MULTILIFT XR S
Hooklift XR2S / XR3S / XR5S
USER AND MAINTENANCE MANUAL
110817116/US
4/2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hooklift Multilift XR S Series and is the answer not in the manual?

Questions and answers

Related Manuals for HIAB Hooklift Multilift XR S Series

Summary of Contents for HIAB Hooklift Multilift XR S Series

  • Page 1 MULTILIFT XR S Hooklift XR2S / XR3S / XR5S USER AND MAINTENANCE MANUAL 110817116/US 4/2019...
  • Page 2 This manual is a translation from the original operating instructions compiled in Finnish.

  • Page 3: Table Of Contents

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Contents MULTILIFT XR2S, XR3S AND XR5S HOOKLIFT ............5 Preface..........................6 Main components ......................7 Control unit ........................8 Safety instructions and safety rules ................10 Safety during use - general .................... 10 Requirements for the working area ground condition .............
  • Page 4 Hooklift Multilift XR2S / XR3S / XR5S User Manual >>> Hook models........................52 Locking mechanisms of the hook ................... 53 Electric system ....................... 57 Additional equipments ....................58 Additional hydraulics....................... 58 MAINTENANCE ......................60 Service table ........................64 Hydraulics service ......................66 Safety functions ......................

  • Page 5: Multilift Xr2S, Xr3S And Xr5S Hooklift

    Hooklift Multilift XR2S / XR3S / XR5S User Manual MULTILIFT XR2S, XR3S AND XR5S HOOKLIFT User Manual This manual concerns the MULTILIFT XR2S, XR3S and XR5S hooklift equipment. Information about the equipment. Type of system: XR2S XR3S XR5S Serial number: Date of commissioning: Owner Your Multilift dealer...

  • Page 6: Preface

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Rakenne Koukkulaite XR - S Käyttöohjekirja Rakenne Preface Yleistä The XR S hooklift equipment is designed for manipulations with swap truck bodies under the standard SFS 4417 only. The hooklift equipment complies with the requirements of the XR-S koukkulaite on suunniteltu standardin mukaisten vaihtokuormatilojen EU Machinery Directive and has the CE marking.

  • Page 7: Main Components

    Koukkulaite on rakennettu apurungolle, joka on kiinnitetty ajoneuvon runkoo kiinnityslevyillä. Takarunko on laakeroitu apurungon takapäähän takarullien Hooklift Multilift XR2S / XR3S / XR5S akseleilla. Takarullat ohjaavat ja keventävät vaihtokuormatilan kulkua User Manual päällevedon ja maahanlaskun aikana. Laitteessa on takarunkoon asennettu mekaaniset lavalukkokoukut ja mahdollisesti lisävarusteena saatava hydraulinen lavalukko.

  • Page 8: Control Unit

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Control unit Control unit Control unit Control unit basic version basic version with options XR S equipment with all options XR2S/XR3S/XR5S 110817116 4/2019...
  • Page 9 Hooklift Multilift XR2S / XR3S / XR5S User Manual Control unit components and basic functions Ref. Component or function Control unit cable Rocker switch MAIN CYLINDERS a main cylinders forward b main cylinders backward Rocker switch HOOK ARM a hook arm forward b hook arm backward Button SLOW SPEED Warning light FRAME NOT DOWN...

  • Page 10: Safety Instructions And Safety Rules

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Safety instructions and safety rules MULTILIFT XR hooklift equipment was developed for the loading, unloading, tipping and transporting of removable containers/bodies on vehicles. All other use of the Multilift hooklift equipment is strictly forbidden. Multilift accepts no liability whatsoever with regard to such other use.
  • Page 11 Hooklift Multilift XR2S / XR3S / XR5S User Manual Avoid the unnecessary use of the main pressure relief valve. Heating up of the oil reduces the quality of it and results in shorter life span of retaining rings and gaskets. In subzero temperatures (<32°F) it is recommended to let the pump idle for around 1 minute in order for the hydraulic oil to be warmed up.

