AEROCET 5850 Maintenance Manual

Twin seaplane floats
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ISSUE
10/17/06
DATE:
REVISION
DATE:
9/10/12
MAINTENANCE MANUAL AND INSTRUCTIONS FOR CONTINUED
AEROCET MODEL 5850 TWIN SEAPLANE FLOATS
INSTALLED ON A DEHAVILLAND DHC-2 BEAVER AIRPLANE
This ICA must be followed when Aerocet 5850 Floats are installed in
accordance with Supplemental Type Certificate (STC) No. SA01722SE .
The information contained in this document supplements or supercedes the basic
manuals only in those areas listed herein. For limitations, procedures, and
performance information not contained in this manual, consult the basic aircraft
ICA or maintenance manual.
ICA Maintenance Manual for
TITLE:
5850 Floats on a
SUBTITLE:
DHC-2, Beaver
AIRWORTHINESS
FOR
Aerocet, Inc.
P.O. Box 2119
265 Shannon Lane
Priest River, Idaho 83856
Phone: (208) 448-0400
Fax: (208) 448-1644
Incorporated
FILE NO.
REVISION
PAGE
1 of 81
A-10034
2
