Sony DAV-DZ340K Quick Setup Manual

Quick Setup Guide
DAV-DZ340K/DZ640K/DZ840K/DZ940K
1

Connecting the speakers

For DAV-DZ640K/DZ840K/DZ940K, speaker assembly is necessary. Refer to the supplied "Speaker
Installation Guide."
To connect speaker cords to the speaker
Connect the cord so that the cord's color tube
matches the color of the label on the rear of the
speaker.
For all models, connect the speaker cords to match the color of the SPEAKERS jacks of the unit.
Rear panel of the main unit
R
TV
DIG ITAL
White
IN
AL
OP TIC
TV
L
FRO NT
R
FRO NT
CEN TER
RS
OFE R SP EA KE
SUB WO
Red
SUR L
SUR R
SP EA KE RS
Green
Gray
Purple
Blue
FRONT L
DAV-DZ340K is the model used for illustration purposes.
©2011 Sony Corporation Printed in China
Rear of the front, surround and center
speakers
SUBWOOFER
CENTER
FRONT R
Main unit
SUR R
SUR L
(1)
4-286-727-11(1)
2
Connecting your TV/set-top box
Depending on the jacks on your TV or set-top box, select the video and audio connection method.
Connecting the video to your TV
VIDEO
*1 The HDMI cable is supplied with certain models/in certain areas only.
*2 Not supplied. The COMPONENT VIDEO OUT jacks are available on DAV-DZ640K/DZ840K/DZ940K only.
Connecting the audio from your set-top box
If you do not use a set-top box, refer to "Connecting your TV/set-top box" in the Operating Instructions.
AUDIO
*1 Not supplied.
*2 Not supplied. The TV (DIGITAL IN OPTICAL) jack is available on DAV-DZ840K/DZ940K only.
For details, refer to the Operating Instructions.