  • Page 12: Requirements For The Working Area Ground Condition

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Requirements for the working area ground condition Before you start loading, unloading or tipping using the XR hooklift equipment, you must inspect the following: the ground must be firm and free from potholes into which the truck could move during operation ·...

  • Page 13: Working Area

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Working area Load or unload only where there is sufficient space; this also applies to free height. There must be at least 33 ft (10 m) free space at both sides of the vehicle. Check the vicinity for possible dangers.
  • Page 14 Hooklift Multilift XR2S / XR3S / XR5S User Manual It is the responsibility of the driver to ensure that there are or there will be no other persons within the danger zone of the working area. It is strictly forbidden for anybody to be close to the truck or the container.

  • Page 15: Safety Instructions And Maintenance

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Safety instructions and maintenance Always follow the maintenance instructions and use only original Multilift spare parts. See chapter Maintenance. Container The demountable body can be a container, tank, gravel body, body for transporting machinery etc.
  • Page 16 Hooklift Multilift XR2S / XR3S / XR5S User Manual Gripping height (H), tunnel height (T) and width (W) of the container can vary from one container to another. Note that they are country specific dimensions. If there is doubt about the origin of the container, the tunnel height and width must be checked in order to ensure that they are compatible with those of the XR equipment.

  • Page 17: Loading And Unloading Of A Container

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Loading and unloading of a container Ensure before loading that the length of the container is suitable for your XR hooklift equipment Loading of a balanced container requires special care. Never load, unload or tip a container when the load is heavier to one side or the ground is sloping.
  • Page 18 Hooklift Multilift XR2S / XR3S / XR5S User Manual Ensure that the load´s centre of gravity is as low as possible and that it is in the middle of the container and evenly distributed. If the load must be secured, do this when the container is on the ground.
  • Page 19 Hooklift Multilift XR2S / XR3S / XR5S User Manual Before picking up the container, the gripping bar of the container must be properly inside the lifting hook. In this way you prevent the container from falling. The situation must be checked by lifting the container approx.
  • Page 20 Hooklift Multilift XR2S / XR3S / XR5S User Manual The operation of the hooklift must take place in the correct sequence, one operation at the time. The handbrake of the vehicle must be activated during the loading and unloading operation. When loading, unloading or tipping a container, check that there are no people too close to the operation, and check for any possible unusual or disruptive movements or sounds caused by the container.

  • Page 21: Tipping

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Tipping Please, check before tipping that the horizontal shift has completely moved forward. If the container overhang is too much, the rear end of the container will touch the ground when tipping and the container, truck or hooklift equipment will be damaged. In very cold weather the load might freeze tight on the container.
  • Page 22 Hooklift Multilift XR2S / XR3S / XR5S User Manual NEVER TIP UNDER THE FOLLOWING CIRCUMSTANCES: • Container is top heavy at the front end or at either side. • Load is frozen or only partially loose • Ground is slippery or uneven •...

  • Page 23: Before Driving Away

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Before driving away Before you drive off, always check the following: • Hydraulic body locks must be closed. The locking hooks must be tight on the container, i.e. on the lower flange of the container frame beams or in the specific notches (if provided).

  • Page 24: Safety Facilities Of The Xr Hooklift Equipment

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Safety facilities of the XR hooklift equipment To increase safety, the control system has safety features to prevent incorrect movements of the body so that the load can be kept under control. The hydraulic cylinders are provided with load holding valves that ensure a controlled movement of the XR equipment.

  • Page 25: Use

    Hooklift Multilift XR2S / XR3S / XR5S User Manual 4/2019 110817116 XR2S/XR3S/XR5S...
  • Page 26 Hooklift Multilift XR2S / XR3S / XR5S User Manual 10 ft (3 m) OPEN XR2S/XR3S/XR5S 110817116 4/2019...

