- Page 1 Skytec Assembly and operating instruction Druck Nr. 29493765en 28.12...
-
Page 2: Table Of Contents
English Table of Contents Package contents ....................3 General safety precautions ..................3 Assembly of the control unit ..................3 Wall mounting....................3 Operation ........................4 Save the appointed time ...................5 Technical data ......................5 Switching to coin box operation ................6 Returning to timer operation ...................6 Connection diagram ....................7 Service Address: .....................8 Guarantee .......................8... -
Page 3: Package Contents
Package contents Assembly of the control unit (subject to change) Wall mounting Included with the control unit are: To mount the control unit, please follow the- se instructions: 1. A plastic bag with three 4 x 20 mm faste- ning screws, code 20011976 1. -
Page 4: Operation
3. Hang the control unit onto the 3 mm upper Upper mounting hole projecting screw. Screw the lower part of the housing onto the cabin wall using the lower threaded holes. Fig. 4 Lower mounting holes Fig. 4 Operation The radiator will be switched on by using the On/Off- switch (1) at the digital-timer. -
Page 5: Save The Appointed Time
Save the appointed time Tune the favoured time. Push the buttons (2) and (4) simultaneously (fi g. 6). Now the radiator is working as long as the appointed time is expired. ON/OFF In between it is not possible to shift the time, the bottons are blocked. -
Page 6: Switching To Coin Box Operation
Switching to coin box operation Returning to timer operation 2 persons are required for this procedure. The resetting is only possible, if the coinbox is separated and the wire jumper „L1-Time“ • When the coin box is not connected yet, is mounted (see connection diagram). -
Page 7: Connection Diagram
Connection diagram Steuerplatine/timer PCB Anschluss/connection InfraSky Fig. 10 Attention! according to the valid regulations, the electrical connection of the control box has to be carried out through the specia- list of an authorized electric shop. We would like to mention to the fact that in case of a warrenty claim, you are kind- ly requested to present a copy of the in- voice of the executive electric shop. -
Page 8: Service Address
Service Address: Outside of Germany please contact your EOS Saunatechnik GmbH specialist dealer in case of warranty claims. Adolf-Weiß-Straße 43 Direct warranty processing with our service 35759 Driedorf-Mademühlen, Germany department is in this case not possible. -
Page 9: Handling Procedures For Return Shipments (Rma) - Details For All Returns
Handling procedures for return shipments (RMA) - Details for all returns ! Dear customer we hope that you will rejoice in the ordered articles. Just in case that you are not entirely contented as an exeption, please follow the procedures specifi ed below.This enabling us to ensure a quick and smooth handling of the return shipment.
