounting....................8 Electrical connection ....................9 Connecting the sauna oven ..................9 Connecting the sauna lamp ................10 Connecting a fan .....................10 Connecting a power control unit ..............10 Connecting a colored light ................10... - Page 3 Operation ......................17 Button functions ....................17 Symbol description ..................17 Initial unit switch-on ....................18 Preset parameters ...................19 Finnish sauna mode ..................19 Temperature display ..................19 Actual - target display ..................19 Heating time ....................19 To consider when programming: ................20 The keylock / hotel mode ..................21 Specialist section ....................22 F1 Setting the current time ................22 F2 Programming the reheating period after humid operation ......23...
-
Page 4: Package Contents
Package contents (subject to change) Included with the control unit are: 1. An oven-sensor board with overheat shutoff protection, KTY-sensors with sensor housing , two 3x25 mm fastening screws and a 2,0 m long sensor cable, red and white. 2. A plastic bag with three 4 x 20 mm fastening screws. 3. -
Page 5: Technical Data
Technical data Nominal voltage: 400 V 3 N AC 50 Hz Switching load: max. 9 kW Ohm resistive load (AC1 - mode) Air conditioning mode: 6 kW + 3 kW for vaporiser device can be extended by connecting powered control units up to 36 kW Heating time limit: 6 hr, 12 hr or no heating time limit... -
Page 6: General Information Concerning Sauna Bathing
General information concerning sauna bathing Dear customer, with purchase of this sauna control unit you For the cabin light use only light bulbs. Do opted for a superior quality, high-tech elec- not use fl uorescent lamps, energy saving tronic device which was developed and lamps and gas discharge lamps. -
Page 7: General Safety Precautions
General safety precautions • his device has not been designed for being • Please note the safety and installation in- used by persons (including children) that formation from the sauna oven manufac- are physically or mentally handicapped turer. or have sensory disabilities. Moreover, it •... -
Page 8: Assembly Of The Control Unit
Assembly of the control unit Wall mounting Mount the control unit outside the sauna cabin only. The most practical mounting point would be the wall area onto which the sauna oven is mounted on the inside, except on the outside of the cabin. If elec- trical conduits are present, mount the con- trol unit accordingly. -
Page 9: Electrical Connection
Electrical connection Connecting the sauna oven The electrical connection may only be done by a qualifi ed electrical technician under authority of the regulations of the Assemble the sauna oven according to the local power supply company and those instructions provided by the manufacturer in of the VDE. -
Page 10: Connecting The Sauna Lamp
Connecting the sauna lamp Connecting the remote but- The sauna lamp must be weatherproof pro- Details can be found in the remote button tected (IPx4) and resistant to the ambient assembly instructions. temperature. Connecting a GSM module The sauna lamp can be mounted at any point, but never near to rising hot air from the heater and as far as possible from the installation position of the IR lamp (may not... -
Page 11: Installation Diagram
Installation diagram EmoLux = alternativ oder Emotec max. 3 kW oder 400 V 3 N AC 50 Hz Terminal arrangement on the circuit board. (Power unit) 500 mA T Jumper S1 FAN LIGHT WM Nr. 2 Nr. 1 TEMP.- Ub E G L1 L2 L3 W WB TEMP.-SENSOR... -
Page 12: Sensor Connection
Sensor connection 142°C Ub G E Nr. 2 Nr. 1 TEMP.- Ub E G TEMP.-SENSOR LIMITER H-SENSOR Connection of the vaporizer max. 100 W max. 100 W S1 FAN LIGHT WM L1 L2 L3 W WB 400 V 3 N AC 50 Hz 3 kW P max. -
Page 13: Connection Of Sauna Heaters ≤ 9 Kw
Connection of sauna heaters ≤ 9 kW max. 100 W max. 100 W S1 FAN LIGHT WM L1 L2 L3 W WB 400 V 3 N AC 50 Hz P max. 9 kW Connection of sauna heaters > 9 kW max. -
Page 14: Connecting The Sensor Lines
Connecting the sensor lines 2. Drill a hole to lead the cable through, pre- ferably through the middle of one of the ou should not install sensor and power sup- wooden boards. ply lines together, or lead them through the 3. -
Page 15: Installing The Optional Bench Sensor
Installing the optional bench sensor If there is a problem with the bench sensor, a fault message will appear: E 103 = Interruption bench sensor Installation location: The bench sensor is fi xed to the ceiling of the rear reclining bench as described for the installation of the heater E 104 = Short-circuit bench sensor sensor. -
Page 16: Connecting The Vaporizer
Connecting the vaporizer Fitting of the humidity sensor (optional) To connect the vaporizer, use silicon connecting lines 4 x 1,5 mm2 as well. The humidity sensor is fi tted in the centre of the sidewall facing away from the oven at a height of approximately Warning: When connecting the 150 cm. -
Page 17: Operation
Operation Button functions „ An/Aus „ „Licht „ „Funktion/ Mode„ „Ab „ „Auf „ Operating Lamp Program button Selection switch on - off on - off buttons Symbol description Time Heating and steam (2 phases + vaporizer) Pre-selected time Heating Heating time Ventilation function Steam operation... -
Page 18: Initial Unit Switch-On
Initial unit switch-on After you have checked all of the connections once again, connect the unit to the mains by switching on all fuses or the main switch. The time appears on the display. 20:03 If the display fl ashes, proceed as follows: 12:03 With the buttons "Ab "... -
