- Page 1 EchoLife HS8245W V300R017C10 Installation Guide Issue: 01 Date: 2017-01-11 HUAWEI TECHNOLOGIES CO., LTD.
-
Page 2: Safety Information
• When operating Huawei products and devices, comply with safety precautions and special safety instructions specific to each Huawei. The safety precautions in the document are only related to Huawei products. Huawei is not liable for any consequence arising from the violation of universal regulations for safety operations and safety codes on design, production, and use. - Page 3 Safety Information Laser Safety • Detailed description ① Keep the optical ports of the module clean, and cap them when they are not used. ② Prevent the end faces of the optical interfaces of the module from being damaged by hard objects. ③...
-
Page 4: Installation Precautions
Installation Precautions Attaching Labels/Tags Attach a label or tag to the signal cable 20 mm (0.79 in.) away from the connector. When the cable is placed vertically, the label or tag should point to the right. When the cable is placed horizontally, the label or tag should point downwards. -
Page 5: Tools Preparation
Preparations Tools Preparation Before beginning the installation, prepare the following tools and meters. M3-M6 Marker pen Level Long measuring tape Phillips screwdriver Cable cutter Wire stripper Hammer drill ESD gloves Screw (2 pcs) Multimeter Rubber Mallet Drilling template Optical power meter Fiber cleaner... - Page 6 Preparations Preparing the Construction Environment Item Method • Select a site that is free of high temperatures, heavy dust, harmful gas, inflammable or explosive materials, low air pressure, great shock, or sharp noise. Site selection • Ensure that the site location (such as a wall) meets the bearing capacity requirement of the product.
- Page 7 • The project supervisor must check the products on site in the presence of the customer. • If the package is damaged, stop unpacking and report the condition of the package to a local Huawei representative. If the quantity of the product is correct and the product is in good condition, unpack and accept the product.
- Page 8 Unpacking and Accepting Products Device Inspection Verify that the device is in good condition, without any damage. Verify that the device components are complete, without any missing parts. Cables Inspection Failure to examine the cables may result in catastrophic equipment damage and service failure. Verify that the specifications of cable connectors meet the requirements for your site.
- Page 9 Product Overview and Technical Specifications Product Overview Product Function 4 Ethernet ports 2 POTS ports HS8245W 2 USB port (USB 2.0 + USB 3.0 ) 2.4 G Wi-Fi (3*3 MIMO)+ 5 G Wi-Fi (4*4 MIMO) Technical Specifications Item Specifications Dimensions (L x W x H) 295 mm x 180 mm x 82 mm ≤...
-
Page 10: Installation Procedure
Installing HS8245W Installation Procedure • The HS8245W can be installed in environments such as a network cabinet or a wall, and is generally mounted on a wall. • Only one operator is required for installing the HS8245W. It is recommended that the operator wear ESD gloves during the installation. - Page 11 Installing HS8245W Quick Installation HS8245W IP STB Optical port USB storage device Phone TV set Optical port Ethernet port POTS port USB port WLAN switch WPS switch Reset Power port Figures in this document may be different from the actual product. However, these differences do not affect the product usage.
- Page 12 Installing HS8245W Quick Installation HS8245W Step 1: Use an optical fiber to connect the optical port on the ONT and the optical port on the wall. 1.The type of the optical connector connected to the optical port in the all is determined by practical conditions. 2.To ensure normal use of fibers, make sure that the fiber bend radius is larger than 30 mm.
- Page 13 Installing HS8245W ONT supporting Wi-Fi, a wireless network coverage is subject to the number, thickness, and positions of walls, materials, ceilings, or other objects that radio signals traverse. Besides, material type and background radio frequency (RF) noise also affect the coverage of a wireless network. You can maximize the coverage of a wireless network using the following methods: 1.
-
Page 14: Indicator Description
Indicator Description Table 1 Indicator status description 1 Status Description Steady on The device is powered on POWER The power supply is cut off. See Table 2. See Table 2. The terminal is registered with the softswitch but no service Steady on flows are transmitted. - Page 15 Indicator Description Table 2 Indicator status description 2 Status Status Description The PON terminal is prohibited by the upper-layer device or blinks abnormally , contact the service Blinks twice a Blinks twice a provider for help. second second Blinks twice a The GPON terminal attempts to set up a second connection with its upper-layer device.
- Page 16 FAQs FAQs 1. The LOS indicator blinks. If the LOS indicator blinks once two seconds, check whether the pigtail fiber is properly connected and the connector is clean. If the GPON terminal blinks twice a second, contact the service provider for help 2.
-
Page 17: Warranty Card
Warranty Card Thank you for choosing Huawei Technologies Co., Ltd. To get better services, please read this warranty card carefully, fill in the required information, and preserve this card in good condition. User Information Personal or company's full name:____________________________________ Address/Postal Code:_____________________________________________... -
Page 18: Limited Warranty
In any case that is not covered by this limited warranty or should the warranty expire, Huawei shall charge for the service(s) claimed for the products if the product is still remediable. Huawei reserves all rights to interpret this limited warranty. - Page 19 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 20 HUAWEI TECHNOLOGIES CO., LTD. Huawei Industrial Base Bantian Longgang Shenzhen 518129 People’s Republic of China www.huawei.com...