  • Page 27: Loading A Container

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Loading a container See the safety instructions before loading. Reverse the truck carefully close to the container. Stop it about 10 ft (3 meters) from the container gripping bar. Check in the rear-view mirrors that the vehicle is aligned with the container. Engage the parking brake.
  • Page 28 Hooklift Multilift XR2S / XR3S / XR5S User Manual XR2S/XR3S/XR5S 110817116 4/2019...
  • Page 29 Hooklift Multilift XR2S / XR3S / XR5S User Manual Move the hook arm / middle frame towards the container - use the control switch 2 (main cylinders out) - signal light 5 lights (frame not down). Stop the movement when the hook opening is on the same level with the container gripping bar.
  • Page 30 Hooklift Multilift XR2S / XR3S / XR5S User Manual CLOSE XR2S/XR3S/XR5S 110817116 4/2019...
  • Page 31 Hooklift Multilift XR2S / XR3S / XR5S User Manual 14. Pull the container fully on the truck chassis - the control switch 2 is in main cylinders in -position - signal light 5 (frame not down) goes off as the body is lowering onto the subframe.
  • Page 32 Hooklift Multilift XR2S / XR3S / XR5S User Manual SECURE XR2S/XR3S/XR5S 110817116 4/2019...

  • Page 33: Tipping A Container

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Tipping a container See the safety instructions before tipping. Drive the truck to the place where the load has to be discharged. Engage the parking brake. Press the clutch pedal and engage the PTO - use control switch 10 (option).
  • Page 34 Hooklift Multilift XR2S / XR3S / XR5S User Manual XR2S/XR3S/XR5S 110817116 4/2019...

  • Page 35: Lowering The Tipping Device

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Decrease the speed of tipping movement to prevent an abrupt stop during the last tipping phase. Release the parking brake and drive, if needed, a little forward in order to empty the complete contents of the container. 10.
  • Page 36 Hooklift Multilift XR2S / XR3S / XR5S User Manual OPEN XR2S/XR3S/XR5S 110817116 4/2019...

  • Page 37: Unloading A Container

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Unloading a container See the safety instructions before unloading. Drive the truck to the place where the container has to be unloaded. Check the working area. Ensure that there is enough space in front, rear and above the truck. Engage the parking brake.
  • Page 38 Hooklift Multilift XR2S / XR3S / XR5S User Manual XR2S/XR3S/XR5S 110817116 4/2019...
  • Page 39 Hooklift Multilift XR2S / XR3S / XR5S User Manual Move the hook arm / middle frame together with the container backwards - use the control switch 2 (main cylinders out) - signal light 5 lights (frame not down). Stop the movement when the container is completely on the ground. 10.
  • Page 40 Hooklift Multilift XR2S / XR3S / XR5S User Manual CLOSE XR2S/XR3S/XR5S 110817116 4/2019...
  • Page 41 Hooklift Multilift XR2S / XR3S / XR5S User Manual 15. Move the hook arm forward. - use the control switch 3 (hook arm forward). Movement will close also the mechanical tipping lock. 16. Close the hydraulic body locks - use the control switch 6 (hydraulic locks closed) - signal light 7 (hydraulic body locks not closed) goes off as the locks are closed.
  • Page 42 Hooklift Multilift XR2S / XR3S / XR5S User Manual XR2S/XR3S/XR5S 110817116 4/2019...

  • Page 43: Loading Of Rear Heavy Container

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Loading of rear heavy container A container loaded more heavily at the rear end can cause the truck front wheels to be lifted of the ground. Be extra cautious when this happens. When the container is on rear rollers, move the hook arm forward before lowering the middle frame on the sub-frame.

