- Page 1 VSC-5882A 5.8GHz Wireless Outdoor CMOS Camera 1107...
-
Page 2: Table Of Contents
Contents 1.Important Safety Information........1 2.Specification............. .1 3.Package Content ............2 4.Panel Control Function ........2 5.Setup Guide ...............3 1.Important Safety Information To prevent fire or shock hazard, do not expose this product to rain and moisture. For example: do not use near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or nearby a swimming pool. -
Page 3: Package Content
3.Package Contents Check to make sure that all units shown as below are enclosed. If something missing, please contact your dealer. 2. Cover X1,Screw X 2 1. 5.8GHz CMOS Camera X 1 3.Power Adapters (12V/300mA) 4. Bracket X1 2.Package Contents 4.Panel Control and Function 5.8GHz COMS Camera 1 DIP-Switch for channel selection. -
Page 4: Setup Guide
2.Package Contents 5.Setup Guide Fig. 1 1 According to the diagram, Connect the DC plug of the power adapter to the DC jack, and connect the power adapter to an outlet(As shown in Fig.1). 2 DIP-Switch for Channel Selection, to find optimal reception, the transmitter and receiver must to be configured as the same channel(As shown in Fig.2). - Page 5 3 Switch to the optimal channel before put on waterproof cover and fasten the screw. (As shown in Fig 3) Waterproof cover Fig. 3 Screw...
- Page 6 Preliminary Specification VSC-5882 5.8GHz Wireless Outdoor CMOS Camera Document Number ： PSC08002 Page ： Revision ： 1A Date ： 2008-10-31 TRANWO Technology Corp. www.chemlink.com.tw...
- Page 7 1. Introduction This document describes the specifications and features of the CHEMLINK 5.8GHz Wireless outdoor CMOS Camera which use FM modulation technology for wireless A/V transmission. 2. Features Avoids interference from crowded 2.4GHz ISM applications such as video senders, 802.11b WLAN equipment, Bluetooth-enable products, cordless phones, microwave ovens, etc.
- Page 8 Video Input Level ± 0.15 V Load Impedance 75 ohms Pre-Emphasis NTSC & PAL Image Sensor 1/3” CMOS Sensor Image area 5.961mm*4.276mm Array size 510 X 496 (NTSC) 628 X 586 (PAL) Illumination Night Vision Range 10 m LENS LENS f6.0mm, F2.0 , (4 glasses with IR cut filter) LENS focus...
- Page 9 4. Photograph Wireless CMOS Camera...
