MONITOR STAND INSTRUCTIONS

Supports up to 1 x 65" screen or 3 x 27" screens
1 x 50mm M8 screws
4 x 16mm M8
each side (3 screen setup)
screws each side
2 x 60mm M8
*Please skip this step if only setting up 1 screen
screws each side
2 x 20mm
2 x 20mm
M8 screws
UP
M8 screws
DOWN

TIPS

*For triple screen setups if you need to lift the
height of the outer screens loosen the 1 x 50mm
screw on each side of the outer arms (from step
3) and physically hold the screens higher in
position before then tightening the screws to
lock.
*In step 5 you will see the middle screen has

Attach large brackets for centre screen

adjustment to go up or down by using the
vertical holes.
For assistance please contact: support@nextlevelracing.com