  • Page 44: Technical Specifications

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Technical specifications Hooklift XR2S, XR3S Manufacturer ........ Multilift, Raisio XR2S XR2S XR3S XR3S Equipment type ............Technical performance, max......lbs 4400 6600 ......(t) Tipping angle, max..........(°) Working pressure of the hydr. system max..psi 18 (180) 2610 25 (250)
  • Page 45 Hooklift Multilift XR2S / XR3S / XR5S User Manual XR2S, XR3S dimensions 2.4 in (61) XR2S, XR3S XR2S, XR3S 2700 2700 2950 2950 3200 3200 G (mm) 2700 2950 3200 G in (mm) 106.3 (2700) 116.1 (2950) 126 (3200) HM (mm) HM in (mm) 19.6 (500) 19.6 (500)
  • Page 46 Hooklift Multilift XR2S / XR3S / XR5S User Manual Hooklift XR5S Manufacturer ........ Multilift, Raisio XR5S Equipment type ............XR5S Technical performance, max......lbs 11000 ......(t) Tipping angle, max..........(°) Working pressure of the hydr. system max..psi XR5S 3250 / 3650: 4060 (28) XR5S 3250 / 3650: 28 (280) ..
  • Page 47 Hooklift Multilift XR2S / XR3S / XR5S User Manual XR5S dimensions 3.1 in XR5S XR5S 3250 3250 3650 3650 4150 4150 G (mm) 3250 3650 4150 G in (mm) 128 (3250) 143.7 (3650) 163.4 (4150) HM (mm) HM in (mm) 23.6 (600) 27.5 (700) 31.5 (800)

  • Page 48: Main Components

    Koukkulaite on rakennettu apurungolle, joka on kiinnitetty ajoneuvon runkoon kiinnityslevyillä. Takarunko on laakeroitu apurungon takapäähän takarullien akseleilla. Takarullat ohjaavat ja keventävät vaihtokuormatilan kulkua päällevedon ja maahanlaskun aikana. Hooklift Multilift XR2S / XR3S / XR5S Laitteessa on takarunkoon asennettu mekaaniset lavalukkokoukut ja User Manual mahdollisesti lisävarusteena saatava hydraulinen lavalukko.

  • Page 49: Construction

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Construction The hooklift equipment is built on a subframe, which is attached to the vehicle frame by fastening plates. The rear frame is bearing-mounted with axles of rear rollers at the rear end of the subframe.

  • Page 50: Hydraulic System

    Hooklift Multilift XR2S / XR3S / XR5S Rakenne Koukkulaite XR - S Käyttöohjekirja User Manual Hydraulijärjestelmä Hydraulic system Yleistä Hydraulijärjestelmän komponentit on esitetty kuvassa alla. The hydraulic system consists of components as shown in the picture below. Huom! Hydraulipumppu on ajoneuvoon kiinnitetty varuste eikä sitä esitetä Note! The hydraulic pump is located on the vehicle and ais not shown in the picture.
  • Page 51 portissa A ei hydraulipainetta rajoiteta • Kolmas venttiili on pääsylinterin ohjausventtiili. Portissa A ei hydraulipainetta rajoiteta, Portissa B on sylinterin pohjanpuoleinen paine rajoitettu 20, 22, 2, 28 or 0 MPa:iin (200, 220, 20, 280 tai 00 bar). Hooklift Multilift XR2S / XR3S / XR5S •...

  • Page 52: Equipment

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Equipment Hook models Hook, standard The safety lock on the gripping hook opens and closes by its own weight during the movement of the middle frame. The correct operation of the safety lock must be checked regularly and the surfaces greased every month.

