Specifications - Heart Interface LINK 2000 Owner's Manual

TABLE OF CONTENTS
One Page Summary of Features
Introduction and Special Notes
Monitor Functions
Inverter and Charger Functions
Status Line and Starting and Stopping Equalize
Set Up
Inverter Set Up
Monitor Set Up
Functions Set Up
Data
How to Use Link 2000 Meters
Ideal Charge Curve
Synchronizing to a Full Battery (Resetting A hrs to Zero)
Selecting The Charged Parameters
Selection Rules
Advanced Functions
High Discharge Rates and Peukert's Equation
Typical Peukert's Exponents
Error Codes and Trouble shooting
Microprocessor Reset Procedure (Resetting to Factor Defaults)
Summary of Set Up & Historical Values
Warranty
Required Reading Prior to Installation
Wire By Wire Instructions
Wiring Diagrams
Supply Voltage
Supply Current
Voltage Range
Voltage Resolution
Voltage Accuracy
Current Range
Current Resolution
Current Accuracy
Current Shunt
Amp Hour Range
Amp Hour Accuracy
Time Remaining Range
Charger Voltage Regulation
Cut out size:
Panel size:
Weight:
2

SPECIFICATIONS

9-40 Volts DC (Not for use with 32V Systems)
28mA (Typical)
Backlight adds 1 to 18mA (Depends on intensity setting)
8.5-50 Volts DC
0.05 Volts DC
+ 0.10 Volts DC at full scale.
+ 500 Amps DC
0.1 Amp DC (From 0 to + 42.0 Amps)
1 Amp DC (From + 42 to + 500)
+ 0.1 Amp DC at full scale low range
+ 1 Amp DC at full scale high range
+ 0.25% Ratio 50mV @ 500A
+ 9,999 Amp Hours
~ Time of Measurement x Current Error
255 Hours maximum
+ 0.2 Volts DC
4.75" x 2.75"
5.75" x 3.75"
Meter 9 oz.; Shunt 20 oz
5/31/96
Center
Page 3
Page 4-5
Page 5
Page 6
Page 7
Page 8
Page 9
Page 10-14
Page 15
Page 16-17
Page 18
Page 19-20
Page 21
Page 22
Page 23
Page 24-25
Page 26-27
Page 28-29
Page 30-31
Page 32
Page 33
Page 34
Page 35-36
