Kebo F-9621-3 Manual

Lavatory faucet
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
et.
12
entation
s
12
ation
tation
Tools You May Need
Outils requis
Adjustable wrench
Clé à molette
Groove joint plier
Pinces multiprises
Pipe tape
Ruban teflon
Allen key
Clé hexagonale
For more information , visit our web site
Pour plus d'information, visitez notre site web
F-9621-3
LAVATORY FAUCET
Solid brass construction,
Ceramic cartridge,
Deluxe finish,
Mechanical pop-up included,
Fits sink with 1-Hole or 3-Hole with 4" center,
Cartridge with limited lifetime warranty,
Easy installation.
ROBINET DE LAVABO
Construction de laiton solide,
Cartouche de céramique,
Fini luxueux,
Bonde mécanique incluse,
Adatable aux éviers percés 1 trou ou 3 trous 4" centre,
Garantie à vie limitée sur les cartouches,
Installation simple.
1 GPM = 3.785 LPM
PSI
L/MIN 2.1
Because of difference of city
water system or others,
water pressure may differ, and
cause the flow rate to
change a little bit.
En raison des différences entre
les systèmes d'eau de ville
ou autre, la pression d'eau
peut varier et provoquer un
léger changement dans le débit.
Flow rate chart
Diagramme de débit
8
7
6
5
4
3
2
10
20
30
40
50
60
80
70
Flow pressure in PSI / Volume de débit en PSI
10
20
30
40
50
60
70
80
3.3
4.3
5.1
5.8
6.5
7.0
7.6
www.kebofaucet.com
www.kebofaucet.com
03/08/16 Rev.A

Advertisement

loading
Need help?

Need help?

Do you have a question about the F-9621-3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kebo F-9621-3

Summary of Contents for Kebo F-9621-3

  • Page 1 F-9621-3 LAVATORY FAUCET Solid brass construction, Ceramic cartridge, Deluxe finish, Mechanical pop-up included, Fits sink with 1-Hole or 3-Hole with 4" center, Cartridge with limited lifetime warranty, entation Easy installation. ROBINET DE LAVABO Construction de laiton solide, Cartouche de céramique, Fini luxueux, Bonde mécanique incluse,...
  • Page 2 Brass pop-up installation / Installation de la bonde mécanique Flange Coupole 1. Install plastic washer, rubber washer and lock nut onto pop-up body from basin underneath. Insert flange and gasket into basin and then screw flange to connect with pop-up body.
  • Page 3 Replacement parts / Pièces de remplacement Faucet Spec 1 23 Spécification du robinet p-up RP-CART25HB-SD Description Quantity Factory No. RP No. Numéro Description Quantité Numéro d'usine Numéro de RP. Button / Bouton 1C00045NC Allen screw / Vis hexagonale 1L20001NT Handle / Poignée 1H01161CP Cap / Coupole de finition 40FB40079CP...
  • Page 4 1. Place rubber washer(9) below faucet. Faucet Screw hot hose(22) and cold hose(21) on the faucet. Robinet And then put them into the hole. Hole size / Grandeur du trou Placer le joint d’étanchéité(9) dessous robinet. Visser le tuyau chaud(22) et le tuyau de froid(21) sur le robinet. Et puis les mettre dans le trou.

  • Page 5: Limited Warranty

    To whom does this warranty apply? KEBO offers a 25-year limited warranty from the date of purchase, exclusive to the first buyer as long as he/she resides in the same property. The warranty applies to single-hole, 4", 8", bathtub, tub-shower, kitchen and shower faucets. The warranty is intended for residential and/or domestic use.

  • Page 6: Garantie Limitée

    À qui la garantie s’applique-t-elle? KEBO offre une garantie limitée de 25 ans à partir de la date d’achat, exclusive au premier acheteur et tant qu’il réside dans la propriété. Cette garantie s’applique aux robinets monotrou, 4’’, 8’’, aux robinets de bain, de bain-douche, de cuisine ainsi qu’à la robinetterie de douche. La garantie est destinée à...