Page 19: Preset Parameters
Preset parameters Finnish sauna mode After switching on, the display alternates 20:03 between showing the current time and the remaining heating time. 05:58 Temperature display During the heating phase plus approx. 15 min- utes, the thermometer symbol continues to fi ll. The control phase begins once the end tem- perature is reached. -
Page 20: To Consider When Programming
If the sauna bath should be fi nished before- hand, press the "An/Aus "button. The symbol distinguishes on the display and only 20:03 the current time is still displayed. The cabin lighting automatically switches off after 30 minutes. You can switch the lighting off at any time using the "licht "... -
Page 21: The Keylock / Hotel Mode
The keylock / hotel mode By activating the keylock / hotel mode, the sauna can only be switched on and off by the user. Changes to the individual parameters are not possible. To activate the keylock / hotel mode, press the "Mode", "... -
Page 22: Specialist Section
Specialist section F1 Setting the current time For clock time adjustment please press „Mode“ and „ “ button synchron. (In the display appears „F1“ and the clock symbol.) Please confi rm with the „Mode“ button. 20:03 Please chose the wished value with the 21:03 „... -
Page 23: F2 Programming The Reheating Period After Humid Operation
F2 Programming the reheating period after humid operation The heating time limiter is fi xed at 6 hours. For pre heating time adjustment please press „Mode“ and „ “ button synchron. (In the display appears „F1“ and the clock symbol.) Afterwards press „ „ button until „F2“... -
Page 24: F3 Programming The Reheating Temperature After Humid Operation
F3 Programming the reheating temperature after humid operation The factory sets the reheating temperature to 95°C. This means that after humid ope- ration the furnace heats up to 95°C during the pre-selected reheating time to dry the cubicle. For post heating temperature adjustment please press „Mode“... -
Page 25: F4 Programming The Reheating Period After Humid Operation
F4 Programming the reheating period after humid operation By default the water-defi cit safety shutoff is set to 2 minutes. This means, should your oven report a water-defi cit, you have 2 mi- nutes to refi ll it. If the water-defi cit warning runs for more than 2 minutes, the control unit shuts the entire sauna system off for safety reasons. -
Page 26: F5 Link Color Light Options With Heater
F5 Link color light options with heater In order to link the coloured light functions with the heater, press the "Funktion/Mode" and the "Auf " button at the same time ("F1" and the clock symbol appear on the display) and then the "Auf "... -
Page 27: F6 The Optional Humidity Sensor
F6 The optional humidity sensor To activate or deactivate the F2 humidity sensor (after new installation or after error) please press „Mode“ and „ “ button syn- chron. (In the display appears „F1“ and the clock symbol.) Afterwards press „ „ button until „F6“... -
Page 28: F8 The Optional Bench Sensor
F8 The optional bench sensor To activate or deactivate the bench sensor (after error) please press „Mode“ and „ “ button syn- chron. (In the display appears „F1“ and the clock symbol.) Afterwards press „ „ button until „F8“ in the display appears. Please confi... -
Page 29: F10 Reset Time From The Submenus
F10 Reset time from the submenus To set the reset time on submenus (the time after which the display automatically resets to the basic display), press the "Funktion/ Mode" and "Auf " buttons at the same time ("F1" and the clock symbol appear on the display) and then the "Auf "... -
Page 30: Programming Levels
Programming levels P1 Starting with the time preselection With time preselection, you may preselect the start of your sauna unit within 24 hours. Always make sure that there are no objects on the sauna unit before the heating process begins. Risk of fi re! In order to set the time preselection, please press the "Funktion/Mode"... -
Page 31: Deactivating The Time Preselection
Deactivating the time preselection In order to deactivate the time preselection, please press the "An/Aus " key. Then the sauna oven will be switched on, By pressing the "An/Aus " key again, the sauna oven is switched on. P2 Heating time limitation This program step will only appear if the device has not been prepared for the "Wochentimer"... -
Page 32: Activation Of The Weekly Timer
P0 Weekly timer This program step will only appear if the device has been prepared during installation for the "Wochentimer" mode. You can program up to 4 preselection times for each week day in the weekly timer menu. The heating time per preselection time can be between 30 minutes and 12 hours. After 12 hours, a heating break of 6 hours starts automatically. -
Page 33: P1 Starting With Time Preselection In Weekly Timer Mode
P1 Starting with time preselection in weekly timer mode Always make sure that there are no objects on the sauna unit before the heating process begins. Risk of fi re! In order to set the time preselection, please press the "Funktion/Mode" key. The prese- lection symbol and "P1"... - Page 34 If the control is running in moist mode (HCS 9003...,), the time set here is the total time including the reheating time set in F2. I f t h e h e a t i n g t i m e i s s e t t o t h e m a x i m u m v a l u e o f 1 2 h , a heating break of 6 h is switched on once this 12 h period has ended.
