T10 Pro Smart
Thermostat with
RedLINK™
THX321WFS2001W
Programmable Thermostat
Professional Install Guide
Read before installing
Package Includes:
• T10 Pro Smart Thermostat
• UWP™ Mounting System
• Standard Installation Adapter (J-box
adapter)
• Cover Plate – Medium: Size 5-11/64" X
5-1/2" X 11/16" (131.4 mm x 139.7 mm
x 17.5 mm)
• RedLINK Wireless Indoor Air Sensor
(QTY 1)
• Screws and Anchors
• Professional Install Guide
• Getting Started Guide
Compatibility
• Compatible with most heating, cooling, and heat pump systems
• Required: 24 VAC power ("C" wire)
• Does not work with electric baseboard heat (120-240V)
• Does not work with millivolt systems
• Android or iOS smartphone or tablet
Customer assistance
WEB honeywellhome.com
PHONE 1-800-633-3991
THX321WF2001W depicted.
Other models may vary.
Search for local rebates.
Honeywell Home thermostats
work with utility programs to
reward you for helping save
energy.
HoneywellHome.com/Rebates
33-00423EFS-05
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Honeywell T10 Pro
Summary of Contents for Honeywell T10 Pro
- Page 1 Thermostat with RedLINK™ THX321WFS2001W Programmable Thermostat Professional Install Guide Read before installing Package Includes: • T10 Pro Smart Thermostat THX321WF2001W depicted. • UWP™ Mounting System Other models may vary. • Standard Installation Adapter (J-box adapter) Search for local rebates. • Cover Plate – Medium: Size 5-11/64" X Honeywell Home thermostats 5-1/2”...
- Page 2 Wiring UWP Push down on the tabs to put the wires into the inner holes of their corresponding termi nals on the UWP (one wire per terminal) until they are firmly in place. Gently tug on the wires to verify they are secure. If you need to release the wires again, push down the terminal tabs on the sides of the UWP.
-
Page 3: Sensor Installation
Sensor installation 1. Remove white cover from grey base and Insert (2) AAA Alkaline batteries in the sensor. 2. Open the menu. 3. Tap "Devices & Sensors." 4. Tap "Add." Devices & Sensors 5. Follow the on-screen instructions. 6. Snap the sensor onto the wall-plate. 7. - Page 4 How to find more options 1. Touch the menu button. 2. Scroll up and down for more options. Installer Options Menu options include Installer Setup • System type • IAQ control (hum, dehum, vent) reminders Installer Test • Turn on heat, cool, or IAQ equipment Devices &...
-
Page 5: Specifications
Golden Valley, MN 55422 www.resideo.com ©2019 Resideo Technologies, Inc. This product is manufactured by Resideo Technologies, Inc., Golden Valley, MN, 1-800-633-3991 The Honeywell Home trademark is used under license from Honeywell International Inc. All rights reserved. 33-00423EFS—05 M.S. Rev. 10-19 Printed in U.S.A.
Need help?
Do you have a question about the T10 Pro and is the answer not in the manual?
Questions and answers
After setting up Heat pump and connecting all wires correctly, heat pump does not come on. Why?
The Honeywell T10 heat pump may not be turning on after correct setup and wiring due to one or more of the following issues:
1. L wire energized: This indicates a problem with the heat pump system. A contractor should be contacted to diagnose and service the unit.
2. Thermostat memory or sensor failure: Errors such as "MEMORY ERROR," "INTERNAL SENSOR," or "ERROR INTERNAL HUM TEMP" suggest a hardware failure in the thermostat. The thermostat needs to be replaced.
3. Power loss or Wi-Fi issues: If the thermostat shows "ERROR THERMOSTAT" or "UNKNOWN TIME," it may have lost power or has poor Wi-Fi communication. Resetting the time or verifying Wi-Fi connection may resolve it.
4. Indoor sensor issues: Errors like "INDOOR SENSOR ERROR" or sensor disconnection messages may also prevent proper system operation. Replace the sensor or its batteries.
In summary, the issue could be due to a fault in the heat pump, thermostat failure, power or Wi-Fi problems, or sensor issues. Each requires specific troubleshooting or replacement.