  • Page 53: Locking Mechanisms Of The Hook

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Rakenne Koukkulaite XR - Rakenne Koukkulaite XR - Koukkulaitteen lukitustoiminnot Kippaus- ja päälleveto- / maahanlaskuliikkeiden turvallisuus on Locking mechanisms of the hook Koukkulaitteen lukitustoiminnot erilaisilla laitteeseen kuuluvilla lukituksilla. Kippaus- ja päälleveto- / maahanlaskuliikkeiden turvallisuus on Kippilukko (takarungon lukitseminen välirunkoo erilaisilla laitteeseen kuuluvilla lukituksilla.
  • Page 54 Hooklift Multilift XR2S / XR3S / XR5S User Manual Koukkulaite XR - S Käyttöohjekirja Rakenne Container locks Lavalukko Body lock alternatives Lavalukitusvaihtoehdot: • mechanical body lock • mekaaninen lavalukko • hydraulinen lavalukko (lisävaruste) Katso Hydraulijärjestelmä, osa Lavalukko. • hydraulic body lock Mechanical body lock Mekaaninen lavalukko Mekaanisen lavalukon muodostaa kaksi takarunkoon hitsattua lukkokoukkua,...
  • Page 55 Hooklift Multilift XR2S / XR3S / XR5S Rakenne Koukkulaite XR - S Käyttöohjekirja User Manual Lavalukkosylinteri ja esiohjattu vastaventtiili Body lock cylinder with blocking valve (optional) Takarungon takaosassa on lavalukot sulkeva ja avaava hydraulisylinteri. Sylinteri ohjaa molempia lavalukkokoukkuja samanaikaisesti. A hydraulic cylinder for locking and unlocking the body lock is located at the rear of the Sylinteriin on kiinnitettynä...
  • Page 56 Hooklift Multilift XR2S / XR3S / XR5S User Manual Control switch of hydraulic body locks Open body locks Close body locks The body locks open when the user presses the back of the boidy lock rocker switch and close when pressing the front part. Remove the element obstructing the locks, or if they are obstructed by the lock pocket in the container frame beam, check that the container is correctly positioned on top of the hook device.

  • Page 57: Electric System

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Electric system The power supply for the hooklift equipment is taken from the vehicle’s regular electrical system. See vehicles instructions for details. Proximity switches Rakenne Koukkulaite XR - S Käyttöohjekirja There are two proximity switches for increasing safety when handling the hooklift equipment that sense the current position of the rear frame and body locks.

  • Page 58: Additional Equipments

    Hooklift Multilift XR2S / XR3S / XR5S User Manual Additional equipments Additional hydraulics Auxiliary equipment connected to the XR S´s own hydraulics, is controlled by the additional hydraulic control switches, for example, tail gate, sand spreader, etc. Drive the cylinder of the hydraulic auxiliary equipment in Drive the cylinder of the hydraulic auxiliary equipment out Control switches of additional hydraulics XR2S/XR3S/XR5S...

  • Page 60: Maintenance

    Hooklift Multilift XR2S / XR3S / XR5S Service Manual This manual is a translation from the original maintenance instructions compiled in Finnish. MAINTENANCE Regular and correctly timed maintenance will increase the safety, reliability and economy of the hooklift equipment. All accomplished services and replacements of wearing parts are worth while to record.
  • Page 61 Hooklift Multilift XR2S / XR3S / XR5S Service Manual Safety instructions Loose, long hair, loose clothing, jewellery etc. are an accident risk. Use always personal protections and other protective means in service work. All modifications and additions made to the equipment construction, which might have an effect to the operational safety of the hooklift, are prohibited.
  • Page 62 Hooklift Multilift XR2S / XR3S / XR5S Service Manual • Inform the equipment operator of the start of the maintenance work. • If the equipment is damaged or otherwise non-functional, ensure that it cannot be started accidentally before and especially during the service work. •...
  • Page 63 Hooklift Multilift XR2S / XR3S / XR5S Service Manual Hooklift supported to tipping position If the work is done under the rear frame, the equipment must be lifted to tipping position and the frames supported with separate tipping support in the correct places. Remember to remove the support after the work has been completed.

  • Page 64: Service Table

    Hooklift Multilift XR2S / XR3S / XR5S Service Manual If the work has to be done on top of the equipment, note and prevent the risk of falling. All ladders, working platforms etc. must be kept clean from oil and grease. Fasten and tighten all removed components and screw joints after the service.
  • Page 65 Hooklift Multilift XR2S / XR3S / XR5S Service Manual Weekly Check the daily objects Check the oil level Check all valves, hoses and pipes Check the clearance of the rear rollers and shafts Check the clearances of other shafts Monthly Check the daily and weekly objects Wash the hooklift equipment carefully Lubricate all the lubrication points...

