OWNER'S MANUAL
MANUAL DEL USUARIO
Tulsa LED
Please write model number here for future reference: /
Por favor, incluya el número del modelo aquí para futura referencia:
Net Weight:
Peso Neto:
1
ETL-ES-Tulsa LED-WH20
19.69 LBS
8.95 KGS

Advertisement

loading
Need help?

Need help?

Do you have a question about the ETL-ES-Tulsa LED-WH20 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Westinghouse ETL-ES-Tulsa LED-WH20

Summary of Contents for Westinghouse ETL-ES-Tulsa LED-WH20

  • Page 1 ETL-ES-Tulsa LED-WH20 OWNER'S MANUAL MANUAL DEL USUARIO Tulsa LED Please write model number here for future reference: / Por favor, incluya el número del modelo aquí para futura referencia: Net Weight: 19.69 LBS Peso Neto: 8.95 KGS...

  • Page 2: Safety Tips

    ETL-ES-Tulsa LED-WH20 SAFETY TIPS OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL INJURY, MOUNT TO OUTLET BOX MARKED 'ACCEPTABLE FOR FAN SUPPORT OF 35 LBS (15.9 KG) OR LESS' AND USE MOUNTING SCREWS PROVIDED WITH THE OUTLET BOX AND/OR SUPPORT DIRECTLY FROM BUILDING STRUCTURE.