-
Page 35: P3 Humid Mode
P3 Humid mode For humidity operation adjustment please press „Mode“ button. Afterwards the „ „ button until in the display the humidity symbol and „P3“ appears. Please confi rm with the „Mode“ button. Please chose the wished value with the „ „... -
Page 36: Switching Back To Finnish Operation
Once the heating cycle ends, the unit au- tomatically starts the reheating program to dry out the cabin. The steam symbol 20:03 disappears and the operation symbol begins to blink. The display now alternates between the time of day and the remaining reheating time. Once the reheating cycle is over, the control 00:30 unit shuts down the system automatically. -
Page 37: P4 Humidity Setting
P4 Humidity setting The humidity is set by the factory to a value of 60% - if a humidity sensor is installed and acti- vated the desired, relative air humidity is set in % (target value). - if no humidity sensor is installed or it is de- activated the value set –... -
Page 38: P5 Temperature Setting
P5 Temperature setting Attention:Temperature range in Finnish operation 30-110 C in humidity operation 30-70 C The temperature is fi xed on 95C for Finnish operation and 60C for Humidity operation. For temperature adjustment please press „Mode“ button. Afterwards the „ „ button until in the display the heating symbol and „P5“... -
Page 39: P6 Programming Fan Operation
P6 Programming fan operation This control unit gives you the option of swit- ching on a fan (max. 100W) and setting the fan speed individually to one of 3 stages. The default setting is „no fan mode“. Only in post heating operation after operation humidity the fan is default on the maximum step. -
Page 40: P7 Ability To Dim The Cubicle Lights
P7 Ability to dim the cubicle lights Please note that this function may only be programmed in combination with incande- scent bulbs, we recommend to use special bulbs like baking oven bulbs.. No phospho- rous, energy-saving or gas discharge bulbs may be used. -
Page 41: Coloured Light (Optional)
Coloured light (optional) This programming option is only available if the coloured light module (item number 942761 / 944286 / 944834) has been installed. Switch off all power to the system before installing the coloured light mo- dule. You have the option of operating a coloured light device in your sauna using the HCS 9003 control unit. - Page 42 20:03 When the coloured light is switched on the screen also displays the fl ashing coloured light icon. blue The coloured light icon indicates the seg- ment for the colour that is currently lit. The colours are assigned as follows. green yellow If coloured light mode is to be switched off...
-
Page 43: P9 Setting The Time Interval For The Coloured Light
P9 Setting the time interval for the coloured light se t x This programming option gives you the option of automatically setting the length of time each collour is on. The fefault is one minute. You can set on-time to between 1 and maximum 10 minutes.. For shining period adjustment please press „Mode“... -
Page 44: The Control Unit Switch (Switch-Off)
The control unit switch (Switch- C o n t r o l u n i t off) switch = unit swit- The control unit switch can be found on the ched on top end of the unit. Using this switch, you can isolate the electronics from the mains supply in case of a breakdown. -
Page 45: Error Display
Error display In order to provide an immediate diagnosis for any errors that may occur, the following errors can be determined via on-screen error codes. Error code Error description E100 –Temperature sensor fault (no signal) E101 – Temperature sensor short circuit E103 –... -
Page 46: Service Address
Service Address: Outside of Germany please contact your EOS Saunatechnik GmbH specialist dealer in case of warranty claims. Adolf-Weiß-Straße 43 Direct warranty processing with our service 35759 Driedorf-Mademühlen, Germany department is in this case not possible. -
Page 47: Handling Procedures For Return Shipments (Rma) - Details For All Returns
Handling procedures for return shipments (RMA) - Details for all returns ! Dear customer we hope that you will rejoice in the ordered articles. Just in case that you are not entirely contented as an exeption, please follow the procedures specifi ed below.This enabling us to ensure a quick and smooth handling of the return shipment.
