Hot Rod Delivery Sedan
"Dave's Speed Shop"
Vehicles like the Sedan Delivery, the commercial work trucks of their era, were found to be ideal hot rods
presenting unique features and plenty of interior room. The same talents used to "soup up" cheap roadsters
proved just as appropriate for the sedan delivery and Hot Rod parts improved both looks and performance.
Few cars were better suited for customizing and they remain popular hot rods today.
This new Minicraft Sedan Delivery features a hot rod flat head V-8 engine; triple carburetors, custom
exhaust, and "racing" rear axle custom wheels and wide custom tires and new custom decals. This kit
includes unique operating futures like opening doors and interior.
Enjoy building the Sedan Delivery and thanks for your purchase of this Minicraft Models model kit!
Minicraft Models, 1501 Commerce Drive, Elgin IL 60123 USA
www.minicraftmodels.com
Printed in China
11233
Advertisement
Related Manuals for MINICRAFT 11233
Summary of Contents for MINICRAFT 11233
- Page 1 Few cars were better suited for customizing and they remain popular hot rods today. This new Minicraft Sedan Delivery features a hot rod flat head V-8 engine; triple carburetors, custom exhaust, and “racing” rear axle custom wheels and wide custom tires and new custom decals. This kit includes unique operating futures like opening doors and interior.
- Page 2 Sprue E Sprue B Sprue C (Fenders) 14 13 NOTE Parts shown Sprue F shaded are not for use. Sprue F Sprue A Sprue C Sprue P (Chromed) Sprue P 11233...
- Page 3 Sprue G Sprue J (Chromed) NOTE Parts shown shaded are not for use Sprue I (Clear) Sprue S (Chromed) Sprue H Sprue Q (Chromed) Rivets Axle Hinge Pins Sprue D Sprue Q (Chromed) NOTE - These parts NOT Chromed 11233...
-
Page 4: Before Beginning Assembly
BEFORE BEGINNING ASSEMBLY Your MINICRAFT Flathead Delivery model contains a wealth of highly detailed parts. Please take a moment to read the instruction sheet to become familiar with the parts before beginning assembly. Cement DO NOTCement Optional Cut away Repeat operation... -
Page 5: Important Note
IMPORTANT NOTE Exhausts may be positioned to exit either under the car, or out the sides of the engine compartment. To exit downward, place parts P(9/10) as shown. To exit from the sides, exchange parts so P(9) is placed on the left side, and part P(10) is placed on the right side. - Page 6 Note tab alignment to part 52 when assembled. Cement parts (52/53) together. Pass rear axle assembly through hole Assemble rear axle halves (61/63), trapping metal in differential/driveshaft housing (52/53), aligning the small tab with slot axle between. on part 52. NOTE: All parts are shown upside down.
- Page 7 PLEASE NOTE It is especially important to check the fit of the custom chromed parts in the following steps. Additional sanding may be necessary due to the extra thickness of the chrome finish. Check all locating holes and open as necessary Slip rear tire T(1) over rear wheel S(1) (wider opening faces in to match tire), then glue brake drum Q(55) to inner face of wheel.
- Page 8 Note alignment (viewed from front). Slip front tire T(2) over front wheel S(2) (rounded outer edge faces out) then glue brake drum Q(38) to inner face of wheel. Pass stub axle of part (Q)37 through this assembly, then glue to knock-off hub S(3). Cement support arms Q(34/30) to part (Q)37.
- Page 9 PLEASE NOTE Be sure to test the fit of parts Q(33/35) in the respective holes in mating parts. Non-glued parts should move easily for proper movement of operable features. NOTE: All parts shown upside down. NOTE: All parts shown upside down. Front suspension parts not shown Snap wheel assembly onto stubs.
- Page 10 NOTE: All parts are shown upside down. Glue brace (65) in place, attaching to stubs on forward crossbeam and also to the stub on the oil pan. NOTE Installed engine not shown for clarity. Seat must fold. Install seats as shown by sliding into holes in floor (do not glue). Assemble two front seats as shown.
-
Page 11: Right Door
Drill holes in hinges C(11) and C(12) as shown to match C(10/13) pins. Cement window I(5) to door C(16). Glue Slide (do not glue) hinges C(11/12) onto door hinge pins. Tape interior panel C(15) to door. Attach hinges C(10), door in closed position, then glue C(11/12) to body. Do not allow C(13) and C(14) and handle F(33) to door. - Page 12 Tape doors to body in closed position. Cement body to chassis, passing the steering linkage through hole in firewall and aligning the linkage with the small indentation under the dash. Do not allow glue to touch doors. Remove left (driver's) door. Cement steering wheel parts J(13/14/27) as shown and cement to steering linkage.
- Page 13 Glue door handles J(29) to left and right doors. Carefully glue lenses I(3) to headlamp frame J(10) and glue to attachment points on front fenders. You may optionally use license plate frame H(19) for the rear or use frame H(20) for a front-mounted license plate.
-
Page 14: Visit Our Website
Your Minicraft model includes high-quality waterslide decals. These decals adhere best to a glossy surface; and it is recommended that you apply a clear gloss coat over your painted model. Use a sharp scissors or knife to cut individual decals from the carrier sheet. Do not cut into the clear film surrounding the individual decals.
