- Page 1 Z604 Product Manual Realtimes Beijing Technology Co., LTD. Fax：+86 010-84284669 / 84280996 Email: info@realtimes.cn Web Page: http://www.realtimesai.com Address:11th Floor, Block B, 20th Heping Xiyuan, Pingxi Street, Chaoyang District, Beijing 100013,P.R.China...
- Page 2 Revision History Revision Date Reason for change Revision Modifier V1.1 2021-07-27 Initial release V1.1 RT0086 V1.2 2021-08 Add sub-model V1.1 RT0086 Z604 Reference Manual V1.1...
- Page 3 Realtimes Beijing Technology Co.,LTD www.realtimesai.com Electronic components and circuits are very sensitive to electrostatic discharge. Although our company designs anti-static protection for the main interfaces on the card when designing circuit board products, it is difficult to achieve anti-static safety protection for all components and circuits. Therefore, it is recommended to observe anti-static safety precautions when handling any circuit board component (including Z604).
- Page 4 Realtimes Beijing Technology Co.,LTD www.realtimesai.com ⚫ Do not modify or use unauthorized accessories by yourself, and the damage caused will not be warranted; After sales maintenance 1) Warranty period ⚫ Base plate, core plate : 3 year (non-human damage) ⚫ Other peripherals sold by the company:1year(non-human damage) 2) Warranty description ⚫...
- Page 5 Realtimes Beijing Technology Co.,LTD www.realtimesai.com guarantee that all kinds of questions can be answered one by one. The following content is not available for technical support, only suggestions can be provided. 1) Knowledge beyond the course published by our company; 2) Specific software program design;...
-
Page 6: Table Of Contents
Realtimes Beijing Technology Co.,LTD www.realtimesai.com TABLE OF CONTENTS 1 PRODUCT INTRODUCTION..........................6 ................................6 1.1 F EATURES ...........................8 1.2 O RDERING NFORMATION 2 EXTERNAL INTERFACE FUNCTION AND LOCATION................9 3 INSTALLATION AND USE..........................10 ....................... 10 3.1 S YSTEM INSTALLATION RENDERINGS ................................10 3.2 D RIVE .......................... -
Page 7: Product Introduction
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 1 Product introduction Z604 is a new Feiyun Smart Box ™ based on the NVIDIA Jetson Nano/Xavier NX/TX2 NX module design. The default built-in Xavier NX module with integrated 384-core Volta ™ architecture GPU, pre-installed Ubuntu 18.04 operating system, and 21TFLOPS floating-point operations AI processing capabilities. - Page 8 Realtimes Beijing Technology Co.,LTD www.realtimesai.com Type Z604 Z604-TX2 NX Z604-NANO Interface 4 x USB Type A ports, support usb2.0, usb3.0/usb3.1 signals, and provide 1.5A output current； 1 x Micro USB port, support usb host and usb device mode, provide 0.5A output current。...
-
Page 9: Ordering Information
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 1.2 Ordering Information Model Options Functional Description Xavier NX Feiyun Smart Box Conductive Cooling Edition, built-in Xavier NX module, pre-installed Ubuntu 18.04, built-in 16GB eMMC; 2 x GbE, 1 x M.2 KEY B, 1 x M.2 KEY E, 1 x M.2 KEY M, 1 x HDMI, 4 x USB3.0, 2 x CAN, 2 x RS485, 4 x GPIO, 1 x Debug UART, 1 x FORCE RECOVERY, 1 x Z604... -
Page 10: External Interface Function And Location
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 2 External interface function and location Z604 FRONT Z604 BACK Z604 Reference Manual V1.1... -
Page 11: Installation And Use
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 3 Installation and use 3.1 System installation renderings 3.2 Drive The Z604 carrier board works on a system burned with the official original version of NVIDIA Linux For Tegra (L4T). HDMI, Gigabit Ethernet, USB2.0, serial port, GPIO, SD card, I2C bus can all be supported. But Mini-PCIe, USB3.0, fan interface, etc. -
Page 12: How To Use Smart Box
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 3.3 How to use Smart Box a) Make sure that the voltage of all external systems is turned off b) Install the Jetson Nano/Xavier NX/TX2 NX core module to the 260-pin SO-DIMM connector.Please pay attention to the alignment between the connectors during the installation process, and install the fixing screws at the same time. -
Page 13: Connectors Description
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 4 Connectors Description 4.1 Micro USB Interface Function Micro USB interface Marking Type USB 2.0 MicroType-B Pin define Signal Signal VBUS USB 2.0 D- USB 2.0 D+ USB ID 4.2 USB3.0 Interface Function USB Connector Marking USB x 2 Dual USB Type-A interface... -
Page 14: Gigabit Ethernet
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 4.3 Gigabit Ethernet Function Ethernet connector Marking GbE1、GbE2 Type RJ45 Pin define Signal Signal TP0+ TP0- TP1+ TP2+ TP2- TP1- TP3+ TP3- 4.4 HDMI Display interface Function HDMI Display connector HDMI Marking HDMI Type Pin define Signal Signal TMDS Data2+... -
Page 15: Micro Sd（Tf）Card Socket
Realtimes Beijing Technology Co.,LTD www.realtimesai.com Debug_UART_TXD Debug_UART_RXD FORCE_RECOVERY POWER_BTN_IN_MCU SYS_RST Pin 1: The yellow box mark in the picture on the right. Pin 2: The box mark in the picture on the right. 1_RS485 mapping file in Linux system is ttyTHS1 under /dev directory. -
Page 16: Power Connector
Realtimes Beijing Technology Co.,LTD www.realtimesai.com 4.8 Power connector Function Power connector Marking DC12V Type 2 pin terminal Pin define Signal Signal VCC (+) GND (-) Input voltage range: +9V~+20V Live connection of cables is strictly prohibited! Hardware update history Z604 Board card hardware update history Revision Reason for change V1.1... -
Page 17: Terms Of Warranty
Realtimes Beijing Technology Co.,LTD www.realtimesai.com Terms of Warranty Important note Each embedded product provided by Realtimes Technology is free from any defects in material and process,fully in line with the specifications officially issued by the original factory. Realtimes Technology warranty covers the original products,If the parts configured by the dealer are out of order, please consult with the dealer to solve the problem. - Page 18 Realtimes Beijing Technology Co.,LTD www.realtimesai.com monitor,I/O boards,cables,power supply, diagram and structure of the system,etc.If such documents or information are not available,we have the right to refuse to perform the warranty, the repairments will be charged accordingly. Rev.C 6/2020 Z604 Reference Manual V1.1...
