Infinix Note 10 Pro User Manual page 2

E x p l o s i
E x p l o s i
1 FL(CTP+LCM
3 PCBA Main
5 Back Camera
7 REC Deco part
9 LT sensor diffuse film
11 REC con fb
13 Fornt CAM rubber
15 SPK
17 Bat cover asm
19 Rear CAM Lens
21 Shield Imp foam
23 LCM FPC con rubber
25 trope fill foam
27 FPC Side key
29 Moto
31 USB Seal rubber
33 SUB PCB BTB Rubber
35 SPK frame asm
37 R CAM Con foams
39 Shield Seal Cop foil
41 FP support foam
o n d i a g
o n d i a g
r a m s p e
r a m s p e
2 fornt housing Assembly
4 Front Camera
6 Back Camera
8 F CAM Cop foil
10 M1.4xL3.5 SCREW
12 LT sensor Seal rubber
14 M1.4xL2.5 SCREW
16 UP frame asm
18 MAIN seal mylar
20 Fingerchip spacer
22 Bat con rubber
24 FP con imp steel asm
26 R trope foam B
28 PCBA SUB
30 Battery
32 Audio Jack Seal rubber
34 coaxial cable
36 3in1 card holder
38 Audio cavity seal mylar
40 FP Con Foams
42
1
c i f i c a t i o
c i f i c a t i o
n
n
