RS Automation AnyTouch V8 Plus Series Operating Instructions Manual page 3

Notes on LCD
Tiny spots (dark or luminescent) may appear on the display due to the liquid crystal characteristics.
Please note that this is not a fault or malfunction of AnyTouch.
UL/c-UL Approval
The V808+ is UL/cUL-approved. (File No.: E150833 (UL508))
The V808+ conforms to the following two standards.
- UL508
- CSA-C22.2 No. 142-M1987 Process Control Equipment
UL Listing Application for a System Equipped with AnyTouch
The back panel of AnyTouch is not approved as an enclosure. For UL listing application, build AnyTouch in the system,
〇
and configure an enclosure so that the entire system will be UL-approved.
Use AnyTouch indoors only.
〇
Mount it on a flat surface so that it will comply with the enclosure type 1.
〇
Use a UL-approved crimp-style terminal for wiring of the power supply cable.
〇
Screw Size Tightening Torque
10.6 inch-lbf
M3.5
(1.2 N·m)
Use the Class 2 power supply for the 24-VDC power unit.
〇
CE Marking
The V808+ complies with EMC Directives.
EN61000-6-2, EN61000-6-4
Industrial Control Equipment
Crimp-style Terminal (Unit: mm)
3.7
7.1 or less
V808+ OPERATING INSTRUCTIONS
φ3.7
7.1 or less
3
Power Cable
AWG16 - AWG14
Rated temperature 60°C
Use copper conductor only.