  • Page 66: Hydraulics Service

    Hooklift Multilift XR2S / XR3S / XR5S Service Manual Hydraulics service BE AWARE! Servicing, repairs and installations of the hydraulic components may be done only by persons trained for the jobs. Do not carry out any repair if you do not know the item to be repaired. Never carry out any service or repair on system under pressure.
  • Page 67 Hooklift Multilift XR2S / XR3S / XR5S Service Manual BE CAREFUL! Do not touch pressurised hydraulics. Do not remove any hydraulic components before the hooklift equipment has been supported mechanically. General • Keep the hydraulic system clean. • Keep the oil in a clean, locked space. When adding oil, use a funnel which has a fine filter net.
  • Page 68 Hooklift Multilift XR2S / XR3S / XR5S Service Manual Checking the air filter Check the condition of the air filter. Clean and replace it as necessary. Checking the condition of the oil It is possible to examine ageing and deterioration of the quality of oil in the following way: •...
  • Page 69 Hooklift Multilift XR2S / XR3S / XR5S Service Manual Changing the hydraulic oil Check that all piston rods of the cylinders are in retracted position. 2. Completely empty the oil tank via the drain plug. 3. Change the return filter. 4.
  • Page 70 Hooklift Multilift XR2S / XR3S / XR5S Service Manual Oil qualities Hydraulic system sets many requirements to the hydraulic oil characteristics. They contain amongst others: • Lubrication requirements • Oxidation prevention capability • Corrosion protection • Defoaming quality • High viscosity index, in other words, low change of viscosity when the oil is heated. In order to meet these requirements and qualities, additives are used in oils.
  • Page 71 Hooklift Multilift XR2S / XR3S / XR5S Service Manual Safety • Suitable eye and hand protection must be worn whilst carrying out this operation. • Ensure suitable containers to hold the amount oil you will be draining are available before starting this operation. Environment •...

  • Page 72: Safety Functions

    Hooklift Multilift XR2S / XR3S / XR5S Service Manual Safety functions Check the safety functions of all different movements; tipping, loading and unloading. Do the checks first without a container and thereafter with the container. Safety functions Check that: • hydraulic body locks cannot be opened during tipping (tipping device approx.
  • Page 73 Hooklift Multilift XR2S / XR3S / XR5S Service Manual Tipping device raised Loading position 110817116 4/2019 XR2S/XR3S/XR5S...

  • Page 74: General Inspection

    Hooklift Multilift XR2S / XR3S / XR5S Service Manual General inspection Check: • steel construction for deformations and breakages • hooklift fastening to the truck chassis, for breakages and loose bolts • fastening of the rear rollers. Check the securings of all shafts. •...

  • Page 75: Welding

    Hooklift Multilift XR2S / XR3S / XR5S Service Manual Welding Before welding, ensure the material to be welded, method and additives. Contact Multilift service, if needed. Welding may only be carried out by a trained welder. Check from the truck user manual all the electrical connections which need to be disconnected before welding.

  • Page 76: Repairing Damaged Paint Surface

    Hooklift Multilift XR2S / XR3S / XR5S Service Manual Repairing Damaged Paint Surface XR hooklift is painted with polyurethane paint in accordance with standard PUR 100/1 FeSa 2 ½. The frame of the device can optionally be coated with a zinc-primer before surface coating, in accordance with standard EPZn®PUR 140/2 FeSa 2 ½.

  • Page 77: Emergency Operation

    Hooklift Multilift XR2S / XR3S / XR5S Service Manual Emergency operation CAUTION! Internal safety functions of the device do not work in manual control mode. Therefore, be especially careful when carrying out the movements. If a failure happens in the electric system of the device, the device may be restored to its normal state, by operating the control valve manually: Press down the button located at the...

