Assembly Instructions

For more information contact our team: service.ec@foagroup.com

CM3452T

ASSEMBLY RATING

Tools Required For Assembly:

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

Allen Wrench

easy and 5 being difficult). For some

(Included)

products, two persons are recommended.

DIFFICULT

EASY

2 PERSONS RECOMMENDED

Page 1 of 5

Rev: 18-08-17

Need help?

Do you have a question about the CM3452T and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3452T ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 8pcs #1 x 1pc Table Top Bolt Ø5/16" x 3'' #B x 8pcs #2 x 4pcs Table Leg Spring Washer Ø5/16"...
Page 4 #A x 8pcs #B x 8pcs #C x 8pcs Align legs (#2) to the top (#1), then secure by using bolts (#A) with washers (#B,C). OPEN Turn lever on bottom of table to open, then extend the table and place leaf (#3) onto table. Page 4 of 5...
Page 5 Turn lever to lock, then carefully place glass (#4) onto table top (#1). LOCK Use suction cups (#E) on glass (#4) to lift up glass (#4). #E x 2pcs ASSEMBLY IS COMPLETED Page 5 of 5...
