- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 101064 BAR UNIT REVISION 0 : 08/18/2017 REVISION 1 : 07/14/2020 REVISION 2 : 09/30/2020 PAGE 1 OF 8 COASTERFURNITURE.COM...
-
Page 2: Assembly Tips
101064 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly. -
Page 3: Hardware Identification
101064 ITEM: ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS PARTS IDENTIFICATION PARTS IDENTIFICATION GLASS HOLDER 2PCS BOTTOM STEEL GUARD BOTTLE GUARD 2PCS GLASS SHELF STEEL GUARD HARDWARE IDENTIFICATION CAM-BOLT SMALL BOLT 4PCS 2PCS (38mm) (5/16" x 50mm) CAM-LOCK ROUND IRON 4PCS 15mm) 63mm) ∅... - Page 4 101064 ITEM: ASSEMBLY INSTRUCTIONS HARDWARE IDENTIFICATION LARGE ALLEN BOLT SCREW 15PCS (5/16" x 63mm SR) (7#15mm) MEDIUM ALLEN BOLT SMALL ALLEN KEY (1/4" x 63mm SR) (4mm) SMALL ALLEN BOLT LARGE ALLEN KEY (5mm) (1/4" x 25mm SR) SPRING WASHER SMALL WASHER (5/16")
- Page 5 101064 ITEM: ASSEMBLY INSTRUCTIONS STEP 1 Do not tighten until each step is completed or instructed. AS #I BOTTLE GUARD CAN BE ASSEMBLED IN LEFT OR RIGHT SIDE, THE #G GLASS HOLDER ALSO CAN BE ASSEMBLED IN OTHER SIDE ACCORDINLY.
- Page 6 101064 ITEM: ASSEMBLY INSTRUCTIONS STEP 3 LEFT RIGHT PAGE 6 OF 8 COASTERFURNITURE.COM...
- Page 7 101064 ITEM: ASSEMBLY INSTRUCTIONS STEP 4 LEFT RIGHT STEP 5 COMPLETE LEFT RIGHT I can be placed either way to suit the indivdual's needs. PAGE 7 OF 8 COASTERFURNITURE.COM...
- Page 8 101064 ITEM: ASSEMBLY INSTRUCTIONS Product Size : 1000 X 400 X 1047 H (MM) Product Size : 39 " X 15 " X 41 " 420 mm 400 mm 950 mm " " " 1047 mm 330 mm " 13"...