  • Page 3: Consejos De Seguridad

    ETL-ES-Tulsa LED-WH20 CONSEJOS DE SEGURIDAD HAGA LO SIGUIENTE: LEA Y GUARDE ESTAS INSTRUCCIONES ADVERTENCIA: PARA REDUCIR EL RIESGO DE INCENDIO, DESCARGA ELÉCTRICA O HERIDAS GRAVES PERSONALES, MONTE EN UNA CAJA DE EMBUTIR ROTULADA “ADECUADA PARA VENTILADORES DE 35 LBS (15,9 KG) O MENOS”...
  • Page 4 ETL-ES-Tulsa LED-WH20 FEATURES CARACTERÍSTICAS SLOPED CEILING DOWNROD INSTALLATION INSTALLATION FLUSH MOUNT INSTALLATION INSTALACIÓN PARA INSTALACIÓN CON INSTALACIÓN AL TECHO VARILLA VERTICAL TECHO INCLINADOS For low ceilings For normal ceilings May require a longer downrod (sold separately) Para techo bajos Para techo normales Podría requerir una varilla vertical más larga...
  • Page 5 ETL-ES-Tulsa LED-WH20 FEATURES CARACTERÍSTICAS COMBO-BLADE Combo-Blades feature two high quality finishes on one blade. Select the one that best complements your decor, or change the style with just a flip of the blade. NOTE: Combo-Blade finishes vary, depending upon model.
  • Page 6 ETL-ES-Tulsa LED-WH20 PREPARING FOR INSTALLATION ANTES DE LA INSTALACIÓN Use metal outlet box suitable for fan support (must support 35 lbs). Before attaching fan to outlet box, ensure the outlet box is securely fastened by at least two points to a structural ceiling member (a loose box will cause the fan to wobble).
  • Page 7 ETL-ES-Tulsa LED-WH20 MOUNTING BRACKET INSTALLATION INSTALACIÓN CON SOPORTE DE MONTAJE Remove the screws and star washers from the two mating holes (2) on the canopy. Loosen (do not remove) the screws in the mating slots (1) on the canopy. Rotate the mounting bracket and remove from the canopy.
  • Page 8 ETL-ES-Tulsa LED-WH20 MOUNTING BRACKET INSTALLATION MOUNTING OPTIONS INSTALACIÓN CON SOPORTE OPCIONES DE MONTAJE DE MONTAJE Choose a MOUNTING OPTION Elija una OPCIÓN DE MONTAJE FLUSH MOUNT OPTION If flush mount option is selected, proceed to page 9, step 6. OPCIÓN DE INSTALACIÓN AL TECHO Si elige la opción de montaje al techo,...
  • Page 9 ETL-ES-Tulsa LED-WH20 FLUSH MOUNT OPTION OPCIÓN DE INSTALACIÓN AL TECHO For flush mount option, raise fan assembly and place onto hook (1) from mount- ing bracket into a closed hole on the canopy. This will allow for hands free wiring.
  • Page 10 ETL-ES-Tulsa LED-WH20 NORMAL DOWNROD OPTION OPCIÓN CON VARILLA VERTICAL PARA TECHO NORMAL Place downrod assembly (1) into canopy (2) and coupling cover (3). Feed motor wires though the downrod assembly (1) from the bottom upwards. Coloque el conjunto de la varilla vertical (1) dentro del dosel (2) y la cubierta del acopla- Remove clamp pin (1) and cross pin (2) from downrod (3).
  • Page 11 ETL-ES-Tulsa LED-WH20 NORMAL DOWNROD OPTION OPCIÓN CON VARILLA VERTICAL PARA TECHO NORMAL If necessary, loosen set screws in downrod coupling. Insert downrod into downrod coupling. Make sure to align hole in downrod with the hole in downrod coupling. Install cross pin (1) through coupling and downrod.
  • Page 12 ETL-ES-Tulsa LED-WH20 EXTENDED DOWNROD OPTION OPCIÓN CON VARILLA VERTICAL MÁS LARGA Slide downrod ball (1) off of downrod and remove pin (2). Loosen (1) from downrod (2) by removing set screw (3). Deslice la bola de la varilla vertical (1) hasta separarla de la varilla vertical y Afloje la bola de la varilla vertical (1) de la varilla vertical (2) quitando quite el pasador (2).
  • Page 13 ETL-ES-Tulsa LED-WH20 EXTENDED DOWNROD OPTION OPCIÓN CON VARILLA VERTICAL MÁS LARGA Re-install pin into extended downrod, and slide downrod ball up to the top of the downrod. Re-install set screw to secure ball to downrod. Note: Some extended downrods have a pre-drilled set-screw hole. If a pre-drilled hole is present in the extended downrod, tighten the set screw into the pre-drilled hole in the extended downrod. If no pre-drilled hole exists in the extended downrod, tighten the set screw against the downrod to secure the downrod ball.
  • Page 14 ETL-ES-Tulsa LED-WH20 MOUNTING MONTAJE Carefully lift fan assembly onto mounting bracket. Rotate fan until notch on downrod ball (1) engages the ridge on the mounting bracket (2). This will allow for hands free wiring. With bracket holding fan assembly, make electrical connections using the following Levante con cuidado el conjunto del ventilador hasta el soporte de montaje.
  • Page 15 ETL-ES-Tulsa LED-WH20 WIRING OPTIONS OPCIÓN DE CABLEADO PULL CHAIN WIRING OPTION WALL CONTROL WIRING OPTION *Connect blue wire only if attaching light kit with fan. *Connect blue wire only if attaching light kit with fan. Follow diagram above to make wiring connections for fan pull chain control.
  • Page 16 ETL-ES-Tulsa LED-WH20 SECURE TO CEILING ASEGURE EL VENTILADOR AL TECHO For flush mount fans, carefully lift fan from the mounting bracket, making sure not to break any wire connections. For downrod fans, slide the canopy up to the mounting bracket.
  • Page 17 ETL-ES-Tulsa LED-WH20 BLADE INSTALLATION INSTALACIÓN DE LAS ALETAS If plastic shipping stabilizer tabs are attached to motor, remove and discard. Attach blade assembly to motor using the noise-dampening motor gaskets and motor screws provided. Tighten screws securely. NOTE: Some models do not utilize motor gaskets, washers, or stabilizer tabs.
  • Page 18 ETL-ES-Tulsa LED-WH20 LIGHT FIXTURE INSTALLATION INSTALACIÓN DEL ARTEFACTO LUMINOSO Find the wire plugs from the light kit and from the motor and slide together. Connect the blue wire from the switch housing, to the black wire from the light kit, and the white wire from the switch housing to the white wire from the light kit align the notch on the light kit with the reverse switch on the switch housing.
  • Page 19 ETL-ES-Tulsa LED-WH20 LIGHT FIXTURE INSTALLATION INSTALACIÓN DEL ARTEFACTO LUMINOSO Unscrew and remove the finial (1), decorative cap (2), nut (3), and rubber/metal washer (4) from the bottom of the light kit. Install the bulbs (included). Desenrosque y quite el florón (1), la tapa decorativa (2), la tuerca (3) y la arandela de caucho/metal (4) de la parte inferior del juego de luces. Instale las bombillas de luz...
  • Page 20 ETL-ES-Tulsa LED-WH20 Install the glass (5) onto the light kit and tighten the washer (4) and nut (3) onto the bottom of glass. Make sure the ceiling fan pull chain is threaded through the side hole in the bottom of the glass. Place decorative cap (2) over the bottom of glass and secure by tightening decorative finial (1).