  • Page 78: Lubrication

    Hooklift Multilift XR2S / XR3S / XR5S Service Manual LUBRICATION Lubricate all the lubrication points at max 3 month intervals. A more recommended Koukkulaite XR - S Käyttöohjekirja Ylläpitohuolto lubrication interval would be 1 month. Voitelu Note! The hooklift equipment contains plastic surface slide bearings. Use LITHIUM based general lubrication grease (EP2).
  • Page 79 Hooklift Multilift XR2S / XR3S / XR5S Service Manual XR2S, XR3S, XR5S Point Lubrication point Number of nipples Main cylinder lower fastening Main cylinder upper fastening Middle frame bearing Rear rollers Rear frame bearing Hook arm slide tube (if necessary) spray (* Hooks of the hydraulic locks (accessory) (if necessary)

  • Page 80: Periodical Service

    Hooklift Multilift XR2S / XR3S / XR5S Service Manual Periodical Service The following services are recommended to be done on XR devices by an authorised Multilift Service Point: • delivery service in connection with the commissioning of the device • first service after 1 - 3 months after commissioning •...

  • Page 81: Service Card

    Hooklift Multilift XR2S / XR3S / XR5S Service Manual Service Card Services done below on XR hook device type XR _____________________ Serial Number _________________________________________________ Service Carried out by Signature Date Commissioning inspection 1st Service 2nd Service 3rd Service 4th Service 5th Service 6th Service 7th Service...

  • Page 82: Warranty Conditions

    WARRANTY CONDITIONS To the buyer You are now the owner of a demountable body system made by the Hiab factory indicated on the manufacturer’s plate and sold to you by an authorized Hiab dealer. With the demountable body system you will receive this Warranty and Maintenance Book, containing service instructions and warranty conditions.

  • Page 83: Owner's Warranty

    Hooklift Multilift XR2S / XR3S / XR5S Service Manual • That adjustment of pressure relief valve settings and where applicable load limiting valve settings is prohibited and will invalidate the warranty. • Miscellaneous ……………………………………………………………………………………….. ……………………………………………………………………………………….. Owner’s Warranty This Owner’s Warranty (hereinafter referred to as the ”Warranty”) applies to the products listed on the delivery card (hereinafter referred to as the ”Products”) which accompanies it.
  • Page 84 Hooklift Multilift XR2S / XR3S / XR5S Service Manual Extended Warranty Demountables An extended Warranty for the period of 5 years or 10 000 platform changes, whichever occurs first, shall apply to structural parts (as defined below), but the period shall never exceed 66 months from the date of delivery from factory.
  • Page 85 Hooklift Multilift XR2S / XR3S / XR5S Service Manual 1.5 After receipt of a written notice the Seller shall remedy the defect. Repairs will be carried out within a reasonable time, having regard to the nature of the defect and the difficulties of assessing it, the Owner’s need of the Product and the availability of spare parts and repair capacity.
  • Page 86 Any repair and/or change of parts have/has been carried out by the Seller or by a Hiab authorised repair Dealer. • Only Hiab genuine spare parts have been used. • Warranty repairs are made only by the Seller or other workshop authorized by Hiab.
  • Page 88 EC declaration of conformity of the machinery (Directive 2006/42/EC, Annex II, part 1, sub A) Cargotec Finland Oy, Multilift Nesteentie 36 FI-21200 Raisio Finland declare on our sole responsibility that the Ground Level Demountable Equipment Mark Multilift Type Serial number Manufacturing year •...

  • Page 89: Delivery Card

    DELIVERY CARD Country Country code Distributor Multilift Demountables Customer: Hooklift Address: Skiploader Contact person: Other Tel.: E-mail: Body builder / Dealer: Model Serial No. Delivered Pump model Oil tank Truck model Chassis No. Registration No. Accessories Part No. Serial No. The equipment described above has Installation and delivery service carried out been received today, assembled and fully...
  • Page 90 Cargotec improves the efficiency of cargo flows on land and at sea – wherever cargo is on the move. Cargotec’s daughter brands, Hiab, Kalmar and MacGregor are recognised leaders in cargo and Cargotec Finland Oy load handling solutions around the world. Cargotec’s global network...

This manual is also suitable for:
